DRA-60 series LPS. 60W Single Output Switching Power Supply. File Name:DRA-60-SPEC Sicherheit ID

Μέγεθος: px
Εμφάνιση ξεκινά από τη σελίδα:

Download "DRA-60 series LPS. 60W Single Output Switching Power Supply. File Name:DRA-60-SPEC Sicherheit ID"

Transcript

1 PS Bauartgepruft Sicherheit egelma ge od o s be wac g www. tuv.com ID

2 SPECIFICATION MODE DRA DRA DC VOTAGE 12V 24V CONSTANT CURRENT REGION 3 ~ 12V 3 ~ 24V RATED CURRENT 5A 2.5A CURRENT RANGE 0 ~ 5A 0 ~ 2.5A RATED POWER 60W 60W OUTPUT RIPPE & NOISE (max.) Note.2 120mVp-p 150mVp-p VOTAGE ADJ. RANGE 12 ~ 15V 24 ~ 30V VOTAGE TOERANCE Note.3 ±1.0% ±1.0% INE REGUATION ±0.5% ±0.5% OAD REGUATION ±0.5% ±0.5% SETUP, RISE TIME Note.4 0ms, 90ms/230VAC 800ms, 90ms/115VAC at full load HOD UP TIME (Typ.) 50ms/230VAC 10ms/115VAC at full load VOTAGE RANGE 90 ~ 264VAC 127 ~ 370VDC [DC input operation possible by connecting AC/(+), AC/N(-)] FREQUENCY RANGE 47 ~ 63Hz INPUT EFFICIENCY (Typ.) 85% 87% AC CURRENT (Typ.) 1.3A/115VAC 0.8A/230VAC INRUSH CURRENT (Typ.) COD START 30A/115VAC 60A/230VAC PROTECTION OVEROAD 95 ~ 108% rated output power Protection type : Constant current limiting, recovers automatically after fault condition is removed OVER VOTAGE ~ 18.63V ~ 37.26V Protection type : Shut down o/p voltage, re-power on to recover WORKING TEMP. -30 ~ +70 (Refer to "Derating Curve") WORKING HUMIDITY 20 ~ RH non-condensing ENVIRONMENT STORAGE TEMP., HUMIDITY - ~ +85, 10 ~ 95% RH TEMP. COEFFICIENT ± 0.03%/ (0 ~ 50 ) on output VIBRATION 10 ~ 500Hz, 2G 10min./1cycle, 60min. each along X, Y, Z axes SAFETY STANDARDS U , TUV EN approved SAFETY & WITHSTAND VOTAGE I/P-O/P:3KVAC I/P-FG:2KVAC O/P-FG:0.5KVAC EMC ISOATION RESISTANCE I/P-O/P, I/P-FG, O/P-FG:M Ohms / 500VDC / 25 / RH (Note 5) EMC EMISSION Compliance to EN55032 (CISPR32) Class B, EN60-3-2,-3 EMC IMMUNITY Compliance to EN60-4-2,3,4,5,6,8,11, EN55024, EN , light industry level, criteria A OTHERS NOTE MTBF DIMENSION PACKING 436.4K hrs min. MI-HDBK-217F (25 ) *90*mm (W*H*D) 0.3Kg; 42pcs/13.6Kg/0.82CUFT

3 Block Diagram I/P EMI RECTIFIERS & POWER SWITCHING RECTIFIERS & O.C.P. +V -V FG O..P. CONTRO DETECTION CIRCUIT O.V.P. Derating Curve Static Characteristics VAC Input only OAD (%) 20 OAD (%) (VERTICA) AMBIENT TEMPERATURE ( ) INPUT VOTAGE (V) 60Hz OUTPUT CURRENT ADJUSTMENT OPERATION Built-in 3 in 1 current adjustment function. Output constant current level can be adjusted by applying 1 ~ 10Vdc, 10V PWM signal or resistance between and. Please DO NOT connect "" to "-V". Reference resistance value for output current adjustment (Typical) Resistance value Applied Source Single Power supply Multiple Power supplies (N=Power supply quantity for simultaneous current adjustment control) 10KΩ 1 ~ 10Vdc for output current adjustment (Typical) 60KΩ 10K Ω/N 20K Ω/N 30K Ω/N K Ω/N 50K Ω/N 60K Ω/N 70K Ω/N 80K Ω/N 90K Ω/N K Ω/N %~108% 1V 2V 3V 4V 5V 6V 7V 8V 9V 10V 20KΩ 30KΩ KΩ 50KΩ 70KΩ 80KΩ 90KΩ KΩ 102%~108% 10V PWM signal for output current adjustment (Typical): Frequency range :Hz ~ 3KHz Duty value 102%~108%

4 Using the current adjustment function can not adjust the output current to 0A. Please refer to the connection method below to adjust the output current to 0A. OAD 10K~K Ohms resistance 1~10V DC Voltage 10V PWM Signal Adjuster +V +V -V -V DC OK + +V ADJ Switch N Relay FG N DRIVING METHODS OF APPICATIONS The power supply may either work in "constant voltage mode or constant current mode" Rated output voltage (A) Constant Voltage area (B) Constant Current area In the constant current region, the highest voltage at the output of the driver depends on the configuration of the end systems. Should there be any compatibility issues, please contact MEAN WE. 3V Vo(v) (C) Hiccup Protection 50 Io (%)

5 35 60W Single Output Switching Power Supply Mechanical Specification Case No.962A Unit:mm V +V -V -V DC OK V ADJ N Installation Instruction This series fits DIN rail TS35/7.5 or TS35/15. For installation details, please refer to the Instruction manual. ADMISSIBE DIN rail:ts35/7.5 OR TS35/15 (For reference only. Not included with unit.) Back View Installation Manual Please refer to :
