2 IT Millions of services.004 MIPS 20 MIPs 124,000 MIPS 2 Copyright 2015Hewlett-Packard Development Company, L.P. The information contained herein is subject to change without notice. Compute Compute compute Compute Compute Software defined Management / / 3 Copyright 2015Hewlett-Packard Development Company, L.P. The information contained herein is subject to change without notice

3 Compute Converged Infrastructure Converged Cloud Software-Defined infrastructure 4 Copyright 2015Hewlett-Packard Development Company, L.P. The information contained herein is subject to change without notice. Software-Defined Networking (SDN) Gartner Magic Quadrant Data Center Networking 2014 Source: Gartner Magic Quadrant for Data Center Networking April, 2014 ID Number: G This Magic Quadrant graphic was published by Gartner Inc. as part of a larger research note and should be evaluated in the context of the entire report. The Gartner report is available upon request from HP. Gartner does not endorse any vendor, product or service depicted in its research publications, and does not advise technology users to select only those vendors with the highest ratings. Gartner research publications consist of the opinions of Gartner's research organization and should not be construed as statements of fact. Gartner disclaims all warranties, expressed or implied, with respect to this research, including any warranties of merchantability or fitness for a particular purpose. 5 Copyright 2015Hewlett-Packard Development Company, L.P. The information contained herein is subject to change without notice

4 !? 6 Copyright 2015Hewlett-Packard Development Company, L.P. The information contained herein is subject to change without notice. / LAN (bps) LAN 400GBASE 40/100G 10G 1000M 100M 10M 2.94M ALOHA i 10BASE5 10BASE-T 802.3u 100BASE-T 2.4GHz / 2Mbps z 1000BASE-X 802.3ae 10GBASE-X/R/W 5GHz / 54Mbps a b g 802.3ba 40G/100GBASE-R 5GHz / 6.9Gbps 2.4, 5GHz / 600Mbps n LAN ac 25/50GBASE MGBASE-T Multi Rate Gigabit X 7 Copyright 2015Hewlett-Packard Development Company, L.P. The information contained herein is subject to change without notice

5 60 CPU 8 Copyright 2015Hewlett-Packard Development Company, L.P. The information contained herein is subject to change without notice. 9 Copyright 2015Hewlett-Packard Development Company, L.P. The information contained herein is subject to change without notice

6 HP Photonics Photonics / 10 Copyright 2015Hewlett-Packard Development Company, L.P. The information contained herein is subject to change without notice. CPU Memristor CPU Memristor Photonics CPU Memristor 11 Copyright 2015Hewlett-Packard Development Company, L.P. The information contained herein is subject to change without notice

7 Photonics Special purpose cores The Machine Massive memory pool 12 Copyright 2015Hewlett-Packard Development Company, L.P. The information contained herein is subject to change without notice. 13 Copyright 2015Hewlett-Packard Development Company, L.P. The information contained herein is subject to change without notice

8 2020? 14 Copyright 2015Hewlett-Packard Development Company, L.P. The information contained herein is subject to change without notice. HP Software-Defined 2 Leaf/Spine SDN 1 FlexFabric 12x00 core FlexFabric 59xx access FlexFabric 12900, 5900 Spine FlexFabric 5970 Leaf Traditional or Spine and Leaf design options VXLAN HP Comware OS HP BladeSystem, 6125XLG FlexFabric EoR 15 Copyright 2015Hewlett-Packard Development Company, L.P. The information contained herein is subject to change without notice

9 Fabric (Spine: 5900, Leaf: 5700) Leaf Spine I/OSpine STP 16 Copyright 2015Hewlett-Packard Development Company, L.P. The information contained herein is subject to change without notice. Leaf/Spine HP STP, TRILL, SPB Enhanced 4 9 STP, TRILL, SPB Enhanced Control Bridge (CB) Port Extender (PE) STP, TRILL, SPB 17 Copyright 2015Hewlett-Packard Development Company, L.P. The information contained herein is subject to change without notice

10 Management CPU L2/L3 Forwarding ASIC Management Forwarding L2 / L3 18 Copyright 2015Hewlett-Packard Development Company, L.P. The information contained herein is subject to change without notice. LAN Switch Management CPU Routing Table MPU #1 LAN Switch Management CPU Routing Table MPU #2 LAN Switch LPU CPU Forwarding Table L2/L3 Forwarding ASIC LPU #1 LAN Switch LPU CPU... Forwarding Table L2/L3 Forwarding ASIC Switch Fabric LPU #2 LAN Switch LPU CPU Forwarding Table L2/L3 Forwarding ASIC LPU #X 19 Copyright 2015Hewlett-Packard Development Company, L.P. The information contained herein is subject to change without notice

11 Enhanced Controlling Bridge (CB) Controlling Bridge (CB) Enhanced CB PE Enhanced Port Extender (PE) Port Extender (PE) Port Extender (PE) 1 (config) 1 Controlling Bridge / CB - PE 20 Copyright 2015Hewlett-Packard Development Company, L.P. The information contained herein is subject to change without notice. Enhanced L3 OSPF/BGP/ISIS L3 L2 Fabric Enhanced CB Fabric CB CB Enhanced PE PE PE Fabric Enhanced 21 Copyright 2015Hewlett-Packard Development Company, L.P. The information contained herein is subject to change without notice

12 FC, FCoE, iscsi HP 5900CP FCoE iscsi / NAS FC Native FC Native Ethernet FCoE 22 Copyright 2015Hewlett-Packard Development Company, L.P. The information contained herein is subject to change without notice.? HP 23 Copyright 2015Hewlett-Packard Development Company, L.P. The information contained herein is subject to change without notice

13 HP Software-Defined 2 Leaf/Spine SDN 1 FlexFabric 12x00 core FlexFabric 59xx access FlexFabric 12900, 5900 Spine FlexFabric 5970 Leaf Traditional or Spine and Leaf design options VXLAN HP Comware OS HP BladeSystem, 6125XLG FlexFabric EoR 24 Copyright 2015Hewlett-Packard Development Company, L.P. The information contained herein is subject to change without notice. VXLAN? Virtual Extensible Local Area Network (VXLAN) L2/L RFC HP VXLAN Data Center (DC) 1 Virtual Overlay VXLAN tunnels Extended Over WAN Data Center (DC) 2 Hypervisor L2 or L3 Hypervisor L3 WAN Hypervisor L2 or L3 Hypervisor Physical Underlay Network Physical Underlay Network 25 Copyright 2015Hewlett-Packard Development Company, L.P. The information contained herein is subject to change without notice

14 VXLAN Tunnel End Point (VTEP) VXLAN End Point / Hypervisor Software VTEP Hardware VTEP VXLAN VTEP VTEP Hardware VTEP QoS Critical Point Outer Header Encapsulation HostA = VTEP VXLAN frame Virtual Network 1000 Underlay Network Virtual Network Hypervisor r / Software 1001 VTEP A Switch / Hardware VTEP C Outer Header VXLAN Hypervisor /Software VTEP B frame De-encapsulation HostB = VTEP Encapsulation/ Deencapsulation 1 2 n frame Switch = VTEP frame Physical Server 5 26 Copyright 2015Hewlett-Packard Development Company, L.P. The information contained herein is subject to change without notice. n HP ware SDN ware NSX SDN ConvergedControl HP VAN SDN HP SDN Manager vcenter HP Intelligent Management Center (IMC) SDN ware NSX ware NSX HP Helion HP and ware Collaborate to Simplify Software-Defined Data Center and Hybrid Cloud Adoption (Press Release: August 25, 2014) 27 Copyright 2015Hewlett-Packard Development Company, L.P. The information contained herein is subject to change without notice

15 ware NSX HP VAN SDN Controller HP Converged Control SDN Application Northbound APIs Southbound Protocols: SNMP, Netconf and OpenFlow HP VAN SDN Controller OVSDB Spine Switches Spine Switches NSX Service Node Unicast Layer 3 Underlay Network OVSDB NSX Manager NSX Controller 5930 Leaf Switches/ VTEPs 5900 Leaf Switches Physical Servers, WAN Routers/Firewalls 28 Copyright 2015Hewlett-Packard Development Company, L.P. The information contained herein is subject to change without notice. Hypervisor Software VTEPs HP Virtual Cloud Networking (VCN) SDN Compute Virtual Cloud Networking SDN K HP Helion OpenStack Networking Storage SDN HP SDN IMC HP VAN SDN HP SDN / SDN SDN Copyright 2015Hewlett-Packard Development Company, L.P. The information contained herein is subject to change without notice

16 HP HP VCN, DCN ware 3 VCN HP-ware Industry most complete cloud solution VCN VCN+ware Virtual Cloud Networking OpenStack SDN VCN Application HP VAN Controller DCN FlexFabric Portfolio Virtualized Services Directory DCN Virtualized Services Controller HP Virtual Switch vcenter vsphere vc NSX vs NSX HP-ware Networking Solution Distributed Cloud Networking 30 Copyright 2015Hewlett-Packard Development Company, L.P. The information contained herein is subject to change without notice HP!,, HP End to End 31 Copyright 2015Hewlett-Packard Development Company, L.P. The information contained herein is subject to change without notice

17 Thank you A-1 A-1 14:50HP SDN Innovation Summit 2015 SDN Copyright 2015Hewlett-Packard Development Company, L.P. The information contained herein is subject to change without notice HP Gb 10G SFP+, 10G BASE-T, 40G QSFP+ L2 FlexFabric Switch G-4XG-2QSFP JC894A : 1,350,000 () XG-2QSFP JC896A : 1,980,000 () XGT-8XG-2QSFP JC898A : 2,300,000 () 1 JG896A, JG898A 2 JG894A 1G x48 10G x4 40G x2 10G x40 (SFP+) 40G x2 10G x32 (10G-T) 10G x8 (SFP+) 40G x2 9HP 5700 HP 960G bps 1 336G bps 2 714M pps 1 250M pps 2 TRILL, EVB, VEPA 33 Copyright 2015Hewlett-Packard Development Company, L.P. The information contained herein is subject to change without notice

18 HP 5900CP Converged Switch 1U 10G Ethernet 10G FCoE 8G FCConverged Port 48 LAN SAN HP 5900CP-48XG-4QSFP+ Switch 16Gb FC/10GbE 100m Converged SFP+ 1.28T bps 9HP () TRILL, SPB, FCoE, DCB, OpenFlow 1.3 Converged SFP+ 10G Eth/FCoE, 4/8G FC 34 Copyright 2015Hewlett-Packard Development Company, L.P. The information contained herein is subject to change without notice. HP VAN SDN SDN SDN Business Applications 3 rd party application OpenStack virtual cloud UC &C application Northbound API (RESTful APIs) HP VAN SDN Controller Network Control Applications Partner Dev application VAN SDN Controllerxx Native APIs (Java APIs) SDN Protocols Southbound API 1.0 / 1.3 Network Virtualization Flow based traffic eng ü ü REST / JAVA API ü ü ü / / 35 Copyright 2015Hewlett-Packard ett-packard Development Company, L.P. The information contained herein is subject to change without notice
