Daewoo Technopark A-403, Dodang-dong, Wonmi-gu, Bucheon-city, Gyeonggido, Korea LM-80 Test Report
|
|
- Σελήνη Αντωνοπούλου
- 6 χρόνια πριν
- Προβολές:
Transcript
1 LM-80 Test Report Approved Method: Measuring Lumen Maintenance of LED Light Sources Project Number: KILT1212-U00216 Date: September 17 th, 2013 Requested by: Dongbu LED Co., Ltd 90-1, Bongmyeong-Ri, Namsa-Myeon, Cheoin-Gu, Yongin-City, Gyeonggi-Do, Korea MODEL NAME: AT532LWPNE - Test Summary - Data Set Case Temp. (Ts) Ambient Temp. (Ta) Drive Current (If) Relative Humidity Average Lumen Maintenance at 6,000 hours Average Chromaticity Shift( u v ) at 6,000 hours mA 12.5% 100.5% mA 9.2% 97.1% mA 5.6% 85.4% September 17 th, 2013 KILT Page 1 of 11
2 1. Number of LED light sources tested - 25 Packages tested at actual case temperature Packages tested at actual case temperature Packages tested at actual case temperature 94.8 Samples have been selected to be representative of the overall population being tested. 2. Description of LED light sources - Dongbu LED Package: AT532LWPNE IF = 120 ma CCT(Nominal) = 5000 K - Package Dimension: 5.6 mm X 3.0 mm 3. Description of auxiliary equipment -Temperature controlling chamber for LED package/array/module This chamber consists of the water cooling heat-sink plates to control the case temperature of each device and the power supply required by LM-80 test conditions. - Photometric measurement tester for LED package/array/module This test equipment consists of the integrating sphere in conjunction with the temperature controlling plate and programmable current-source meter. 4. Operating Cycle LED packages are driven with a constant direct current. - Number of units: 25 at 55, 25 at 85 and 25 at 95 - Drive current: 120 ma - Typical Voltage: 3.2 V September 17 th, 2013 KILT Page 2 of 11
3 5. Ambient Conditions including airflow, temperature and relative humidity The minimal airflow is maintained in chamber. The ambient temperature around the LED packages inside chamber is controlled by air flowing and the thermocouple readings are monitored. - Case temperature: controlled to -2 - Surrounding air temperature: controlled to -5 - Relative humidity: <65 RH 6. Case Temperature(Test Point Temperature) LED temperature measurement point is shown in the picture below. Test Point 7. Drive Current of the LED light source during lifetime test See sub-clause 8.1, 8.2, and Lumen Maintenance data and Chromaticity shift reported over the measurement See each table. During the test of luminous flux and chromaticity, ambient temperature was set to 25 ±2. September 17 th, 2013 KILT Page 3 of 11
4 8.1. Temperature Data set 1: 55 - Drive Current :120mA - Measurement Current :120mA Φv VF Hour [lm] [V] Lumen Maintenance [%] 0 h (Initial) 0h 1000 h 2000 h 3000 h 4000 h 5000 h 6000 h Ave Med σ Min Max September 17 th, 2013 KILT Page 4 of 11
5 Hour CCT Chromaticity Shift u v [K] 0h 1000 h 2000 h 3000 h 4000 h 5000 h 6000 h Ave Med σ Min Max September 17 th, 2013 KILT Page 5 of 11
6 8.2. Temperature Data set 2: 85 - Drive Current :120mA - Measurement Current :120mA Φv VF Hour [lm] [V] Lumen Maintenance [%] 0 h (Initial) 0h 1000 h 2000 h 3000 h 4000 h 5000 h 6000 h Ave Med σ Min Max September 17 th, 2013 KILT Page 6 of 11
7 Hour CCT Chromaticity Shift u v [K] 0h 1000 h 2000 h 3000 h 4000 h 5000 h 6000 h Ave Med σ Min Max September 17 th, 2013 KILT Page 7 of 11
8 8.3. Temperature Data set 3: 95 - Drive Current :120mA - Measurement Current :120mA Φv VF Hour [lm] [V] Lumen Maintenance [%] 0 h (Initial) 0h 1000 h 2000 h 3000 h 4000 h 5000 h 6000 h Ave Med σ Min Max September 17 th, 2013 KILT Page 8 of 11
9 Hour CCT Chromaticity Shift u v [K] 0h 1000 h 2000 h 3000 h 4000 h 5000 h 6000 h Ave Med σ Min Max September 17 th, 2013 KILT Page 9 of 11
10 9. TM Report : Projecting Long Term Lumen Maintenance of LED Light Source - Calculator results have been validated by NIST Table 1: Report at each LM-80 Test Condition Description of LED Light - Manufacturer : Dongbu LED Co., Ltd Source Tested (manufacturer, model, - Model : AT532LWPNE catalog number) Test Condition ⁰C Case Temp Test Condition ⁰C Case Temp Test Condition ⁰C Case Temp Sample size 25 Sample size 25 Sample size 25 Number of failures 0 Number of failures 0 Number of failures 0 DUT drive current used in the test (ma) Test duration Test duration used for projection (hour to hour) Tested case temperature (⁰C) 120 DUT drive current used in the test (ma) 120 DUT drive current used in the test (ma) 6,000 Test duration 6,000 Test duration 6,000 1,000-6, Test duration used for projection (hour to hour) Tested case temperature (⁰C) 1,000-6, Test duration used for projection (hour to hour) Tested case temperature (⁰C) 120 1,000-6,000 α 2.734E-06 α 1.048E-05 α 3.930E-05 B B B Calculated L70(0k) Reported L70(0k) 141,000 >36000 Calculated L70(0k) Reported L70(0k) 38,000 >36000 Calculated L70(0k) Reported L70(0k) ,000 12, Observation of Failures No optical, electrical or mechanical failure of any LED Package was seen during the lifetime testing. 11. LED Light source monitoring interval Measurements have been taken after the following durations: Tc = , 1000, 2000, 3000, 4000, 5000 and 6000 hours Tc = , 1000, 2000, 3000, 4000, 5000 and 6000 hours Tc = , 1000, 2000, 3000, 4000, 5000 and 6000 hours September 17 th, 2013 KILT Page 10 of 11
11 12. Photometric Measurement Uncertainty The testers are calibrated monthly and the calibration data ensures ±2% uncertainty of measurement. Prepared By: Reviewed By: Jungsu Kim Principal Engineer SangkyooJeon Technical Manager September 17 th, 2013 KILT Page 11 of 11
IES LM Report. Form. No. GLW-0001-F / 21 P.2 P.2 P.3 P.5 P.6 P.7
IES LM-80-08 Report ~ Copy ~ Description of LED Light Sources Tested Applicable Product Series IES LM-80-08 Report Requirement IES TM-21-11 Prediction IES LM-80-08 Test Summary IES LM-80-08 Test Result
