4 Table of Contents Table of Contents 01 Alphanumeric Index 03 Products & Solutions 19 Flash LED 31 Flash LED_2016 Package...32 Flash LED_1610 Package...33 Flash LED_Module Type...33 Flash LED_CSP Type...35 SMD LED 37 Chip LED_Top View...40 Chip LED_Top View_Reverse Mount...46 Chip LED _Top View _Dome Lens...47 Chip LED _Top View_Inner Lens...49 Chip LED_Top View_Dual Color...50 Chip LED_Top View_Reverse Mount Dual Color...53 Chip LED_Top View_Multi Color...54 Chip LED_Side View...58 Chip LED_Side View with Reflector...60 Chip LED_Side View_Dual Color...61 Chip LED_Side View_Multi Color...62 PLCC_Top View...65 PLCC_Top View_Dual Color...71 PLCC_Top View_Multi Color...72 PLCC_Side View...76 PLCC_Side View_Dual Color...79 PLCC_Side View_Multi Color...80 Through Hole Lamp 82 3mm mm_Dual Color mm mm mm_Dual Color mm_0.5W...88 RGB Lamp...89 Circuit Board Indicator (CBI)_Single Level...89 Circuit Board Indicator (CBI)_Bi-Level...92 Circuit Board Indicator (CBI)_Tri-Level...94 Circuit Board Indicator (CBI)_Quad-Level...94 Circuit Board Indicator (CBI)_Quin-Level...95 Circuit Board Indicator (CBI)_PIP...95 Circuit Board Indicators (CBI) with SMD LED...97 LED Display 99 Numeric Display_Single Digit Numeric Display_Dual Digits Numeric Display_Triple Digits Numeric Display_Quadruple Digits Numeric Display_Quintuple Digits Numeric Display_SMD Type Alphanumeric Display Alphanumeric Display_SMD Type Dot Matrix_5X7 Single Color Dot Matrix_5X8 Single Color Dot Matrix_8X8 Single Color Dot Matrix_8X8 Multi Color Dot Matrix_16X16 Single Color Light Bar Array LED Display Module LED Catalog

5 Automotive LED 160 Optical Sensors 225 Interior_Chip LED, PLCC Interior_Side LED Interior_Multi Color 3-in-1 LED Interior/Exterior_PLCC4/6 LED Exterior_Through Hole Lamp Exterior_High Power LED Exterior_High Intensity Chip Array Signage LED 171 Chip LED Single Color Chip LED Multi Color Chip LED Multi Color (IC Embedded) PLCC Single Color PLCC Multi Color Through Hole Lamp_3mm Through Hole Lamp_4mm Through Hole Lamp_5mm Through Hole Lamp_5mm_Dual Color Lighting LED 184 Middle Power High Power Ceramic COB MCPCB COB Ambient Light Sensor RGB Color Sensor UV Sensor Proximity Sensor in-1 Integrated Sensor in-1 Integrated Sensor in-1 Integrated Sensor Gesture Integrated Sensor Heart Rate Monitoring Sensor Reflective Sensor Transmissive Sensor_Slotted Type Transmissive Sensor_Actuator Type Photocoupler 246 General Purpose Phototransistor Photocoupler Darlington Transistor Output Photocoupler Triac Output Photocoupler MBd Transistor Output photocoupler MBd Logic Gate/ 15MBd CMOS Photocoupler kBd Darlington Output Photocoupler Integrated Gate Drive Photocoupler Schmitt Trigger Intelligent Power Module Interface Photocoupler UV LED 263 Infrared Emitter and Detector 197 UV LED IR Emitter_3mm Through Hole Type IR Emitter_5mm Through Hole Type IR Emitter_Side Look IR Emitter_SMD Side View IR Emitter_SMD Type IR Emitter_SMD Bowl Type IR Emitter_High Power SMD IR Emitter_SMD Type Photodiode_5mm Through Hole Type Photodiode_Side Look Photodiode_SMD Side Look Photodiode_SMD Type Phototransistors_3mm Through Hole Type Phototransistors_Side Look Phototransistors_SMD Type Photolink_Transmitter Infrared Transceiver Worldwide Contacts 266 REPRESENTATIVES AND DISTRIBUTORS ASIA / PACIFIC EMEA Americas Branch Offices

6 Alphanumeric Index

7 Alphanumeric Index 4N N N N N N N135-H N135-L N136-H N136-L N137-L N138-L N139-L CNY CNY CNY CNY CNY17F CNY17F CNY17F CNY17F H11L1-L H11L2-L H11L3-L HSDL HSDL HSDL HSDL-3208-S LTA-1000KD LTA-1000KF LTA-1000KG LTA-1000KR LTA-1000KS LTC-26C7KD LTC-46D2SW LTC-46F6CKD-P LTC-46F6CKF-P LTC-46F6CKG-P LTC-46F6CKR-P LTC-46F6CKS-P LTC-46F6TB-P LTC-57C7KD LTC-57C7KF LTC-57C7KG LTC-57C7KR LTC-57C7KS LTC-561JD LTC-561JG LTC-561KF LTC-561KR LTC-561KS LTC-561TB LTC-571JD LTC-571JG LTC-571KF LTC-571KR LTC-571KS LTC-571TB LTC-2621JD LTC-2621JG LTC-2621JR LTC-2621KF LTC-2621KS LTC-2621TB LTC-2623JD LTC-2623JF LTC-2623JG LTC-2623JR LTC-2623JS LTC-2623TB LTC-2650JG LTC-2650KD LTC-2650KF LTC-2650KR LTC-2650KS LTC-2650TBE LTC-2721JD LTC-2721JG LTC-2721JR LTC-2721KF LTC-2721KS LTC-2721TB LTC-2723JD LTC-2723JF LTC-2723JG LTC-2723JR LTC-2723JS LTC-2723TB LTC-2750JG LTC-2750KD LTC-2750KF LTC-2750KR LTC-2750KS LTC-2750TBE LTC-3710KD LTC-3710KG LTC-3718KD LTC-3718KG LTC-4624JD LTC-4624JG LTC-4624JR LTC-4624KF LTC-4624KS LTC-4624TB LTC-4627JD LTC-4627JF LTC-4627JG LTC-4627JR LTC-4627JS LTC-4627TB LTC-4724JD LTC-4724JG LTC-4724JR LTC-4724KF LTC-4724KS LTC-4724TB LTC-4727JD LTC-4727JF LTC-4727JG LTC-4727JR LTC-4727JS LTC-4727TB

8 Alphanumeric Index LTC-5623JD LTC-5623JG LTC-5623KF LTC-5623KR LTC-5623KS LTC-5623TB LTC-5653KD LTC-5653KF LTC-5653KG LTC-5653KR LTC-5653KS LTC-5653TB LTC-5723JD LTC-5723JG LTC-5723KF LTC-5723KR LTC-5723KS LTC-5723TB LTC-5753KD LTC-5753KF LTC-5753KG LTC-5753KR LTC-5753KS LTC-5753TB LTC-7500KD LTC-7500KF LTC-7500KG LTC-7500KR LTC-7500KS LTD-322JD LTD-322JG LTD-322KF LTD-322KR LTD-322KS LTD-322TB LTD-323JD LTD-323JG LTD-323KF LTD-323KR LTD-323KS LTD-323TB LTD-2404CKD-P LTD-2404CKF-P LTD-2404CKG-P LTD-2404CKR-P LTD-2404CKS-P LTD-2404SW-P LTD-2601JD LTD-2601JG LTD-2601KF LTD-2601KR LTD-2601KS LTD-2601TB LTD-2701JD LTD-2701JG LTD-2701KF LTD-2701KR LTD-2701KS LTD-2701TB LTD-4516CKD-PM LTD-4516CKF-PM LTD-4516CKG-PM LTD-4516CKR-PM LTD-4516CKS-PM LTD-4516TBE-PM LTD-4608JD LTD-4608JG LTD-4608JS LTD-4608KF LTD-4608KR LTD-4608TB LTD-4708JD LTD-4708JG LTD-4708JS LTD-4708KF LTD-4708KR LTD-4708TB LTD-5021AJD LTD-5021TB LTD-5023AJD LTD-5023TB LTD-5250JD LTD-5250KF LTD-5250KG LTD-5250KR LTD-5250KS LTD-5250TB LTD-5260KD LTD-5260KF LTD-5260KG LTD-5260KR LTD-5260KS LTD-5260TB LTD-5435CKD-P LTD-5435CKF-P LTD-5435CKG-P LTD-5435CKR-P LTD-5435CKS-P LTD-5435TBE-P LTD-5521AJR LTD-5523AJR LTD-5621AJG LTD-5623AJG LTD-5721AJS LTD-5721AKF LTD-5723AJS LTD-5723AKF LTD-6410KD LTD-6410KF LTD-6410KG LTD-6410KR LTD-6410KS LTD-6410TB LTD-6610KD LTD-6610KF LTD-6610KG LTD-6610KR LTD-6610KS LTD-6610TB LTD-8302KD LTD-8302KF LTD-8302KG LTD-8302KR LED Catalog

9 LTD-8302KS LTD-8302TB LTD-8802KD LTD-8802KF LTD-8802KG LTD-8802KR LTD-8802KS LTD-8802TB LTDL-RA16A LTDL-RA25A LTDL-TA16A LTDL-TA25A LTDL-TA25B LTE-7F70L LTE-14H0B LTE-3271B LTE-3271BL LTE-3273DL LTE-3273L LTE LTE-3279K LTE-3370L LTE-3371T LTE LTE LTE LTE LTE-4206C LTE LTE LTE-4238R LTE-R38386-SE LTE-R38386S-S LTE-R38386S-ZF LTE-R38386-ZF LTE-R38386-ZFE LTE-R38389S-S LTE-R38831S-S LTE-S LTE-S LTE-S9511-E LTE-S9511TS LTE-S9711-J LTF-2505KD LTF-2505KF LTF-2505KG LTF-2505KR LTF-2505KS LTE-16H0B LTE-16K3L LTE-18G3N LTE-18H0B LTE-5228A LTE-7377L LTE-C195IRG LTF-2606KD LTF-2606KF LTF-2606KG LTF-2606KR LTF-2606KS LTE-32B0L LTE-32B3L LTE-32F0L LTE LTE LTE LTE LTE LTE-C211-X LTE-C216-P LTE-C216R LTE-C LTE-C LTE-C LTE-C LTE-C1901-ZF LTE-C1906R LTH LTH LTH LTH LTH LTH P LTH LTH W LTH-301A LTE LTE-2872U LTE-3070L LTE-3220L LTE-3223L LTE LTE-C LTE-C LTE-C9306R LTE-C9501-E-T LTE-C9506B LTE-C LTE-R38381-S LTE-R38386-S LTH LTH LTH LTH W LTH P LTH LTH P LTH P LTH

10 Alphanumeric Index LTH LTH LTH LTL1BEKVJNN...86 LTL1BESTBKJH185P...91 LTL1BETBEK5H LTL1BETBEK5-HF...86 LTL1BETBYJR LTL1CHKEKNN...83 LTL1CHKFKNN...83 LTL1CHKGKNN...83 LTL1CHKSKNN...83 LTL1CHTBK LTL1CHTGK LTL2R3TCY3JS LTL2R3TGY3KS LTL2R3YW3KS LTL2T3TBK LTL2T3TGK LTL2V3EUJS LTL2V3EY3KS LTL3H3EPADS LTL3H3TBNADS LTL3H3TGTADS LTL4HMEPADS LTL4HMWSDS-A LTL4HMYSADS LTL4VMYS5D LTL17KTBS3KS LTL17KTGX3KS...84 LTL17KTGX3KS LTL30EGCBKJ...88 LTL30EJ9NN...88 LTL30EKDFGJ...88 LTL30SETG3J LTL-42M3NHKP...94 LTL-42M4NH LTL-42NEW8DHBP LTL-42NGY8D2H LTL42NKFKNN...85 LTL42NKGKNN...85 LTL42NKRKNN...85 LTL42NKSKNN...85 LTL1NHEG6D...83 LTL1NHGB4D...83 LTL1NHSJ4D...83 LTL1NHTBH4J...83 LTL1NHTGT4TZ...83 LTL1SHER3D LTL1SHEW3KS LTL1SHTBN3DP LTL1SHTGV3DP LTL1SHYW3KS LTL2H3E11K LTL2H3TC21K LTL2H3Y11K LTL2P3EX2K LTL2P3TCY2K LTL2P3YX2K LTL2R3FU3JSR LTL2R3KFK...87 LTL2R3KG...87 LTL2R3KRK...87 LTL2R3KSK...87 LTL5H3TBDS LTL5H3TGDS LTL5H3TRDS LTL5L3ES7D LTL5L3TGV7D LTL5L3YU7DS LTL-14CDJNH LTL-14CM1H LTL-14CM01H LTL17HGL4T...87 LTL17KCBH5D...84 LTL17KCGP4J...84 LTL17KET3KS...84 LTL17KET3KS LTL17KFL5D...84 LTL17KGH5D...84 LTL17KRH5D...84 LTL17KRL6D...84 LTL17KSL5D...84 LTL17KTBS3KS...84 LTL42TB6N...85 LTL42TG6N...85 LTL42TG6NH LTL67HGEJ...85 LTL750RGBHBJ...89 LTL-2300HR LTL-2400Y LTL-2500G LTL-2620M LTL-2655HR LTL-2655JD LTL-2720Y LTL-2755Y LTL-2800G LTL-2820G LTL-2855G LTL-4201M LTLA2H3VYY1K LTLA2R3EW3K LTLA2R3YW3K LED Catalog

11 LTLA916VAJ2K LTLA916VYJ2K LTLA918VEJ3K LTLA918VYJ3K LTL-M12RG1H300Q...97 LTL-M12YG1H300Q...98 LTL-R42M12NH LTL-R42NGYAD2H LTL-R42NGYADH LTM-0735G LTM-0735SW LTM-1008M LTM-1302SM LTM-1524KS LTP-158FFKF LTP-159FFKF LTP-185FFMKD-J LTP-229FFKF LTP-537KD LTP-537KF LTP-537KG LTP-537KR LTP-537KS LTP-587KD LTP-587KF LTP-587KG LTP-587KR LTP-587KS LTP-747KD LTP-747KF LTP-747KG LTP-747KR LTP-747KS LTP-757KD LTP-757KF LTP-757KG LTP-757KR LTP-757KS LTP-1457KD LTP-1457KF LTP-1457KG LTP-1457KR LTP-1457KS LTP-1557KD LTP-1557KF LTP-1557KG LTP-1557KR LTP-1557KS LTP-1557TBE LTP-2057AKA LTP-2057AKR LTP-2057AKY LTP-2058AKD LTP-2058AKF LTP-2058AKG LTP-2058AKR LTP-2058AKS LTP-2157AKA LTP-2157AKR LTP-2157AKY LTP-2158AKD LTP-2158AKF LTP-2158AKG LTP-2158AKR LTP-2158AKS LTP-3362JD LTP-3362JF LTP-3362JG LTP-3362JR LTP-3362JS LTP-3363CKD-P LTP-3363CKF-P LTP-3363CKG-P LTP-3363CKR-P LTP-3363CKS-P LTP-3784JG LTP-3784KD LTP-3784KF LTP-3784KR LTP-3784KS LTP-3786JG LTP-3786KD LTP-3786KF LTP-3786KR LTP-3786KS LTP-3862JD LTP-3862JF LTP-3862JG LTP-3862JR LTP-3862JS LTP-4323JD LTP-4323JG LTP-4323KF LTP-4323KR LTP-4323KS LTP-4823JD LTP-4823JG LTP-4823KF LTP-4823KR LTP-4823KS LTP-4824CKD-P LTP-4824CKF-P LTP-4824CKG-P LTP-4824CKR-P LTP-4824CKS-P LTP-7188KD LTP-7188KF LTP-7188KG LTP-7188KR LTP-7188KS LTP-7488SF LTP-7588SF LTP-12788KD

12 Alphanumeric Index LTP-12788KF LTP-12788KG LTP-12788KR LTP-12788KS LTP-14058AKD LTP-14058AKF LTP-14058AKG LTP-14058AKR LTP-14058AKS LTP-14158AKD LTP-14158AKF LTP-14158AKG LTP-14158AKR LTP-14158AKS LTP-18088KD LTP-18088KF LTP-18088KG LTP-18088KR LTP-18088KS LTPA-C35NUAWP LTPA-C35NUBBPPA LTPA-C LTPA-C3535ANPTB LTPA-C3535AWP LTPA-C3535BBPPA LTPA-C3535BWP LTPA-C3535CNPKE LTPA-C3535CNPTG LTPA-H2S LTPA-H3S LTPA-H4S LTPA-H5S LTPA-P35PUCBPPA LTPA-P35PUCWP LTPA-P35PUDNPKE LTPA-P3030ANPTB LTPA-P3030CBPPA LTPA-P3030CNPKE LTPA-P3030CNPTG LTPA-P3030CWP LTPA-P3535CBPPA LTPA-P3535CWP LTPA-S38FUMBPPA LTPA-S38FUMWE LTPL-A133DWARB...35 LTPL-A136DWAYB...35 LTPL-A155DWFWB...36 LTPL-A157DWFYB...36 LTPL-C08EAS LTPL-C08ECT LTPL-C08ERS LTPL-C08UVH LTPL-C08UVH LTPL-C08UVH LTPL-C08UVH LTPL-C08UVH LTPL-C16FBD LTPL-C16FGH LTPL-C16FRD LTPL-C16FRD LTPL-C16FRM LTPL-C16FUVH LTPL-C16FUVM LTPL-C16FUVM LTPL-C16FUVM LTPL-C16FUVM LTPL-C16FUVM LTPL-C034AH LTPL-C034DH LTPL-C034OH LTPL-C034UVD LTPL-C034UVD LTPL-C034UVD LTPL-C034UVD LTPL-C034UVD LTPL-C034UVH LTPL-C034UVH LTPL-C034UVH LTPL-C034UVH LTPL-C034UVH LTPL-C034UVH LTPL-C035BH LTPL-C035BH LTPL-C035GH LTPL-C035GH LTPL-C035RH LTPL-C035RH LTPL-C035RH LTPL-C035RN LTPL-C095WPGE...33 LTPL-C095WPRB...33 LTPL-C095WPYB...33 LTPL-C0673WPYB...32 LTPL-C0675WPGB...32 LTPL-C0675WPRB...32 LTPL-C0675WPYB...32 LTPL-C0677WPGB...32 LTPL-C0677WPHB...32 LTPL-C0677WPRB...32 LTPL-C0677WPYB...32 LTPL-C0678WPYB...32 LTPL-C0685WCGB...33 LTPL-C0695DAYD...34 LTPL-M03614ZS27-T LTPL-M03614ZS30-T LTPL-M03614ZS40-T LTPL-M03622ZS30-T LTPL-M03622ZS30-T LTPL-M03622ZS30-T LTPL-M04520QS30-T LTPL-M04520ZS27-T LTPL-M04520ZS30-T LTPL-M04520ZS40-T LTPL-M04530QS30-T LED Catalog

13 LTPL-M04530ZS27-T LTPL-M04530ZS30-T LTPL-M04530ZS40-T LTPL-M07452ZS30-T LTPL-M07452ZS57-T LTPL-M07452ZS65-T LTPL-M07480ZS30-T LTPL-M07480ZS57-T LTPL-M07480ZS65-T LTPL-M08206QS30-T LTPL-M08206ZS27-T LTPL-M08206ZS30-T LTPL-M08206ZS40-T LTPL-M08210QS30-T LTPL-M08210ZS27-T LTPL-M08210ZS30-T LTPL-M08210ZS40-T LTPL-M08218QS30-T LTPL-M08218ZS27-T LTPL-M08218ZS30-T LTPL-M08218ZS40-T LTPL-M09825QS30-T LTPL-M09825ZS30-T LTPL-M09825ZS40-T LTPL-M09825ZS50-F LTPL-M09830QS30-T LTPL-M09830ZS30-T LTPL-M09830ZS40-T LTPL-M09830ZS50-F LTPL-M13706ZS27-T LTPL-M13706ZS30-T LTPL-M13706ZS40-T LTPL-M13706ZS50-F LTPL-M13710ZS27-T LTPL-M13710ZS30-T LTPL-M13710ZS40-T LTPL-M13710ZS50-F LTPL-M13712ZS27-T LTPL-M13712ZS30-T LTPL-M13712ZS40-T LTPL-M13712ZS50-F LTPL-P033BS LTPL-P033BS LTPL-P033BS LTPL-P033RGB...75 LTR LTR-209H LTR LTR-303ALS LTR LTR-308ALS LTR LTR-323DB LTR-329ALS LTR-380RGB LTR-390UV LTR-507ALS LTR-516AB LTR-516AD LTR-526AD LTR-536AD LTR-546AB LTR-546AD LTR-559ALS LTR-578ALS LTR-579ALS LTR-580RGB LTR-588RGB LTR-590UV LTR-659PS LTR-676PS LTR-733DBM1-TA LTR-778ALS LTR-800HR LTR-801HR LTR-806HR LTR-810HR LTR-820HR LTR-1650D LTR LTR-3208E LTR LTR-4206E LTR-5576D LTR-5579DP LTR-5888DH LTR-5986H LTR LTR-C155-DB LTR-C155-DC LTR-C950-DB LTR-C950-TB-T LTR-C LTR-C LTR-C5510-DC LTR-C5511-DB LTR-C9303B LTR-S320-DB-L LTR-S320-TB LTR-S951-TB LTR-S971-TB LTS-360KD LTS-360KF LTS-360KG LTS-360KR LTS-360KS LTS-367KD LTS-367KF LTS-367KG LTS-367KR LTS-367KS

14 Alphanumeric Index LTS-546AJD LTS-546AJG LTS-546AKF LTS-546AKR LTS-546AKS LTS-546TB LTS-547AJD LTS-547AJG LTS-547AJR LTS-547AKF LTS-547AKS LTS-547TB LTS-2301AJD LTS-2301AJR LTS-2301AKF LTS-2301AKG LTS-2301AKS LTS-2301ATB LTS-2306CKD-P LTS-2306CKF-P LTS-2306CKG-P LTS-2306CKR-P LTS-2306CKS-P LTS-2306TBE-P LTS-2307CKD-P LTS-2307CKF-P LTS-2307CKG-P LTS-2307CKR-P LTS-2307CKS-P LTS-2307TBE-P LTS-2801AJD LTS-2801AJR LTS-2801AKF LTS-2801AKG LTS-2801AKS LTS-2801ATB LTS-2806CKD-P LTS-2806CKF-P LTS-2806CKG-P LTS-2806CKR-P LTS-2806CKS-P LTS-2806TBE-P LTS-2807CKD-P LTS-2807CKF-P LTS-2807CKG-P LTS-2807CKR-P LTS-2807CKS-P LTS-2807TBE-P LTS-3361JD LTS-3361JF LTS-3361JG LTS-3361JR LTS-3361JS LTS-3361TB LTS-3385KD LTS-3385KF LTS-3385KG LTS-3385KR LTS-3385KS LTS-3385TBE LTS-3386CKD-P LTS-3386CKF-P LTS-3386CKG-P LTS-3386CKR-P LTS-3386CKS-P LTS-3386CTB-P LTS-3861JD LTS-3861JF LTS-3861JG LTS-3861JR LTS-3861JS LTS-3861TB LTS-3885KD LTS-3885KF LTS-3885KG LTS-3885KR LTS-3885KS LTS-3885TBE LTS-3886CKD-P LTS-3886CKF-P LTS-3886CKG-P LTS-3886CKR-P LTS-3886CKS-P LTS-3886CTB-P LTS-4301JD LTS-4301JF LTS-4301JG LTS-4301JR LTS-4301JS LTS-4301TB LTS-4312CKD-PM LTS-4312CKF-PM LTS-4312CKG-PM LTS-4312CKR-PM LTS-4312CKS-PM LTS-4312TBE-PM LTS-4317CKD-P LTS-4317CKF-P LTS-4317CKG-P LTS-4317CKR-P LTS-4317CKS-P LTS-4317TBE-P LTS-4801JD LTS-4801JF LTS-4801JG LTS-4801JR LTS-4801JS LTS-4801TB LTS-4812CKD-PM LTS-4812CKF-PM LTS-4812CKG-PM LTS-4812CKR-PM LTS-4812CKS-PM LTS-4812TBE-PM LTS-4817CKD-P LTS-4817CKF-P LTS-4817CKG-P LTS-4817CKR-P LTS-4817CKS-P LTS-4817TBE-P LED Catalog

15 LTS-5001AJD LTS-5001AJR LTS-5003AJD LTS-5003AJR LTS-5325CKD-P LTS-5325CKF-P LTS-5325CKG-P LTS-5325CKR-P LTS-5325CKS-P LTS-5325TBE-P LTS-5501ATB LTS-5503ATB LTS-5601AJG LTS-5603AJG LTS-5701AJS LTS-5701AKF LTS-5703AJS LTS-5703AKF LTS-5825CKD-P LTS-5825CKF-P LTS-5825CKG-P LTS-5825CKR-P LTS-5825CKS-P LTS-5825TBE-P LTS-10304KD LTS-10304KF LTS-10304KG LTS-10304KR LTS-10304KS LTS-10304TBE LTS-10804KD LTS-10804KF LTS-10804KG LTS-10804KR LTS-10804KS LTS-10804TBE LTS-23305JG LTS-23305KD LTS-23305KF LTS-23305KR LTS-23305KS LTS-23805JG LTS-23805KD LTS-23805KF LTS-23805KR LTS-23805KS LTSA-C150KEKT LTSA-C150KSKT LTSA-C150TBK LTSA-C150TBV LTSA-C150TBW LTSA-C150TGK LTSA-C170KEKT LTSA-C170KSKT LTSA-C170TBKT LTSA-C170TGKT LTSA-C191KEKT LTSA-C191KSKT LTSA-C191TBK LTSA-C191TGK LTSA-E67RVAWT LTSA-E67RVEWT LTSA-E67RVSWT LTSA-E67RZHET LTSA-E67RZWET LTSA-G6SPVAKT LTSA-G6SPVEKT LTSA-G6SPVSKT LTSA-G6SVUAET LTSA-G6SVUWET LTSA-G683ZBEGWU LTSA-M67KKEWT LTSA-M67KKSWT LTSA-M67KTBWT LTSA-M67KTGWT LTSA-M67KTHET LTSA-M67KTWET LTSA-S008RGBWA LTSA-S33GBEGK LTSA-S089ZHET LTSA-S089ZWET LTSA-T680KEWT LTSA-T680KSWT LTSA-T680VEWT LTSA-T680VSWT LTSA-T680ZBWT LTSA-T680ZGWT LTSA-T680ZHET LTSA-T680ZWET LTSA-W150TBA LTSA-W170DBC LTSA-W170ZTBAT-WT LTSA-W191DBS LTSN-B32JEGBB LTSN-B68JEGBB LTSN-C170DS LTSN-C170KSWT LTSN-C191DS LTSN-C191KSKT LTSN-D353EGBW LTSN-E263HEGBK LTSN-E363CEGBW LTSN-H213EGBW LTSN-N211QSWT LTSN-N211UWET LTSN-N211VSWT LTSN-N213EGBW LTST-006BGEW...80 LTST-006GEBW...80 LTST-008BGEW...81 LTST-008EGSW...81 LTST-008GEBW...81 LTST-008TGKEWT...79 LTST-010KFKT...77 LTST-010KGKT

16 Alphanumeric Index LTST-010KRKT...77 LTST-010KSKT...77 LTST-010TBKT...77 LTST-010TGKT...77 LTST-020KFKT...78 LTST-020KGKT...78 LTST-020KRKT...78 LTST-020KSKT...78 LTST-020TBKT...78 LTST-020TGKT...78 LTST-108KFKT...79 LTST-108KGKT...79 LTST-108KRKT...79 LTST-108KSKT...79 LTST-108TBKT...79 LTST-108TGKT...79 LTST-5630UBWT...70 LTST-5630UGWT...70 LTST-5630ULWT...70 LTST-5630VDWT...70 LTST-5630VEWT...70 LTST-5630VSWT...70 LTST-A683BEGW...75 LTST-A683GEBW...75 LTST-B28JEGBB-5A...54 LTST-B680UGKT LTST-B680UWET LTST-B680VEKT LTST-B680VSKT LTST-C19DKFKT...44 LTST-C19DKRKT...44 LTST-C19DKSKT...44 LTST-C19DTGKT...44 LTST-C19FD1WT...57 LTST-C19GD2WT...57 LTST-C19HE1WT...55 LTST-C19HRGYW...55 LTST-C19JZEGB1W-5A...56 LTST-C19KBEGK-5A...55 LTST-C19MGEBK-5A...56 LTST-C21KFKT...49 LTST-C21KGKT...49 LTST-C21KRKT...49 LTST-C21KSKT...49 LTST-C21TBKT...49 LTST-C21TGKT...49 LTST-C28NBEGK-2A...54 LTST-C150KFKT...45 LTST-C150KGKT...45 LTST-C150KRKT...45 LTST-C150KSKT...45 LTST-C150TBKT...45 LTST-C150TGKT...45 LTST-C155KGJRKT...52 LTST-C155KGKFKT...52 LTST-C155TBJRKT...52 LTST-C170KFKT...45 LTST-C170KGKT...45 LTST-C170KRKT...45 LTST-C170KSKT...45 LTST-C170TBKT...45 LTST-C170TGKT...45 LTST-C171KFKT...44 LTST-C171KGKT...44 LTST-C171KRKT...44 LTST-C171KSKT...44 LTST-C171TBKT...44 LTST-C171TGKT...44 LTST-C190KFKT...43 LTST-C190KGKT...43 LTST-C190KRKT...43 LTST-C190KSKT...43 LTST-C190TBKT...43 LTST-C190TGKT...43 LTST-C191KFKT...43 LTST-C191KGKT...43 LTST-C191KRKT...43 LTST-C191KSKT...43 LTST-C191TBKT...43 LTST-C191TGKT...43 LTST-C193KFKT-5A...42 LTST-C193KGKT-5A...42 LTST-C193KRKT-5A...42 LTST-C193KSKT-5A...42 LTST-C193TBKT-5A...42 LTST-C193TGKT-5A...42 LTST-C194KFKT...42 LTST-C194KGKT...42 LTST-C194KRKT...42 LTST-C194KSKT...42 LTST-C194TBKT...42 LTST-C194TGKT...42 LTST-C195KGJRKT...51 LTST-C195KGKFKT...51 LTST-C195TBJRKT...51 LTST-C197KGKEKT...52 LTST-C197KGKSKT...52 LTST-C197TGKEKT...52 LTST-C198KFKT...41 LTST-C198KGKT...41 LTST-C198KRKT...41 LTST-C198KSKT...41 LTST-C198TBKT...41 LTST-C198TGKT...41 LTST-C216KFKT...49 LTST-C216KGKT...49 LTST-C216KRKT...49 LTST-C216KSKT...49 LTST-C216TBKT...49 LTST-C216TGKT...49 LTST-C230KFKT...47 LTST-C230KGKT...47 LTST-C230KRKT...47 LTST-C230KSKT...47 LTST-C230TBKT LED Catalog

17 LTST-C230TGKT...47 LTST-C231KFKT...46 LTST-C231KGKT...46 LTST-C231KRKT...46 LTST-C231KSKT...46 LTST-C231TBKT...46 LTST-C231TGKT...46 LTST-C235KGKRKT...53 LTST-C235KGKSKT...53 LTST-C235TBJRKT...53 LTST-C250KFKT...46 LTST-C250KGKT...46 LTST-C250KRKT...46 LTST-C250KSKT...46 LTST-C250TBKT...46 LTST-C250TGKT...46 LTST-C255TBKFWT-5A...53 LTST-C281KFKT-5A...41 LTST-C281KGKT-5A...41 LTST-C281KRKT-5A...41 LTST-C281KSKT-5A...41 LTST-C281TBKT-5A...41 LTST-C281TGKT-5A...41 LTST-C283KFKT-5A...40 LTST-C283KGKT-5A...40 LTST-C283KRKT-5A...40 LTST-C283KSKT-5A...40 LTST-C283TBKT-5A...40 LTST-C283TGKT-5A...40 LTST-C285KGKFWT-5A...50 LTST-C285TBKEWT-5A...50 LTST-C285TGKFWT-5A...50 LTST-C295KGKFKT...50 LTST-C295KGKRKT...50 LTST-C295TBKFKT...50 LTST-C371JBKT...40 LTST-C371JGKT...40 LTST-C371KFKT...40 LTST-C371KGKT...40 LTST-C371KRKT...40 LTST-C371KSKT...40 LTST-C395KGKFKT...51 LTST-C395KGKRKT...51 LTST-C395TBKFKT...51 LTST-C0610UBWT...65 LTST-C0610UGWT...65 LTST-C0610VEWT...65 LTST-C0610VSWT...65 LTST-C0610ZWET...65 LTST-C930KFKT...48 LTST-C930KGKT...48 LTST-C930KRKT...48 LTST-C930KSKT...48 LTST-C930TBKT...48 LTST-C930TGKT...48 LTST-C950KFKT...48 LTST-C950KGKT...48 LTST-C950KRKT...48 LTST-C950KSKT...48 LTST-C950TBKT...48 LTST-C950TGKT...48 LTST-C990KFKT...47 LTST-C990KGKT...47 LTST-C990KRKT...47 LTST-C990KSKT...47 LTST-C990TBKT...47 LTST-C990TGKT...47 LTST-E680UBWT...70 LTST-E680UGWT...70 LTST-E680VEWT...70 LTST-E680VSWT...70 LTST-E682KETBWT...71 LTST-E682KGKFWT...71 LTST-E682KGKSWT...71 LTST-E682KRKGWT...71 LTST-E682TGKRWT...71 LTST-E683EGBW...73 LTST-E683EGSW...73 LTST-E683FGBW...73 LTST-E683RGBW...73 LTST-F680UBET...71 LTST-F680UBWT...71 LTST-F680UGWT...71 LTST-F680VEWT...71 LTST-F680VSWT...71 LTST-G563BBBE...74 LTST-G563DDDW...74 LTST-G563EEEW...74 LTST-G563SSSW...74 LTST-G563ZBBBW...74 LTST-G563ZEGBW...74 LTST-G563ZGGGW...74 LTST-G683ESBW...72 LTST-G683GEBW...72 LTST-G683RGBW...72 LTST-M140KFKT...67 LTST-M140KGKT...67 LTST-M140KRKT...67 LTST-M140KSKT...67 LTST-M140QEKT...67 LTST-M140QSKT...67 LTST-M140TBKT...67 LTST-M140TGKT...67 LTST-M230UBWT...65 LTST-M230UGWT...65 LTST-M230VEWT...65 LTST-M230VSWT...65 LTST-M230ZWET...65 LTST-M670KFKT...68 LTST-M670KGKT...68 LTST-M670KRKT...68 LTST-M670KSKT...68 LTST-M670TBKT...68 LTST-M670TGKT...68 LTST-S32F1KT

18 Alphanumeric Index LTST-S33FBEGW-5A...62 LTST-S33GBEGK...63 LTST-S43FBEGW...63 LTST-S110KFKT...59 LTST-S110KGKT...59 LTST-S110KRKT...59 LTST-S110KSKT...59 LTST-S110TBKT...59 LTST-S110TGKT...59 LTST-S115KGJRKT...61 LTST-S115KGKFKT...61 LTST-S115TGKFKT...61 LTST-S220KFKT...59 LTST-S220KGKT...59 LTST-S220KRKT...59 LTST-S220KSKT...59 LTST-S220TBKT...59 LTST-S220TGKT...59 LTST-S270KFKT...58 LTST-S270KGKT...58 LTST-S270KRKT...58 LTST-S270KSKT...58 LTST-S270TBKT...58 LTST-S270TGKT...58 LTST-S310F3WT...64 LTST-S320KFKT...60 LTST-S320KGKT...60 LTST-S320KRKT...60 LTST-S320KSKT...60 LTST-S320TBKT...60 LTST-S320TGKT...60 LTST-S326KGJRKT...61 LTST-S326KGKFKT...61 LTST-S326TBKSKT...61 LTST-S327KGJRKT...62 LTST-S327KGJSKT...62 LTST-S327TBKFKT...62 LTST-S482KFKT-5A...58 LTST-S482KGKT-5A...58 LTST-S482KRKT-5A...58 LTST-S482KSKT-5A...58 LTST-S482TBKT-5A...58 LTST-S482TGKT-5A...58 LTST-T680KFWT...69 LTST-T680KGWT...69 LTST-T680KRWT...69 LTST-T680KSWT...69 LTST-T680QEWT...69 LTST-T680QSWT...69 LTST-T680TGWT...69 LTST-T680UBWT...69 LTST-T680UGWT...69 LTST-T680UWET...69 LTST-T680VEWT...69 LTST-T680VSWT...69 LTV-50LP LTV-50LW LTV-053L LTV-60LP LTV-60LW LTV-063L LTV-70LP LTV-70LW LTV-071L LTV-073L LTV-074L LTV LTV-155E LTV LTV LTV LTV LTV LTV LTV LTV LTV LTV LTV LTV LTV LTV LTV-314P LTV-314W LTV-340P LTV-340W LTV-341P LTV-341W LTV-352T LTV-354T LTV-355T LTV-356T LTV-357T LTV-358T LTV LTV-456P LTV-456W LTV LTV-480P LTV-480W LTV LTV-481P LTV-481W LTV LTV LTV LTV-702F LTV-702V LTV-715F LED Catalog

19 LTV-725F LTV-725V LTV LTV LTV LTV LTV LTV LTV LTV LTV LTV LTV LTV LTV LTV LTV LTV LTV LTV LTV LTV LTV LTV LTV LTV LTV LTV LTV LTV LTV LTV LTV LTV LTV LTV LTV LTV LTV LTV LTV LTV LTV LTV LTV LTV LTV LTV-3150-L LTV LTV LTV LTV LTV LTV LTV LTV LTV-M LTV-M LTV-M LTV-M LTV-M LTV-M LTV-T LTW-1BEEDNJZ...86 LTW-1BETBKJLC...86 LTW-1CHDS LTW-1GHCV LTW-1NHDR5JH LTW-1NHDR7JW...83 LTW-1NHDY LTW-2H3D51K...88 LTW-2L3DV LTW-2P3D52K...88 LTW-2R3D43K...88 LTW-2S3D LTW-2S3D8-CY LTW-2V3D13JS LTW-2V3DS LTW-2W3DRA...87 LTW4HMDVAJS LTW4VMDV5JS LTW5H3DVAJS LTW5L3DW7JS LTW-006DCG-E LTW-008RGB2-PH LTW-008ZDCG...79 LTW-010DCG...77 LTW-010DCG-TR...77 LTW-010SCB...77 LTW-010SCG...77 LTW-010SCR...77 LTW-010SCSK...77 LTW-010SCVL...77 LTW-17HDU6J...87 LTW-17HDW5J...87 LTW-17HDY LTW-17KDU4Z...84 LTW-020ZDCG...78 LTW-21TS LTW-42NDH8JH LTW-42NDH8JH LTW-42NDP LTW-42NDP4H LTW-87HD4BSZ...83 LTW-108SEG-W...79 LTW-110TS LTW-150ZDS LTW-170ZDC...45 LTW-198ZDS LTW-206DCG-TM...78 LTW-206DCG-TMS...78 LTW-206KRKT...78 LTW-206VFKT-PX...78 LTW-216TS

20 Alphanumeric Index LTW-270TLA...58 LTW-295DSKS-5A...50 LTW-303DCG-KB...76 LTW-326DSKF-5A...61 LTW-327DSKF-5A...62 LTW-670BS LTW-670DS-EL...69 LTW-670GS LTW-670OS LTW-670RS LTW-670YS LTW-2835AZH LTW-2835AZH LTW-2835AZH LTW-2835AZH LTW-2835AZH LTW-2835AZH LTW-2835AZI LTW-2835AZI LTW-2835AZI LTW-2835AZI LTW-2835AZI LTW-2835AZI LTW-2835AZL LTW-2835AZL LTW-2835AZL LTW-2835AZL LTW-2835AZL LTW-2835AZL LTW-2835SZK LTW-2835SZK LTW-2835SZK LTW-2835SZK LTW-2835SZK LTW-2835SZK LTW-2835TZN LTW-2835TZN LTW-2835TZN LTW-2835TZN LTW-2835TZN LTW-2835TZN LTW-5630AQL LTW-5630AQL LTW-5630AQL LTW-5630AQL LTW-5630AQL LTW-5630AQL LTW-5630AZL27-EUH LTW-5630AZL30-EUH LTW-5630AZL40-EUH LTW-5630AZL50-EUH LTW-5630AZL57-EUH LTW-5630AZL65-EUH LTW-5630SD LTW-5630SD LTW-5630SD LTW-5630SD LTW-5630SD LTW-5630SP LTW-5630SP LTW-5630SP LTW-9301ZDS LTW-9501ZDS LTW-C19DZDS LTW-C190DA LTW-C191TS LTW-C193TS LTW-C194TS LTW-C195DSKS-5A...51 LTW-C230DS...47 LTW-C231DS...46 LTW-C235DSKF-5A...53 LTW-C250DC LTW-C255DCKF-5A...53 LTW-C281DS LTW-C283DS LTW-C285DSKG-5A...50 LTW-C371US LTW-C9301DS LTW-C9501DS LTW-K140BS LTW-K140GS LTW-K140OS LTW-K140RS LTW-K140SCGD...66 LTW-K140SCIB...66 LTW-K140SCSK...66 LTW-K140SCTF...66 LTW-K140SCVL...66 LTW-K140SXR LTW-K140SZR27-EU LTW-K140SZR30-EU LTW-K140SZR40-EU LTW-K140SZR50-EU LTW-K140SZR57-EU LTW-K140SZR65-EU LTW-K140YS LTW-M140ZVS...67 LTW-M670ZVS-M LTW-Q35ZRGB...74 LTW-R4MLDGDJH LTW-S115KFDS-5A...61 LTW-S221DS...59 LTW-S321ZDS LTW-S482DS LTW-S850DC MOC MOC3052-H MOC3052-L MOC MOC LED Catalog

21 Products & Solutions

22 Products & Solutions in Mobile & Wearable Devices Environmental Monitoring UV Detector Health Care Heart Rate Monitor / Pulse oximetry Status Display Indicator UV sensor Health Sensor SMD LED Camera Flash Illumination Entertainment Remote Control Smart Adjusting Detect Object Presence Turn On/Off Screen Screen Brightness/Color Temperature Adjusting Flash LED Infrared LED Proximity Sensor Ambient Light Sensor RGB Sensor Integrated Sensor (PS+ALS+IR) 19 LED Catalog

23 Positioning Position Tracking & Mapping Infrared LED Photodiode SMD LED Convenient Gesture Recognition Security Iris Recognition Gesture Sensor Infrared LED 20

24 Products & Solutions in Smart Home & Appliances Isolation Power Supply Power Management Power Source Isolation Communication Isolation Photocoupler Photocoupler Photocoupler Obstacle Avoidance Object Detecting Smart Switch Touchless Light Switch Program Selecting Detect Color (of Clothes) Infrared Emitter & Detector Proximity Sensor RGB Sensor 21 LED Catalog

25 Status Display Indicator SMD LED LED Display LAMP Isolation Inverter / Motor Control Convenient Remote Control Photocoupler Infrared Emitter 22

26 Products & Solutions in Automotive CHMSL Side Turn Indicator Piranha PLCC 4/6 Top View LED PLCC Top View LED RCL (Rear Combination Light) Light Sensing PLCC 4/6 Top View LED Ambient Light Sensor High Power LED 23 LED Catalog

27 Headlight (High/Low Beam) Daytime Running Light / Front Position 2 to 5 multi-chips array LED High Power LED Single Die High Power LED Decorative/ Ambient Light Dashboard Lights Interior Lighting/ Reading Light Front Fog Light Interior Lighting 2 chips array LED SMD LED Single Die High Power LED MiniTop LED PLCC Side View LED RGB 3-in-1 LED 24

28 Products & Solutions in Industrial Protection Isolation Status Display Status Display Photocoupler SMD LED High Power LED LED Display Safety Guards Object Detecting Infrared Emitter and Detector 25 LED Catalog

29 Isolation Signal Isolation Photocoupler Isolation Inverter / Motor Control Transmission Data Communication Photocoupler Infrared Emitter and Detector 26

30 Products & Solutions in Surveillance & Security Night Vision Assistance Illumination Infrared LED 27 LED Catalog

31 Status Display Indicator Smart Switch Touchless Light Switch SMD LED Proximity Sensor Detection Detecting Particles Security Facial & Iris Recognition IR Emitter & Detector Infrared LED 28

32 Products & Solutions in Signage & Street Lighting Indoor P2.5 Fine Pitch SMD Chip LED SMD LED PLCC 2/4/6 29 LED Catalog

33 Outdoor P12 Pure outdoor Through Hole Lamp High Power White LED 30

34 Flash LED

35 Flash LED_2016 Package Part No. 2.0 x 1.6 x 0.7 mm Correlated color temperature (K) CRI Typ. Luminous Flux Φv (lm) View Angle Typ. Voltage V F (V) Current I F * Thermal Resistance R th (j-s) ( C/W) Peak Pulsed Current I F ** Max. Junction Temperature Tj ( C) Operating Temperature Range ( C) LTPL-C0678WPYB 5000~6000K NCRI ~85 LTPL-C0677WPYB 5000~6000K NCRI ~85 LTPL-C0675WPYB 5000~6000K NCRI ~85 LTPL-C0673WPYB 5000~6000K NCRI ~85 LTPL-C0677WPRB 2000~2500K NCRI ~85 LTPL-C0675WPRB 2000~2500K NCRI ~85 LTPL-C0677WPGB 5000~6000K ~85 LTPL-C0675WPGB 5000~6000K ~85 LTPL-C0677WPHB 5000~6000K ~85 * Electro-optical testing conducted in single pulse mode, TON=300ms, IF=1000mA ** Peak pulsed forward current applies to 50ms:on, 950ms: Off, D: Infrared Emitter and Flash LED SMD LED Through Hole Lamp LED Display Automotive LED Signage LED Lighting LED Optical Sensors Photocoupler UV LED Detector 32

36 Flash LED_1610 Package 1.6 x 1.0 x 0.81 mm Part No. Correlated color temperature (K) Typ. Luminous Flux Φv (lm) View Angle Typ. Voltage V F (V) Current I F * Thermal Resistance R th (j-s) ( C/W) Peak Pulsed Current I F ** Max. Junction Temperature Tj ( C) Operating Temperature Range ( C) LTPL-C095WPGE 4500~ ~85 LTPL-C095WPYB 5000~ ~85 LTPL-C095WPRB 2000~ ~85 * Electro-optical testing conducted in single pulse mode, TON=300ms, IF=1000mA ** Peak pulsed forward current applies to 400ms:on, 3600ms: Off, D: 0.1 Flash LED_Module Type Anode Cathode x 4.0 x 1.4 mm - Part No. Correlated color temperature (K) Typ. Luminous Flux Φv (lm) View Angle Typ. Voltage V F (V) Current I F * Thermal Resistance R th (j-s) ( C/W) Peak Pulsed Current I F ** Max. Junction Temperature Tj ( C) Operating Temperature Range ( C) LTPL-C0685WCGB 4500~6000K / ~85 * Electro-optical testing conducted in single pulse mode, TON=300ms, IF=1000mA ** Peak pulsed forward current applies to 50ms:on, 950ms: Off, D: LED Catalog

37 Flash LED_Module Type Part No. LTPL-C0695DAYD 4.5 x 4.5 x 1.3 mm Correlated color temperature (K) Typ. Luminous Flux Φv (lm) 5000~6000K ~2500K 160 View Angle * Electro-optical testing conducted in single pulse mode, TON=300ms, IF=1000mA ** Peak pulsed forward current applies to 50ms:on, 950ms: Off, D: 0.05 Typ. Voltage V F (V) Current I F * Thermal Resistance R th (j-s) ( C/W) Peak Pulsed Current I F ** Max. Junction Temperature Tj ( C) Operating Temperature Range ( C) ~85 Infrared Emitter and Flash LED SMD LED Through Hole Lamp LED Display Automotive LED Signage LED Lighting LED Optical Sensors Photocoupler UV LED Detector 34

38 + - Flash LED_CSP Type x 1.3 x 0.3 mm Part No. Correlated color temperature (K) Typ. Luminous Flux Φv (lm) View Angle Typ. Voltage V F (V) Current I F * Thermal Resistance R th (j-s) ( C/W) Peak Pulsed Current I F ** Max. Junction Temperature Tj ( C) Operating Temperature Range ( C) LTPL-A136DWAYB 5000~6000K ~85 LTPL-A133DWARB 2000~2500K ~85 * Electro-optical testing conducted in single pulse mode, TON=300ms, IF=1000mA ** Peak pulsed forward current applies to 400ms:on, 3600ms: Off, D: LED Catalog

39 Flash LED_CSP Type Part No. 1.5 x 1.5 x 0.33 mm Correlated color temperature (K) Typ. Luminous Flux Φv (lm) View Angle Typ. Voltage V F (V) Current I F * Thermal Resistance R th (j-s) ( C/W) Peak Pulsed Current I F ** Max. Junction Temperature Tj ( C) Operating Temperature Range ( C) LTPL-A157DWFYB 5000~6000K '-40~85 LTPL-A155DWFWB 2000~2500K '-40~85 * Electro-optical testing conducted in single pulse mode, TON=300ms, IF=1000mA ** Peak pulsed forward current applies to 400ms:on, 3600ms: Off, D: 0.1 Infrared Emitter and Flash LED SMD LED Through Hole Lamp LED Display Automotive LED Signage LED Lighting LED Optical Sensors Photocoupler UV LED Detector 36

40 SMD LED SMD Product Quick View Table Chip LED_Top view Color Single color Product Type General Reverse Mount Dimension (mm) 0.6x x x x x x x x x t 1.85t 1.1t C170 C150 C t 0.85t 0.8t C190 C171 C t C19D 0.7t C t 0.6t 0.55t C t 0.4t 0.35t C371 C281 C t C t C283 C198 I= individual Circuit A=Common Anode C=Common Cathode * Please refer to Signage LED

41 Color Single color Dual Color Multi Color Product Type Dome Lens Inner Lens General Reverse Mount General Dimension (mm) 1.6x x x x x x x x x x x x x x x t C t C t C21 C155 C t C t 0.8t C t 0.7t C t *B68J (A) *B32J (A) 0.6t C t C295 C395 C195 C19F (A) 0.5t B28J (A) C19J C19M (I) 0.4t C19G (A) 0.35t C t 0.2t C28N C19H (A) C19K (I) I= individual Circuit A=Common Anode C=Common Cathode * Please refer to Signage LED 38

42 SMD Product Quick View Table Chip LED_Side View Color Single Color Dual Color Multi Color Product Type General Reflector General General Dimension (mm) 1.6x x x x x x x x x x x t S110 S320 S115(A) S326(A) S327(C) S310(A) S311(C) S32F(A) 0.6t S270 S220 S33G(A) 0.5t 0.4t S850 S33F(A) S43F(C) 0.3t S482 A=Common Anode C=Common Cathode PLCC_Top View Color Single Color Dual Color Multi Color Dimension (mm) 2.0x x x x x x x x x x x x x x t T680/670 (PLCC2) E680 (PLCC4) F680 E682 A t G t M230 M670 G683 P t M t t K t Q t C t PLCC_Side View Color Single Color Dual Color Multi Color Dimension (mm) 2.8x x x x x x x t t t t 303

43 Chip LED_Top View 0.6 x 0.3 x 0.25 mm Part No. Color λ d (nm)/cie(x,y) Chip LED_Top View Typ. Luminous Intensity Iv View Angle Typ. Voltage V F (V) Current I F LTST-C371KRKT Red LTST-C371KFKT Orange LTST-C371KSKT Yellow LTST-C371KGKT Yellow Green LTST-C371JGKT True Green LTST-C371JBKT Blue LTW-C371US5 White (0.304, 0.301) x 0.5 x 0.2 mm Part No. Color λ d (nm)/cie(x,y) Typ. Luminous Intensity Iv View Angle Typ. Voltage V F (V) Current I F LTST-C283KRKT-5A Red LTST-C283KFKT-5A Orange LTST-C283KSKT-5A Yellow LTST-C283KGKT-5A Yellow Green LTST-C283TGKT-5A True Green LTST-C283TBKT-5A Blue LTW-C283DS5 White (0.304, 0.301) Infrared Emitter and Flash LED SMD LED Through Hole Lamp LED Display Automotive LED Signage LED Lighting LED Optical Sensors Photocoupler UV LED Detector 40

44 Chip LED_Top View 1.0 x 0.8 x 0.35 mm Part No. Color λ d (nm)/cie(x,y) Typ. Luminous Intensity Iv View Angle Typ. Voltage V F (V) Current I F LTST-C281KRKT-5A Red LTST-C281KFKT-5A Orange LTST-C281KSKT-5A Yellow LTST-C281KGKT-5A Yellow Green LTST-C281TGKT-5A True Green LTST-C281TBKT-5A Blue LTW-C281DS5 White (0.304, 0.301) Chip LED_Top View 1.6 x 0.8 x 0.2 mm Part No. Color λ d (nm)/cie(x,y) Typ. Luminous Intensity Iv View Angle Typ. Voltage V F (V) Current I F LTST-C198KRKT Red LTST-C198KFKT Orange LTST-C198KSKT Yellow LTST-C198KGKT Yellow Green LTST-C198TGKT True Green LTST-C198TBKT Blue LTW-198ZDS5 White (0.31, 0.33) LED Catalog

45 Chip LED_Top View 1.6 x 0.8 x 0.3 mm Part No. Color λ d (nm)/cie(x,y) Chip LED_Top View Typ. Luminous Intensity Iv View Angle Typ. Voltage V F (V) Current I F LTST-C194KRKT Red LTST-C194KFKT Orange LTST-C194KSKT Yellow LTST-C194KGKT Yellow Green LTST-C194TGKT True Green LTST-C194TBKT Blue LTW-C194TS5 White (0.294, 0.286) x 0.8 x 0.35 mm Part No. Color λ d (nm)/cie(x,y) Typ. Luminous Intensity Iv View Angle Typ. Voltage V F (V) Current I F LTST-C193KRKT-5A Red LTST-C193KFKT-5A Orange LTST-C193KSKT-5A Yellow LTST-C193KGKT-5A Yellow Green LTST-C193TGKT-5A True Green LTST-C193TBKT-5A Blue LTW-C193TS5 White (0.294, 0.286) Infrared Emitter and Flash LED SMD LED Through Hole Lamp LED Display Automotive LED Signage LED Lighting LED Optical Sensors Photocoupler UV LED Detector 42

46 Chip LED_Top View 1.6 x 0.8 x 0.55 mm Part No. Color λ d (nm)/cie(x,y) Typ. Luminous Intensity Iv View Angle Typ. Voltage V F (V) Current I F LTST-C191KRKT Red LTST-C191KFKT Orange LTST-C191KSKT Yellow LTST-C191KGKT Yellow Green LTST-C191TGKT True Green LTST-C191TBKT Blue LTW-C191TS5 White (0.294, 0.286) Chip LED_Top View 1.6 x 0.8 x 0.8 mm Part No. Color λ d (nm)/cie(x,y) Typ. Luminous Intensity Iv View Angle Typ. Voltage V F (V) Current I F LTST-C190KRKT Red LTST-C190KFKT Orange LTST-C190KSKT Yellow LTST-C190KGKT Yellow Green LTST-C190TGKT True Green LTST-C190TBKT Blue LTW-C190DA5 White (0.203, 0.319) LED Catalog

47 Chip LED_Top View 1.6 x 0.9 x 0.75 mm Part No. Color λ d (nm)/cie(x,y) Chip LED_Top View Typ. Luminous Intensity Iv View Angle Typ. Voltage V F (V) Current I F LTST-C19DKRKT Red LTST-C19DKFKT Orange LTST-C19DKSKT Yellow LTST-C19DTGKT True Green LTW-C19DZDS5 White (0.27, 0.26) x 1.25 x 0.8 mm Part No. Color λ d (nm)/cie(x,y) Typ. Luminous Intensity Iv View Angle Typ. Voltage V F (V) Current I F LTST-C171KRKT Red LTST-C171KFKT Orange LTST-C171KSKT Yellow LTST-C171KGKT Yellow Green LTST-C171TGKT True Green LTST-C171TBKT Blue Infrared Emitter and Flash LED SMD LED Through Hole Lamp LED Display Automotive LED Signage LED Lighting LED Optical Sensors Photocoupler UV LED Detector 44

48 Chip LED_Top View 2.0 x 1.25 x 1.1 mm Part No. Color λ d (nm)/cie(x,y) Typ. Luminous Intensity Iv View Angle Typ. Voltage V F (V) Current I F LTST-C170KRKT Red LTST-C170KFKT Orange LTST-C170KSKT Yellow LTST-C170KGKT Yellow Green LTST-C170TGKT True Green LTST-C170TBKT Blue LTW-170ZDC White (0.30, 0.30) Chip LED_Top View 3.2 x 1.6 x 1.1 mm Part No. Color λ d (nm)/cie(x,y) Typ. Luminous Intensity Iv View Angle Typ. Voltage V F (V) Current I F LTST-C150KRKT Red LTST-C150KFKT Orange LTST-C150KSKT Yellow LTST-C150KGKT Yellow Green LTST-C150TGKT True Green LTST-C150TBKT Blue LTW-150ZDS5 White (0.31, 0.32) LED Catalog

49 Chip LED_Top View_Reverse Mount 3.2 x 0.8 x 0.7 mm Part No. Color λ d (nm)/cie(x,y) Chip LED_Top View_Reverse Mount Typ. Luminous Intensity Iv View Angle Typ. Voltage V F (V) Current I F LTST-C231KRKT Red LTST-C231KFKT Orange LTST-C231KSKT Yellow LTST-C231KGKT Yellow Green LTST-C231TGKT True Green LTST-C231TBKT Blue LTW-C231DS White (0.31, 0.32) x 1.2 x 0.8 mm Part No. Color λ d (nm)/cie(x,y) Typ. Luminous Intensity Iv View Angle Typ. Voltage V F (V) Current I F LTST-C250KRKT Red LTST-C250KFKT Orange LTST-C250KSKT Yellow LTST-C250KGKT Yellow Green LTST-C250TGKT True Green LTST-C250TBKT Blue LTW-C250DC5 White (0.28, 0.27) Infrared Emitter and Flash LED SMD LED Through Hole Lamp LED Display Automotive LED Signage LED Lighting LED Optical Sensors Photocoupler UV LED Detector 46

50 Chip LED_Top View_Reverse Mount 3.2 x 1.6 x 1.1 mm Part No. Color λ d (nm)/cie(x,y) Typ. Luminous Intensity Iv View Angle Typ. Voltage V F (V) Current I F LTST-C230KRKT Red LTST-C230KFKT Orange LTST-C230KSKT Yellow LTST-C230KGKT Yellow Green LTST-C230TGKT True Green LTST-C230TBKT Blue LTW-C230DS White (0.294, 0.286) Chip LED _Top View _Dome Lens 1.6 x 0.8 x 0.98 mm Part No. Color λ d (nm)/cie(x,y) Typ. Luminous Intensity Iv View Angle Typ. Voltage V F (V) Current I F LTST-C990KRKT Red LTST-C990KFKT Orange LTST-C990KSKT Yellow LTST-C990KGKT Yellow Green LTST-C990TGKT True Green LTST-C990TBKT Blue LED Catalog

51 Chip LED _Top View _Dome Lens 3.2 x 1.6 x 1.85 mm Part No. Color λ d (nm)/cie(x,y) Chip LED _Top View _Dome Lens Iv View Angle Typ. Voltage V F (V) Current I F LTST-C950KRKT Red LTST-C950KFKT Orange LTST-C950KSKT Yellow LTST-C950KGKT Yellow Green LTST-C950TGKT True Green LTST-C950TBKT Blue LTW-C9501DS5 White (0.294, 0.286) LTW-9501ZDS5 White (0.294, 0.286) x 2.4 x 2.4 mm Part No. Color λ d (nm)/cie(x,y) Typ. Luminous Intensity Iv View Angle Typ. Voltage V F (V) Current I F LTST-C930KRKT Red LTST-C930KFKT Orange LTST-C930KSKT Yellow LTST-C930KGKT Yellow Green LTST-C930TGKT True Green LTST-C930TBKT Blue LTW-C9301DS5 White (0.294, 0.286) LTW-9301ZDS5 White (0.294, 0.286) Infrared Emitter and Flash LED SMD LED Through Hole Lamp LED Display Automotive LED Signage LED Lighting LED Optical Sensors Photocoupler UV LED Detector 48

52 Chip LED _Top View_Inner Lens 3.2 x 1.6 x 0.6 mm Part No. Color λ d (nm)/cie(x,y) Typ. Luminous Intensity Iv View Angle Typ. Voltage V F (V) Current I F LTST-C216KRKT Red LTST-C216KFKT Orange LTST-C216KSKT Yellow LTST-C216KGKT Yellow Green LTST-C216TGKT True Green LTST-C216TBKT Blue LTW-216TS5 White (0.304, 0.301) Chip LED _Top View_Inner Lens 3.2 x 1.6 x 1.1 mm Part No. Color λ d (nm)/cie(x,y) Typ. Luminous Intensity Iv View Angle Typ. Voltage V F (V) Current I F LTST-C21KRKT Red LTST-C21KFKT Orange LTST-C21KSKT Yellow LTST-C21KGKT Yellow Green LTST-C21TGKT True Green LTST-C21TBKT Blue LTW-21TS5 White (0.304, 0.301) LED Catalog

53 Chip LED_Top View_Dual Color Part No. Color λ d (nm)/cie(x,y) LTST-C285TBKEWT-5A LTST-C285TGKFWT-5A LTST-C285KGKFWT-5A LTW-C285DSKG-5A Chip LED_Top View_Dual Color Typ. Luminous Intensity Iv View Angle Typ. Voltage V F (V) Current I F Red Blue Orange True Green Orange Yellow Green Yellow Green White (0.30, 0.30) Part No. Color λ d (nm)/cie(x,y) LTST-C295TBKFKT LTST-C295KGKFKT LTST-C295KGKRKT LTW-295DSKS-5A 1.0 x 0.5 x 0.35 mm 1.6 x 0.8 x 0.55 mm C1 A C2 Typ. Luminous Intensity Iv View Angle Typ. Voltage V F (V) Current I F Orange Blue Orange Yellow Green Red Yellow Green Yellow White (0.30, 0.30) Infrared Emitter and Flash LED SMD LED Through Hole Lamp LED Display Automotive LED Signage LED Lighting LED Optical Sensors Photocoupler UV LED Detector 50

54 Chip LED_Top View_Dual Color 1.6 x 1.25 x 0.55 mm Part No. Color λ d (nm)/cie(x,y) Typ. Luminous Intensity Iv View Angle Typ. Voltage V F (V) Current I F LTST-C395TBKFKT LTST-C395KGKFKT LTST-C395KGKRKT Orange Blue Orange Yellow Green Red Yellow Green Chip LED_Top View_Dual Color 1.6 x 1.5 x 0.55 mm Part No. Color λ d (nm)/cie(x,y) Typ. Luminous Intensity Iv View Angle Typ. Voltage V F (V) Current I F LTST-C195TBJRKT LTST-C195KGKFKT LTST-C195KGJRKT LTW-C195DSKS-5A Red Blue Orange Yellow Green Red Yellow Green Yellow White (0.30, 0.30) LED Catalog

55 Chip LED_Top View_Dual Color Part No. Color λ d (nm)/cie(x,y) LTST-C197TGKEKT LTST-C197KGKEKT LTST-C197KGKSKT Chip LED_Top View_Dual Color Typ. Luminous Intensity Iv View Angle Typ. Voltage V F (V) Current I F Red True Green Red Yellow Green Yellow Yellow Green Part No. Color λ d (nm)/cie(x,y) LTST-C155TBJRKT LTST-C155KGKFKT LTST-C155KGJRKT 1.6 x 1.5 x 0.7 mm 3.2 x 2.7 x 1.1 mm Typ. Luminous Intensity Iv View Angle Typ. Voltage V F (V) Current I F Red Blue Orange Yellow Green Red Yellow Green Infrared Emitter and Flash LED SMD LED Through Hole Lamp LED Display Automotive LED Signage LED Lighting LED Optical Sensors Photocoupler UV LED Detector 52

56 Chip LED_Top View_Reverse Mount Dual Color 3.2 x 1.2 x 0.8 mm Part No. Color λ d (nm)/cie(x,y) Typ. Luminous Intensity Iv View Angle Typ. Voltage V F (V) Current I F LTST-C255TBKFWT-5A LTW-C255DCKF-5A Orange Blue Orange White (0.28, 0.27) Chip LED_Top View_Reverse Mount Dual Color 3.2 x 1.6 x 1.1 mm Part No. Color λ d (nm)/cie(x,y) Typ. Luminous Intensity Iv View Angle Typ. Voltage V F (V) Current I F LTST-C235TBJRKT LTST-C235KGKSKT LTST-C235KGKRKT LTW-C235DSKF-5A Red Blue Yellow Yellow Green Red Yellow Green Orange White (0.30, 0.30) LED Catalog

57 Chip LED_Top View_Multi Color Part No. Color λ d (nm) LTST-C28NBEGK-2A Chip LED_Top View_Multi Color Typ. Luminous Intensity Iv Red Part No. Color λ d (nm) LTST-B28JEGBB-5A 1.0 x 1.0 x 0.25 mm 1.0 x 1.0 x 0.5 mm View Angle Typ. Voltage V F (V) Current I F True Green Blue Typ. Luminous Intensity Iv Red View Angle Typ. Voltage V F (V) Current I F True Green Blue Infrared Emitter and Flash LED SMD LED Through Hole Lamp LED Display Automotive LED Signage LED Lighting LED Optical Sensors Photocoupler UV LED Detector 54

58 Chip LED_Top View_Multi Color 1.6 x 1.6 x 0.35 mm Part No. Color λ d (nm) Typ. Luminous Intensity Iv View Angle Typ. Voltage V F (V) Current I F Red LTST-C19HE1WT True Green Blue Red LTST-C19HRGYW Yellow True Green Chip LED_Top View_Multi Color 1.6 x 1.6 x 0.35 mm Part No. Color λ d (nm) Typ. Luminous Intensity Iv View Angle Typ. Voltage V F (V) Current I F Red LTST-C19KBEGK-5A True Green Blue LED Catalog

59 Chip LED_Top View_Multi Color Part No. Color λ d (nm) LTST-C19JZEGB1W-5A Part No. Color λ d (nm) LTST-C19MGEBK-5A 1.6 x 1.6 x 0.5 mm Chip LED_Top View_Multi Color 1.6 x 1.6 x 0.5 mm Typ. Luminous Intensity Iv Red Typ. Luminous Intensity Iv Red View Angle View Angle Typ. Voltage V F (V) Typ. Voltage V F (V) Current I F True Green Blue Current I F 2 5 True Green Blue Infrared Emitter and Flash LED SMD LED Through Hole Lamp LED Display Automotive LED Signage LED Lighting LED Optical Sensors Photocoupler UV LED Detector 56

60 Chip LED_Top View_Multi Color 1.6 x 2.1 x 0.4 mm Part No. Color λ d (nm) Typ. Luminous Intensity Iv View Angle Typ. Voltage V F (V) Current I F Red LTST-C19GD2WT True Green Blue Chip LED_Top View_Multi Color 1.6 x 2.1 x 0.55 mm Part No. Color λ d (nm) Typ. Luminous Intensity Iv View Angle Typ. Voltage V F (V) Current I F Orange LTST-C19FD1WT True Green Blue LED Catalog

61 Chip LED_Side View 1.8 x 1.0 x 0.3 mm Part No. Color λ d (nm)/cie(x,y) Typ. Luminous Intensity Iv View Angle Typ. Voltage V F (V) Current I F LTST-S482KRKT-5A Red LTST-S482KFKT-5A Orange LTST-S482KSKT-5A Yellow LTST-S482KGKT-5A Yellow Green LTST-S482TGKT-5A True Green LTST-S482TBKT-5A Blue LTW-S482DS5 White (0.29, 0.29) Chip LED_Side View 1.6 x 1.15 x 0.6 mm Part No. Color λ d (nm)/cie(x,y) Typ. Luminous Intensity Iv View Angle Typ. Voltage V F (V) Current I F LTST-S270KRKT Red LTST-S270KFKT Orange LTST-S270KSKT Yellow LTST-S270KGKT Yellow Green LTST-S270TGKT True Green LTST-S270TBKT Blue LTW-270TLA White (0.31, 0.32) Infrared Emitter and Flash LED SMD LED Through Hole Lamp LED Display Automotive LED Signage LED Lighting LED Optical Sensors Photocoupler UV LED Detector 58

62 Chip LED_Side View 2.1 x 1.0 x 0.6 mm Part No. Color λ d (nm)/cie(x,y) Typ. Luminous Intensity Iv View Angle Typ. Voltage V F (V) Current I F LTST-S220KRKT Red LTST-S220KFKT Orange LTST-S220KSKT Yellow LTST-S220KGKT Yellow Green LTST-S220TGKT True Green LTST-S220TBKT Blue LTW-S221DS White (0.3, 0.3) Chip LED_Side View 3.2 x 1.5 x 1.0 mm Part No. Color λ d (nm)/cie(x,y) Typ. Luminous Intensity Iv View Angle Typ. Voltage V F (V) Current I F LTST-S110KRKT Red LTST-S110KFKT Orange LTST-S110KSKT Yellow LTST-S110KGKT Yellow Green LTST-S110TGKT True Green LTST-S110TBKT Blue LTW-110TS5 White (0.304, 0.301) LED Catalog

63 Chip LED_Side View 3.0 x 2.0 x 1.0 mm Part No. Color λ d (nm)/cie(x,y) Typ. Luminous Intensity Iv View Angle Typ. Voltage V F (V) Current I F LTST-S320KRKT Red LTST-S320KFKT Orange LTST-S320KSKT Yellow LTST-S320KGKT Yellow Green LTST-S320TGKT True Green LTST-S320TBKT Blue LTW-S321ZDS5 White (0.30, 0.29) Chip LED_Side View with Reflector 1.4 x 0.8 x 0.4 mm Part No. Color λ d (nm)/cie(x,y) Typ. Luminous Intensity Iv View Angle Typ. Voltage V F (V) Current I F LTW-S850DC5 White (0.2862, ) Infrared Emitter and Flash LED SMD LED Through Hole Lamp LED Display Automotive LED Signage LED Lighting LED Optical Sensors Photocoupler UV LED Detector 60

64 Chip LED_Side View_Dual Color 3.2 x 1.5 x 1.0 mm Part No. Color λ d (nm)/cie(x,y) Typ. Luminous Intensity Iv View Angle Typ. Voltage V F (V) Current I F LTST-S115TGKFKT LTST-S115KGKFKT LTST-S115KGJRKT LTW-S115KFDS-5A Orange True Green Orange Yellow Green Red Yellow Green Orange White (0.29, 0.282) Chip LED_Side View_Dual Color 3.0 x 2.0 x 1.0 mm Part No. Color λ d (nm)/cie(x,y) Typ. Luminous Intensity Iv View Angle Typ. Voltage V F (V) Current I F LTST-S326TBKSKT LTST-S326KGKFKT LTST-S326KGJRKT LTW-326DSKF-5A Yellow Blue Orange Yellow Green Red Yellow Green Orange White (0.3, 0.3) LED Catalog

65 Chip LED_Side View_Dual Color Part No. Color λ d (nm)/cie(x,y) LTST-S327TBKFKT LTST-S327KGJRKT LTST-S327KGJSKT LTW-327DSKF-5A Part No. Color λ d (nm) LTST-S33FBEGW-5A 3.0 x 2.0 x 1.0 mm Chip LED_Side View_Multi Color 3.0 x 1.0 x 0.4 mm Typ. Luminous Intensity Iv View Angle Typ. Voltage V F (V) Current I F Orange Blue Red Yellow Green Yellow Yellow Green Orange White (0.3, 0.3) Typ. Luminous Intensity Iv Red View Angle Typ. Voltage V F (V) Current I F True Green Blue Infrared Emitter and Flash LED SMD LED Through Hole Lamp LED Display Automotive LED Signage LED Lighting LED Optical Sensors Photocoupler UV LED Detector 62

66 Chip LED_Side View_Multi Color 3.0 x 1.0 x 0.4 mm Part No. Color λ d (nm) Typ. Luminous Intensity Iv View Angle Typ. Voltage V F (V) Current I F Red LTST-S43FBEGW True Green Blue Chip LED_Side View_Multi Color 3.0 x 1.0 x 0.6 mm Part No. Color λ d (nm) Typ. Luminous Intensity Iv View Angle Typ. Voltage V F (V) Current I F Red LTST-S33GBEGK True Green Blue LED Catalog

67 Chip LED_Side View_Multi Color Part No. Color λ d (nm) LTST-S310F3WT Part No. Color λ d (nm) LTST-S32F1KT 3.2 x 1.5 x 1.0 mm Typ. Luminous Intensity Iv Red Chip LED_Side View_Multi Color 3.0 x 2.0 x 1.0 mm Typ. Luminous Intensity Iv Red View Angle View Angle Typ. Voltage V F (V) Typ. Voltage V F (V) Current I F 2 20 True Green Blue Current I F 2 20 True Green Blue Infrared Emitter and Flash LED SMD LED Through Hole Lamp LED Display Automotive LED Signage LED Lighting LED Optical Sensors Photocoupler UV LED Detector 64

68 - + PLCC_Top View - + Anode 2.0 x 1.6 x 0.55 mm - + Part No. Color λ d (nm)/ CIE(x,y) Typ. Luminous Intensity Iv View Angle Typ. Voltage V F (V) Current I F Max. Current I F LTST-C0610VEWT Red LTST-C0610VSWT Yellow LTST-C0610UGWT True Green LTST-C0610UBWT Blue LTST-C0610ZWET White (0.31, 0.31) PLCC_Top View 2.3 x 1.4 x 1.3 mm Part No. Color λ d (nm)/ CIE(x,y) Typ. Luminous Intensity Iv View Angle Typ. Voltage V F (V) Current I F Max. Current I F LTST-M230VEWT Red LTST-M230VSWT Yellow LTST-M230UGWT True Green LTST-M230UBWT Blue LTST-M230ZWET White (0.31, 0.31) LED Catalog

69 PLCC_Top View Part No. 2.7 x 1.4 x 0.8 mm Color λ d (nm)/ CIE(x,y) Typ. Luminous Flux Φv (lm) View Angle Typ. Voltage V F (V) Current I F LTW-K140RS625 Red LTW-K140OS607 Orange LTW-K140YS587 Yellow LTW-K140GS525 True Green LTW-K140BS470 Blue LTW-K140SCIB Ice Blue (0.24, 0.29) LTW-K140SCTF Tiffany Blue (0.22, 0.33) LTW-K140SCVL Violet (0.32, 0.19) LTW-K140SCSK Sakura Pink (0.45, 0.26) LTW-K140SCGD Gold (0.40, 0.46) Max. Current I F Infrared Emitter and Flash LED SMD LED Through Hole Lamp LED Display Automotive LED Signage LED Lighting LED Optical Sensors Photocoupler UV LED Detector 66

70 PLCC_Top View 3.0 x 1.4 x 1.2 mm Part No. Color λ d (nm)/ CIE(x,y) Typ. Luminous Intensity Iv Typ. Luminous Flux Φv (lm) View Angle Typ. Voltage V F (V) Current I F Max. Current I F LTST-M140KRKT Red LTST-M140QEKT Red Orange LTST-M140KFKT Orange LTST-M140KSKT Yellow LTST-M140QSKT Yellow LTST-M140KGKT Yellow Green LTST-M140TGKT True Green LTST-M140TBKT Blue LTW-M140ZVS White (0.296, 0.285) LED Catalog

71 PLCC_Top View Part No. 3.0 x 2.0 x 1.3 mm Color λ d (nm)/ CIE(x,y) Typ. Luminous Intensity Iv View Angle Typ. Voltage V F (V) Current I F LTST-M670KRKT Red LTST-M670KFKT Orange LTST-M670KSKT Yellow LTST-M670KGKT Yellow Green LTST-M670TGKT True Green LTST-M670TBKT Blue LTW-M670ZVS-M5 White (0.29, 0.27) Max. Current I F Infrared Emitter and Flash LED SMD LED Through Hole Lamp LED Display Automotive LED Signage LED Lighting LED Optical Sensors Photocoupler UV LED Detector 68

72 PLCC_Top View 3.5 x 2.8 x 1.9 mm Part No. Color λ d (nm)/ CIE(x,y) Typ. Luminous Intensity Iv Typ. Luminous Flux Φv (lm) View Angle Typ. Voltage V F (V) Current I F Max. Current I F LTST-T680KRWT Red LTW-670RS625 Red LTST-T680VEWT Red LTST-T680QEWT Red LTW-670OS607 Orange LTST-T680KFWT Orange LTST-T680KSWT Yellow LTST-T680VSWT Yellow LTST-T680QSWT Yellow LTW-670YS587 Yellow LTST-T680KGWT Yellow Green LTST-T680TGWT True Green LTST-T680UGWT True Green LTW-670GS525 True Green LTST-T680UBWT Blue LTW-670BS470 Blue LTW-670DS-EL White (0.31, 0.30) LTST-T680UWET White (0.31, 0.31) LED Catalog

73 PLCC_Top View Part No. Color λ d (nm) Typ. Luminous Intensity Iv View Angle Typ. Voltage V F (V) Current I F Max. Current I F LTST-E680VEWT Red LTST-E680VSWT Yellow LTST-E680UGWT True Green LTST-E680UBWT Blue PLCC_Top View 3.5 x 2.8 x 1.9 mm 5.6 x 3.0 x 0.9 mm Part No. Color λ d (nm) Typ. Luminous Flux Φv (lm) View Angle Typ. Voltage V F (V) Current I F LTST-5630VDWT Red LTST-5630VEWT Red LTST-5630VSWT Yellow LTST-5630UGWT True Green LTST-5630UBWT Blue LTST-5630ULWT Blue Max. Current I F Infrared Emitter and Flash LED SMD LED Through Hole Lamp LED Display Automotive LED Signage LED Lighting LED Optical Sensors Photocoupler UV LED Detector 70

74 PLCC_Top View 6.2 x 2.8 x 1.9 mm Part No. Color λ d (nm)/ CIE(x,y) Typ. Luminous Intensity Iv View Angle Typ. Voltage V F (V) Current I F Max. Current I F LTST-F680VEWT Red LTST-F680VSWT Yellow LTST-F680UGWT True Green LTST-F680UBWT Blue LTST-F680UBET White (0.31, 0.31) PLCC_Top View_Dual Color 3.5 x 2.8 x 1.9 mm Part No. Color λ d (nm) Typ. Luminous Intensity Iv View Angle Typ. Voltage V F (V) Current I F Max. Current I F LTST-E682KRKGWT LTST-E682KGKFWT LTST-E682KGKSWT LTST-E682KETBWT LTST-E682TGKRWT Red Yellow Green Orange Yellow Green Yellow Yellow Green Red Blue True Green Red LED Catalog

75 PLCC_Top View_Multi Color Part No. Color λ d (nm) LTST-G683GEBW LTST-G683RGBW LTST-G683ESBW 3.5 x 2.8 x 1.3 mm Typ. Luminous Intensity Iv View Angle Typ. Voltage V F (V) Current I F Max. Current I F Red True Green Blue Red True Green Blue Red Yellow Blue Infrared Emitter and Flash LED SMD LED Through Hole Lamp LED Display Automotive LED Signage LED Lighting LED Optical Sensors Photocoupler UV LED Detector 72

76 PLCC_Top View_Multi Color 3.5 x 2.8 x 1.9 mm Part No. Color λ d (nm) Typ. Luminous Intensity Iv View Angle Typ. Voltage V F (V) Current I F Max. Current I F Red LTST-E683RGBW True Green Blue Orange LTST-E683FGBW True Green Blue Red LTST-E683EGSW True Green Yellow Red LTST-E683EGBW True Green Blue LED Catalog

77 PLCC_Top View_Multi Color Part No. Color λ d (nm) LTW-Q35ZRGB PLCC_Top View_Multi Color Part No. Color λ d (nm)/ CIE(x,y) Typ. Luminous Intensity Iv View Angle Typ. Voltage V F (V) Current I F LTST-G563DDDW Red LTST-G563EEEW Red LTST-G563SSSW Yellow LTST-G563ZGGGW True Green LTST-G563ZBBBW Blue LTST-G563ZEGBW 3.5 x 3.2 x 0.65 mm 5.4 x 5.0 x 1.6 mm Typ. Luminous Flux Φv (lm) View Angle Typ. Voltage V F (V) Current I F Max. Current I F Red True Green Blue LTST-G563BBBE White (0.31, 0.31) Max. Current I F Red True Green Blue Infrared Emitter and Flash LED SMD LED Through Hole Lamp LED Display Automotive LED Signage LED Lighting LED Optical Sensors Photocoupler UV LED Detector 74

78 PLCC_Top View_Multi Color 6.2 x 2.8 x 1.9 mm Part No. Color λ d (nm) Typ. Luminous Intensity Iv View Angle Typ. Voltage V F (V) Current I F Max. Current I F Red LTST-A683GEBW True Green Blue Red LTST-A683BEGW True Green Blue PLCC_Top View_Multi Color 7.4 x 5.0 x 1.3 mm Part No. Color λ d (nm) Typ. Luminous Intensity Iv Typ. Luminous Flux Φv (lm) View Angle Typ. Voltage V F (V) Current I F Max. Current I F Red LTPL-P033RGB True Green Blue LED Catalog

79 PLCC_Side View 3.0 x 0.85 x 0.35 mm Part No. Color CIE(x,y) Typ. Luminous Flux Φv (lm) View Angle Typ. Voltage V F (V) Current I F Max. Current I F LTW-303DCG-KB White (0.285, 0.265) Infrared Emitter and Flash LED SMD LED Through Hole Lamp LED Display Automotive LED Signage LED Lighting LED Optical Sensors Photocoupler UV LED Detector 76

80 PLCC_Side View 3.8 x 1.0 x 0.4 mm 3.8 x 0.9 x 0.43 mm (LTW-010ZDCG only) Part No. Color λ d (nm)/ CIE(x,y) Typ. Luminous Intensity Iv View Angle Typ. Voltage V F (V) Current I F Max. Current I F LTST-010KRKT Red LTW-010SCR Red LTST-010KFKT Orange LTST-010KSKT Yellow LTST-010KGKT Yellow Green LTW-010SCG True Green LTST-010TGKT True Green LTST-010TBKT Blue LTW-010SCB Blue LTW-010DCG White (0.300, 0.283) LTW-010DCG-TR White (0.293, 0.283) LTW-010SCSK Sakura Pink (0.45, 0.26) LTW-010SCVL Violet (0.32, 0.19) LED Catalog

81 PLCC_Side View Part No. PLCC_Side View Part No. 3.8 x 1.0 x 0.6 mm Color 3.8 x 1.2 x 0.6 mm Color λ d (nm)/ CIE(x,y) λ d (nm)/ CIE(x,y) Typ. Luminous Flux Φv (lm) Typ. Luminous Intensity Iv View Angle View Angle Typ. Voltage V F (V) Typ. Voltage V F (V) Current I F LTW-206KRKT Red LTW-206VFKT-PX Orange LTW-206DCG-TMS White (0.285, 0.267) LTW-206DCG-TM White (0.285, 0.267) Current I F LTST-020KRKT Red LTST-020KFKT Orange LTST-020KSKT Yellow LTST-020KGKT Yellow Green LTST-020TGKT True Green LTST-020TBKT Blue LTW-020ZDCG White (0.297, 0.278) LTW-006DCG-E2 White (0.277, 0.257) Max. Current I F Max. Current I F Infrared Emitter and Flash LED SMD LED Through Hole Lamp LED Display Automotive LED Signage LED Lighting LED Optical Sensors Photocoupler UV LED Detector 78

82 PLCC_Side View 2.8 x 1.2 x 0.8 mm 2.85 x 1.2 x 0.8 mm (LTW-108DCG only ) Part No. Color λ d (nm)/ CIE(x,y) Typ. Luminous Intensity Iv View Angle Typ. Voltage V F (V) Current I F Max. Current I F LTST-108KRKT Red LTST-108KFKT Orange LTST-108KSKT Yellow LTST-108KGKT Yellow Green LTST-108TGKT True Green LTST-108TBKT Blue LTW-008ZDCG White (0.295, 0.273) LTW-108SEG-W White (0.295, 0.280) PLCC_Side View_Dual Color 4.5 x 1.25 x 0.8 mm Part No. Color λ d (nm) Typ. Luminous Intensity Iv View Angle Typ. Voltage V F (V) Current I F Max. Current I F LTST-008TGKEWT Red True Green LED Catalog

83 PLCC_Side View_Multi Color Part No. Color λ d (nm) LTST-006BGEW LTST-006GEBW 0.40 AREA FOR NOZZLE PICK-UP 0.40 * 4.50 Typ. Luminous Intensity Iv Red View Angle Typ. Voltage V F (V) Current I F Max. Current I F True Green Blue True Green Cathode Mark Red Blue B R G G R B Infrared Emitter and Flash LED SMD LED Through Hole Lamp LED Display Automotive LED Signage LED Lighting LED Optical Sensors Photocoupler UV LED Detector 80

84 PLCC_Side View_Multi Color 4.5 x 1.25 x 0.8 mm Part No. Color λ d (nm) Typ. Luminous Intensity Iv Typ. Luminous Flux Φv (lm) View Angle Typ. Voltage V F (V) Current I F Max. Current I F Red LTST-008BGEW True Green Blue True Green LTST-008GEBW Red Blue Red LTST-008EGSW True Green Yellow Blue LTW-008RGB2-PH1 True Green Red LED Catalog

85 Through Hole Lamp

86 3mm 3mm Round Part No. Color Resin Color λ d (nm)/ CIE (x,y) Min. Luminous Intensity Iv Max. Luminous Intensity Iv View Angle Typ. Voltage V F (V) Current I F LTL1CHKEKNN Red Water Clear LTL1CHKFKNN Amber Water Clear LTL1CHKSKNN Yellow Water Clear LTL1CHKGKNN Yellow Green Water Clear LTL1CHTGK6 True Green Water Clear LTL1CHTBK5 Blue Water Clear LTW-1CHDS4 White Water Clear (0.29, 0.28) LTW-1GHCV4 White Water Clear (0.29, 0.28) LTW-87HD4BSZ White Water Clear (0.25, 0.21) mm 3mm Round Part No. Color Resin Color λ d (nm)/ CIE (x,y) Min. Luminous Intensity Iv Max. Luminous Intensity Iv View Angle Typ. Voltage V F (V) Current I F LTL1NHEG6D Red Red Diffused LTL1NHSJ4D Yellow Yellow Diffused LTL1NHGB4D Yellow Green Green Diffused LTL1NHTGT4TZ True Green Green Transparent LTL1NHTBH4J Blue White Diffused LTW-1NHDY2 White Water Clear (0.27, 0.25) LTW-1NHDR7JW White White Diffused (0.42, 0.40) LED Catalog

87 3mm Part No. Color Resin Color λ d (nm)/ CIE (x,y) Min. Luminous Intensity Iv Max. Luminous Intensity Iv View Angle Typ. Voltage V F (V) LTL17KRH5D Super Red Red Diffused LTL17KRL6D Red Red Diffused LTL17KET3KS Red Water Clear LTL17KFL5D Amber 3mm Round Amber Diffused Current I F LTL17KSL5D Yellow Yellow Diffused LTL17KGH5D Yellow Green Green Diffused LTL17KCGP4J True Green White Diffused LTL17KTGX3KS True Green Water Clear LTL17KCBH5D Blue Blue Diffused LTL17KTBS3KS Blue Water Clear LTW-17KDU4Z White Water Clear (0.29, 0.28) Infrared Emitter and Flash LED SMD LED Through Hole Lamp LED Display Automotive LED Signage LED Lighting LED Optical Sensors Photocoupler UV LED Detector 84

88 3mm 3mm Round Part No. Color Resin Color λ d (nm)/ CIE (x,y) Min. Luminous Intensity Iv Max. Luminous Intensity Iv View Angle Typ. Voltage V F (V) Current I F LTL42NKRKNN Super Red Water Clear LTL42NKFKNN Amber Water Clear LTL42NKSKNN Yellow Water Clear LTL42NKGKNN Yellow Green Water Clear LTL42TG6N True Green Water Clear LTL42TB6N Blue Water Clear LTW-42NDP4 White Water Clear (0.3, 0.3) mm_Dual Color 3mm Round Part No. Color Resin Color λ d (nm)/ CIE (x,y) Min. Luminous Intensity Iv Max. Luminous Intensity Iv View Angle Typ. Voltage V F (V) Current I F LTL67HGEJ Red White Diffused 110 Yellow Green LED Catalog

89 3mm_Dual Color Part No. Color Resin Color LTL1BETBEK5-HF LTL1BETBYJR5 LTL1BEKVJNN LTW-1BEEDNJZ LTW-1BETBKJLC 3mm Round λ d (nm)/ CIE (x,y) Min. Luminous Intensity Iv Max. Luminous Intensity Iv View Angle Typ. Voltage V F (V) Red White Diffused 30 Blue Yellow White Diffused 30 Blue Red White Diffused 45 Yellow Green Red White Diffused 30 White (0.26, 0.22) Blue White Diffused 30 White (0.3, 0.3) Current I F Infrared Emitter and Flash LED SMD LED Through Hole Lamp LED Display Automotive LED Signage LED Lighting LED Optical Sensors Photocoupler UV LED Detector 86

90 4mm 4mm Round Part No. Color Resin Color λ d (nm)/ CIE (x,y) Min. Luminous Intensity Iv Max. Luminous Intensity Iv View Angle Typ. Voltage V F (V) Current I F LTL17HGL4T Yellow Green Green Transpaned LTW-17HDU6J White White Diffused (0.27, 0.25) LTW-17HDW5J White White Diffused (0.27, 0.24) LTW-17HDY4 White White Diffused (0.3, 0.3) mm 5mm Round Part No. Color Resin Color λ d (nm)/ CIE (x,y) Min. Luminous Intensity Iv Max. Luminous Intensity Iv View Angle Typ. Voltage V F (V) Current I F LTL2R3KRK Red Water Clear LTL2R3KFK Orange Water Clear LTL2R3KSK Yellow Water Clear LTL2R3KG Yellow Green Water Clear LTL2T3TGK6 True Green Water Clear LTL2T3TBK5 Blue Water Clear LTW-2L3DV5 White Water Clear (0.29, 0.28) LTW-2S3D8 White Water Clear (0.3, 0.3) LTW-2V3DS3 White Water Clear (0.3, 0.3) LTW-2W3DRA White Water Clear (0.3, 0.3) LED Catalog

91 5mm_Dual Color Part No. Color Resin Color λ d (nm) LTL30EGCBKJ LTL30EJ9NN LTL30EKDFGJ 5mm_0.5W 5mm Round Min. Luminous Intensity Iv Max. Luminous Intensity Iv View Angle Typ. Voltage V F (V) Yellow Green White Diffused 30 Blue Yellow White Diffused 30 Yellow Green Red White Diffused 30 Yellow Green mm Round Part No. Color Lens Color CIE (x,y) Min. Luminous Intensity Iv Max. Luminous Intensity Iv View Angle Typ. Voltage V F (V) LTW2H3D51K White Water Clear (0.30, 0.30) LTW2P3D52K White Water Clear (0.30, 0.30) LTW2R3D43K White Water Clear (0.30, 0.30) Current I F Current I F Infrared Emitter and Flash LED SMD LED Through Hole Lamp LED Display Automotive LED Signage LED Lighting LED Optical Sensors Photocoupler UV LED Detector 88

92 RGB Lamp 5mm Part No Color Resin Color λ d (nm) Min. Luminous Intensity Iv Max. Luminous Intensity Iv View Angle Typ. Voltage V F (V) Current I F Red LTL750RGBHBJ True Green White Diffused Blue Circuit Board Indicator (CBI)_Single Level Part No. Color Resin Color CIE(x,y) Min. Luminous Intensity Iv Max. Luminous Intensity Iv View Angle Typ. Voltage V F (V) Current I F LTW-R4MLDGDJH234 White White Diffused (0.3, 0.29) H:130 V: LED Catalog

93 Circuit Board Indicator (CBI)_Single Level Part No. Color Resin Color CIE (x,y) Circuit Board Indicator (CBI)_Single Level Circuit Board Indicator (CBI)_Single Level Min. Luminous Intensity Iv Max. Luminous Intensity Iv View Angle Typ. Voltage V F (V) LTW-42NDP4H218 White Water clear (0.3, 0.3) Part No. Color Resin Color λ d (nm) Min. Luminous Intensity Iv Max. Luminous Intensity Iv View Angle Typ. Voltage V F (V) LTL-42NEW8DHBP-1 Red Red Diffused Part No. Color Resin Color λ d (nm) Min. Luminous Intensity Iv Max. Luminous Intensity Iv View Angle Typ. Voltage V F (V) LTL42TG6NH184 True Green Water clear Current I F Current I F Current I F Infrared Emitter and Flash LED SMD LED Through Hole Lamp LED Display Automotive LED Signage LED Lighting LED Optical Sensors Photocoupler UV LED Detector 90

94 Circuit Board Indicator (CBI)_Single Level Part No. Color Resin Color CIE (x,y) Min. Luminous Intensity Iv Max. Luminous Intensity Iv View Angle Typ. Voltage V F (V) Current I F LTW-1NHDR5JH231 White White Diffused (0.3, 0.29) Circuit Board Indicator (CBI)_Single Level Part No. Color Resin Color CIE (x,y) Min. Luminous Intensity Iv Max. Luminous Intensity Iv View Angle Typ. Voltage V F (V) Current I F LTW-42NDH8JH227 White White Diffused (0.3, 0.3) Circuit Board Indicator (CBI)_Single Level Part No. Color Resin Color λ d (nm) LTL1BESTBKJH185P Min. Luminous Intensity Iv Max. Luminous Intensity Iv View Angle Typ. Voltage V F (V) Blue White Diffused Yellow Current I F LED Catalog

95 Circuit Board Indicator (CBI)_Single Level Part No. Color Resin Color λ d (nm) LTL1BETBEK5H149 Min. Luminous Intensity Iv Max. Luminous Intensity Iv View Angle Typ. Voltage V F (V) Blue Water clear 30 Red Circuit Board Indicator (CBI)_Bi-Level Part No. Color Resin Color λ d (nm) LTL-14CM1H183 Min. Luminous Intensity Iv Max. Luminous Intensity Iv View Angle Yellow Green Color Diffused 3 50 Yellow Typ. Voltage V F (V) Current I F 20 Current I F Infrared Emitter and Flash LED SMD LED Through Hole Lamp LED Display Automotive LED Signage LED Lighting LED Optical Sensors Photocoupler UV LED Detector 92

96 Circuit Board Indicator (CBI)_Bi-Level Part No. Color Resin Color λ d (nm) Min. Luminous Intensity Iv Max. Luminous Intensity Iv View Angle Typ. Voltage V F (V) Current I F LTL-42M4NH106 Yellow Green Color Diffused Circuit Board Indicator (CBI)_Bi-Level Part No. Color Resin Color λ d (nm) Min. Luminous Intensity Iv Max. Luminous Intensity Iv View Angle Typ. Voltage V F (V) Current I F LTL-42NGY8D2H214 Yellow Green Color Diffused Circuit Board Indicator (CBI)_Bi-Level Part No. Color Resin Color CIE (x,y) Min. Luminous Intensity Iv Max. Luminous Intensity Iv View Angle Typ. Voltage V F (V) Current I F LTW-42NDH8JH229 White White Diffused (0.3, 0.3) LED Catalog

97 Circuit Board Indicator (CBI)_Tri-Level Part No. Color Resin Color λ d (nm) Min. Luminous Intensity Iv Max. Luminous Intensity Iv View Angle Typ. Voltage V F (V) LTL-42M3NHKP Yellow Green Green Diffused Circuit Board Indicator (CBI)_Quad-Level Part No. Color Resin Color λ d (nm) LTL-14CDJNH79 Yellow Green 565 Color Diffused Yellow 585 Min. Luminous Intensity Iv Max. Luminous Intensity Iv View Angle Typ. Voltage V F (V) Current I F Current I F Infrared Emitter and Flash LED SMD LED Through Hole Lamp LED Display Automotive LED Signage LED Lighting LED Optical Sensors Photocoupler UV LED Detector 94

98 Circuit Board Indicator (CBI)_Quin-Level Part No. Color Resin Color λ d (nm) Min. Luminous Intensity Iv Max. Luminous Intensity Iv View Angle Typ. Voltage V F (V) Current I F Orange LTL-14CM01H232 Yellow Color Diffused Blue Circuit Board Indicator (CBI)_PIP Part No. Color Resin Color λ d (nm) Min. Luminous Intensity Iv Max. Luminous Intensity Iv View Angle Typ. Voltage V F (V) LTL-R42NGYAD2H106 Yellow Green Color Diffused Current I F 95 LED Catalog

99 Circuit Board Indicator (CBI)_PIP Part No. Color Resin Color λ d (nm) Min. Luminous Intensity Iv Max. Luminous Intensity Iv View Angle Typ. Voltage V F (V) LTL-R42NGYADH229 Yellow Green Color Diffused Circuit Board Indicator (CBI)_PIP Part No. Color Resin Color λ d (nm) LTL-R42M12NH51 Red 624 Min. Luminous Intensity Iv Max. Luminous Intensity Iv View Angle Typ. Voltage V F (V) Yellow Green Color Diffused Blue Current I F Current I F 20 Infrared Emitter and Flash LED SMD LED Through Hole Lamp LED Display Automotive LED Signage LED Lighting LED Optical Sensors Photocoupler UV LED Detector 96

100 Circuit Board Indicators (CBI) with SMD LED Part No. Color Resin Color λ d (nm) Red 630 LTL-M12RG1H300Q White Diffused Yellow Green 570 Min. Luminous Intensity Iv Max. Luminous Intensity Iv View Angle Typ. Voltage V F (V) Current I F LED Catalog

101 Circuit Board Indicators (CBI) with SMD LED Part No. Color Resin Color λ d (nm) Yellow 590 LTL-M12YG1H300Q White Diffused Yellow Green 570 Min. Luminous Intensity Iv Max. Luminous Intensity Iv View Angle Typ. Voltage V F (V) Current I F Infrared Emitter and Flash LED SMD LED Through Hole Lamp LED Display Automotive LED Signage LED Lighting LED Optical Sensors Photocoupler UV LED Detector 98

102 LED Display LED Display Quick View Table Numeric Display Product Type Digit 5.08 mm 7 mm 7.62 mm 8 mm 9 mm Single Digit LTS-2301(CC) LTS-2801(CA) LTS-3361(CC) LTS-3861(CA) LTS-3385(CC) LTS-3885(CA) Dual Digits LTD-2601(CA) LTD-2701(CC) LTD-322(CC) LTD-323(CA) - Through Hole Type Triple Digits LTC-2621(CA) LTC-2721(CC) - - Quadruple Digits LTC-26C7 (CA) LTC-2623(CA) LTC-2723(CC) LTC-2650(CA) LTC-2750(CC) LTC-3710(CC) Quintuple Digits LTF-2606 (CA) LTF-2505 (CA) Single Digit LTS-2307(CC) LTS-2807(CA) LTS-2306(CC) LTS-2806(CA) LTS-3386 (CC) LTS-3886 (CA) SMD Type Dual Digits LTD-2404 (CA) Triple Digits

103 9.14 mm 10 mm 13.2 mm mm 18.4 mm 20 mm 25.4 mm 57 mm LTS-360 (CA) LTS-367 (CC) LTS-4301(CC) LTS-4801(CA) LTS-546(CC) LTS-547(CA) LTS-5x01(CA) LTS-5x03(CC) LTS-10304(CC) LTS-10804(CA) LTS-23305(CC) LTS-23805(CA) LTD-4608(CA) LTD-4708(CC) LTD-5250(CA) LTD-5260(CC) LTD-5x21(CA) LTD-5x23(CC) LTD-6610(CA) LTD-6410(CC) LTD-8302(CC) LTD-8802(CA) - LTC-4624(CA) LTC-4724(CC) LTC-561(CA) LTC-571(CC) LTC-7500(CC) - LTC-4627(CA) LTC-4727(CC) LTC-46D2(CA) LTC-57C7(CC) LTC-5623(CA) LTC-5723(CC) LTC-5653(CA) LTC-5753(CC) - - LTS-4312(CC) LTS-4812(CA) LTS-4317(CC) LTS-4817(CA) LTS-5325(CC) LTS-5825(CA) LTD-4516(CC) LTD-5435(CA) LTC-46F6 (CA) 100

104 Numeric Display_Single Digit 7mm (.28 ) Dual-In-Line.39 H x.29 W x.24 D Part No. Color λ d (nm) Description Typ. Luminous Intensity F =1mA (μcd) LTS-2301AJD Hyper Red LTS-2301AJR Super Red LTS-2301AKF Orange Common Cathode, Rt.Hand Decimal LTS-2301AKS Yellow LTS-2301AKG Yellow Green LTS-2301ATB Blue LTS-2801AJD Hyper Red LTS-2801AJR Super Red LTS-2801AKF Orange Common Anode, Rt.Hand Decimal LTS-2801AKS Yellow LTS-2801AKG Yellow Green LTS-2801ATB Blue LED Catalog

105 Numeric Display_Single Digit Part No. Color λ d (nm) Description LTS-3361JD Hyper Red 639 Typ. Luminous Intensity F =1mA (μcd) LTS-3361JR Super Red LTS-3361JF Orange Common Cathode, Rt.Hand Decimal LTS-3361JS Yellow LTS-3361JG Yellow Green LTS-3361TB Blue LTS-3861JD Hyper Red mm (.3 ) Dual-In-Line.5 H x.3 W x.2 D LTS-3861JR Super Red LTS-3861JF Orange Common Anode, Rt.Hand Decimal LTS-3861JS Yellow LTS-3861JG Yellow Green LTS-3861TB Blue Infrared Emitter and Flash LED SMD LED Through Hole Lamp LED Display Automotive LED Signage LED Lighting LED Optical Sensors Photocoupler UV LED Detector 102

106 Numeric Display_Single Digit 8mm (.32 ) Dual-In-Line.47 H x.32 W x.2 D Part No. Color λ d (nm) Description Typ. Luminous Intensity F =1mA (μcd) LTS-3385KD Hyper Red LTS-3385KR Super Red LTS-3385KF Orange Common Cathode, Rt. Hand Decimal LTS-3385KS Yellow LTS-3385KG Yellow Green LTS-3385TBE Blue LTS-3885KD Hyper Red LTS-3885KR Super Red LTS-3885KF Orange Common Anode, Rt. Hand Decimal LTS-3885KS Yellow LTS-3885KG Yellow Green LTS-3885TBE Blue LED Catalog

107 Numeric Display_Single Digit Part No. Color λ d (nm) Description LTS-360KR Hyper Red 639 Typ. Luminous Intensity F =1mA (μcd) LTS-360KD Super Red LTS-360KF Orange 605 Common Anode, Rt. Hand Decimal 1200 LTS-360KS Yellow LTS-360KG Yellow Green LTS-367KR Hyper Red mm (.36 ) Dual-In-Line.55 H x.3 W x.33 D LTS-367KD Super Red LTS-367KF Orange 605 Common Cathode, Rt. Hand Decimal 1200 LTS-367KS Yellow LTS-367KG Yellow Green Infrared Emitter and Flash LED SMD LED Through Hole Lamp LED Display Automotive LED Signage LED Lighting LED Optical Sensors Photocoupler UV LED Detector 104

108 Numeric Display_Single Digit 10.0mm (.4 ) Dual-In-Line.5 H x.38 W x.27 D Part No. Color λ d (nm) Description Typ. Luminous Intensity F =1mA (μcd) LTS-4301JD Hyper Red LTS-4301JR Super Red LTS-4301JF Orange Common Cathode, Rt.Hand Decimal LTS-4301JS Yellow LTS-4301JG Yellow Green LTS-4301TB Blue LTS-4801JD Hyper Red LTS-4801JR Super Red LTS-4801JF Orange Common Anode, Rt.Hand Decimal LTS-4801JS Yellow LTS-4801JG Yellow Green LTS-4801TB Blue LED Catalog

109 Numeric Display_Single Digit Part No. Color λ d (nm) Description LTS-546AJD Hyper Red 639 Typ. Luminous Intensity F =1mA (μcd) LTS-546AKR Super Red LTS-546AKF Orange Common Anode, Rt.Hand Decimal LTS-546AKS Yellow LTS-546AJG Yellow Green LTS-546TB Blue LTS-547AJD Hyper Red mm (.52 ) Dual-In-Line.7 H x.49 W x.28 D LTS-547AJR Super Red LTS-547AKF Orange Common Cathode, Rt.Hand Decimal LTS-547AKS Yellow LTS-547AJG Yellow Green LTS-547TB Blue Infrared Emitter and Flash LED SMD LED Through Hole Lamp LED Display Automotive LED Signage LED Lighting LED Optical Sensors Photocoupler UV LED Detector 106

110 Numeric Display_Single Digit 14.22mm (.56 ) Dual-In-Line.67 H x.49 W x.32 D Part No. Color λ d (nm) Description Typ. Luminous Intensity F =1mA (μcd) LTS-5001AJD Hyper Red LTS-5001AJR Super Red LTS-5701AKF Orange Common Anode, Rt.Hand Decimal LTS-5701AJS Yellow LTS-5601AJG Yellow Green LTS-5501ATB Blue LTS-5003AJD Hyper Red LTS-5003AJR Super Red LTS-5703AKF Orange Common Cathode, Rt.Hand Decimal LTS-5703AJS Yellow LTS-5603AJG Yellow Green LTS-5503ATB Blue LED Catalog

111 Numeric Display_Single Digit 25.4mm (1.0 ) Dual-In-Line.9 00 H x W x.354 D Part No. Color λ d (nm) Description LTS-10304KD Hyper Red 639 Typ. Luminous Intensity F =1mA (μcd) LTS-10304KR Super Red LTS-10304KF Orange Common Cathode, Rt.Hand Decimal LTS-10304KS Yellow LTS-10304KG Yellow Green LTS-10304TBE Blue LTS-10804KD Hyper Red 639 LTS-10804KR Super Red LTS-10804KF Orange Common Anode, Rt.Hand Decimal LTS-10804KS Yellow LTS-10804KG Yellow Green LTS-10804TBE Blue Infrared Emitter and Flash LED SMD LED Through Hole Lamp LED Display Automotive LED Signage LED Lighting LED Optical Sensors Photocoupler UV LED Detector 108

112 Numeric Display_Single Digit 57mm (2.244 ) Dual-In-Line H x W x.472 D Part No. Color λ d (nm) Description Typ. Luminous Intensity F =1mA (μcd) LTS-23305KD Hyper Red LTS-23305KR Super Red LTS-23305KF Orange 605 Common Cathode, Rt. & Lt. Hand Decimal 10 LTS-23305KS Yellow LTS-23305JG Yellow Green LTS-23805KD Hyper Red LTS-23805KR Super Red LTS-23805KF Orange 605 Common Anode, Rt. & Lt. Hand Decimal 10 LTS-23805KS Yellow LTS-23805JG Yellow Green LED Catalog

113 Numeric Display_Dual Digits Part No. Color λ d (nm) Description LTD-2601JD Hyper Red 639 Typ. Luminous Intensity F =1mA (μcd) LTD-2601KR Super Red LTD-2601KF Orange Duplex Common Anode, Rt.Hand Decimal LTD-2601KS Yellow LTD-2601JG Yellow Green LTD-2601TB Blue LTD-2701JD Hyper Red mm (.28 ) Dual-In-Line.39 H x.59 W x.24 D LTD-2701KR Super Red LTD-2701KF Orange Duplex Common Cathode, Rt.Hand Decimal LTD-2701KS Yellow LTD-2701JG Yellow Green LTD-2701TB Blue Infrared Emitter and Flash LED SMD LED Through Hole Lamp LED Display Automotive LED Signage LED Lighting LED Optical Sensors Photocoupler UV LED Detector 110

114 Numeric Display_Dual Digits 7.62mm (.3 ) Dual-In-Line.59 H x.62 W x.29 D Part No. Color λ d (nm) Description Typ. Luminous Intensity F =1mA (μcd) LTD-322JD Hyper Red LTD-322KR Super Red LTD-322KF Orange Duplex Common Cathode, Rt.Hand Decimal LTD-322KS Yellow LTD-322JG Yellow Green LTD-322TB Blue LTD-323JD Hyper Red LTD-323KR Super Red LTD-323KF Orange Duplex Common Anode, Rt.Hand Decimal LTD-323KS Yellow LTD-323JG Yellow Green LTD-323TB Blue LED Catalog

115 Numeric Display_Dual Digits Part No. Color λ d (nm) Description LTD-4608JD Hyper Red 639 Typ. Luminous Intensity F =1mA (μcd) LTD-4608KR Super Red LTD-4608KF Orange Duplex Common Anode, Rt.Hand Decimal LTD-4608JS Yellow LTD-4608JG Yellow Green LTD-4608TB Blue LTD-4708JD Hyper Red mm (.4 ) Dual-In-Line.5 H x.78 W x.28 D LTD-4708KR Super Red LTD-4708KF Orange Duplex Common Cathode, Rt.Hand Decimal LTD-4708JS Yellow LTD-4708JG Yellow Green LTD-4708TB Blue Infrared Emitter and Flash LED SMD LED Through Hole Lamp LED Display Automotive LED Signage LED Lighting LED Optical Sensors Photocoupler UV LED Detector 112

116 Numeric Display_Dual Digits 13.2mm (.52 ) Dual-In-Line.69 H x99 W x.28 D Part No. Color λ d (nm) Description Typ. Luminous Intensity F =1mA (μcd) LTD-5250JD Hyper Red LTD-5250KR Super Red LTD-5250KF Orange Common Anode, Rt.Hand Decimal LTD-5250KS Yellow LTD-5250KG Yellow Green LTD-5250TB Blue LTD-5260KD Hyper Red LTD-5260KR Super Red LTD-5260KF Orange Common Cathode, Rt.Hand Decimal LTD-5260KS Yellow LTD-5260KG Yellow Green LTD-5260TB Blue LED Catalog

117 Numeric Display_Dual Digits Part No. Color λ d (nm) Description LTD-5021AJD Hyper Red 639 Typ. Luminous Intensity F =1mA (μcd) LTD-5521AJR Super Red LTD-5721AKF Orange Common Anode, Rt.Hand Decimal LTD-5721AJS Yellow LTD-5621AJG Yellow Green LTD-5021TB Blue LTD-5023AJD Hyper Red mm (.56 ) Dual-In-Line.67 H x.98 W x.32 D LTD-5523AJR Super Red LTD-5723AKF Orange Common Cathode, Rt.Hand Decimal LTD-5723AJS Yellow LTD-5623AJG Yellow Green LTD-5023TB Blue Infrared Emitter and Flash LED SMD LED Through Hole Lamp LED Display Automotive LED Signage LED Lighting LED Optical Sensors Photocoupler UV LED Detector 114

118 Numeric Display_Dual Digits 14.22mm (.56 ) Dual-In-Line.75 H x.98 W x.32 D Part No. Color λ d (nm) Description Typ. Luminous Intensity F =1mA (μcd) LTD-6410KD Hyper Red LTD-6410KR Super Red LTD-6410KF Orange Common Cathode, Rt.Hand Decimal LTD-6410KS Yellow LTD-6410KG Yellow Green LTD-6410TB Blue LTD-6610KD Hyper Red LTD-6610KR Super Red LTD-6610KF Orange Common Anode, Rt.Hand Decimal LTD-6610KS Yellow LTD-6610KG Yellow Green LTD-6610TB Blue LED Catalog

119 Numeric Display_Dual Digits Part No. Color λ d (nm) Description LTD-8302KR Hyper Red 639 Typ. Luminous Intensity F =1mA (μcd) LTD-8302KF Super Red LTD-8302KS Orange Duplex Common Cathode, Rt.Hand Decimal LTD-8302KG Yellow LTD-8302KD Yellow Green LTD-8302TB Blue LTD-8802KR Hyper Red mm (.79 ) Dual-In-Line 1.0 H x 1.4 W x.39 D LTD-8802KF Super Red LTD-8802KS Orange Duplex Common Anode, Rt.Hand Decimal LTD-8802KG Yellow LTD-8802KD Yellow Green LTD-8802TB Blue Infrared Emitter and Flash LED SMD LED Through Hole Lamp LED Display Automotive LED Signage LED Lighting LED Optical Sensors Photocoupler UV LED Detector 116

120 Numeric Display_Triple Digits 7.0mm (.28 ) Dual-In-Line.39 H x.89 W x.24 D Part No. Color λ d (nm) Description Typ. Luminous Intensity F =1mA (μcd) LTC-2621JD Hyper Red LTC-2621JR Super Red LTC-2621KF Orange Multiplex Common Anode, Rt.Hand Decimal LTC-2621KS Yellow LTC-2621JG Yellow Green LTC-2621TB Blue LTC-2721JD Hyper Red LTC-2721JR Super Red LTC-2721KF Orange Multiplex Common Cathode, Rt.Hand Decimal LTC-2721KS Yellow LTC-2721JG Yellow Green LTC-2721TB Blue LED Catalog

121 Numeric Display_Triple Digits 10.0mm (.40 ) Dual-In-Line.5 H x 1.18 W x.276 D Part No. Color λ d (nm) Description LTC-4624JD Hyper Red 639 Typ. Luminous Intensity F =1mA (μcd) LTC-4624JR Super Red LTC-4624KF Orange Multiplex Common Anode, Rt.Hand Decimal LTC-4624KS Yellow LTC-4624JG Yellow Green LTC-4624TB Blue LTC-4724JD Hyper Red 639 LTC-4724JR Super Red LTC-4724KF Orange Multiplex Common Cathode, Rt.Hand Decimal LTC-4724KS Yellow LTC-4724JG Yellow Green LTC-4724TB Blue Infrared Emitter and Flash LED SMD LED Through Hole Lamp LED Display Automotive LED Signage LED Lighting LED Optical Sensors Photocoupler UV LED Detector 118

122 Numeric Display_Triple Digits 14.22mm (.56 ) Dual-In-Line.75 H x 1.5 W x.32 D Part No. Color λ d (nm) Description Typ. Luminous Intensity F =1mA (μcd) LTC-561JD Hyper Red LTC-561KR Super Red LTC-561KF Orange Multiplex Common Anode, Rt.Hand Decimal LTC-561KS Yellow LTC-561JG Yellow Green LTC-561TB Blue LTC-571JD Hyper Red LTC-571KR Super Red LTC-571KF Orange Multiplex Common Cathode, Rt.Hand Decimal LTC-571KS Yellow LTC-571JG Yellow Green LTC-571TB Blue LED Catalog

123 Numeric Display_Triple Digits 18.4mm (.72 ) Dual-In-Line.87 H x 1.8 W x.5 D Part No. Color λ d (nm) Description LTC-7500KD Hyper Red 639 DIGIT 1 A F B G E C D DP DIGIT 1 28,3 A B C D E F G DP Typ. Luminous Intensity F =1mA (μcd) LTC-7500KR Super Red LTC-7500KF Orange 605 Multiplex Common Cathode, Rt.Hand Decimal 650 LTC-7500KS Yellow LTC-7500KG Yellow Green Numeric Display_Quadruple Digits 5.08mm (.2 ) Dual-In-Line.39 H x.79 W x.22 D Part No. Color λ d (nm) Description DIGIT 2 DIGIT 3 DIGIT 2 23,8 A B C D E F G DP DIGIT 1 18,13 A B C D E F G DP Typ. Luminous Intensity F =1mA (μcd) LTC-26C7KD-02 Hyper Red 639 Multiplex Common Anode 900 Infrared Emitter and Flash LED SMD LED Through Hole Lamp LED Display Automotive LED Signage LED Lighting LED Optical Sensors Photocoupler UV LED Detector 120

124 Numeric Display_Quadruple Digits 7.0mm (.28 ) Dual-In-Line.39 H x 1.19 W x.24 D Part No. Color λ d (nm) Description Typ. Luminous Intensity F =1mA (μcd) LTC-2623JD Hyper Red LTC-2623JR Super Red LTC-2623JF Orange Multiplex Common Anode, Rt.Hand Decimal LTC-2623JS Yellow LTC-2623JG Yellow Green LTC-2623TB Blue LTC-2723JD Hyper Red LTC-2723JR Super Red LTC-2723JF Orange Multiplex Common Cathode, Rt.Hand Decimal LTC-2723JS Yellow LTC-2723JG Yellow Green LTC-2723TB Blue LED Catalog

125 Numeric Display_Quadruple Digits Part No. Color λ d (nm) Description LTC-2650KD Hyper Red 639 Typ. Luminous Intensity F =1mA (μcd) LTC-2650KR Super Red LTC-2650KF Orange Multiplex Common Anode, Rt.Hand Decimal LTC-2650KS Yellow LTC-2650JG Yellow Green LTC-2650TBE Blue LTC-2750KD Hyper Red mm (.28 ) Dual-In-Line.39 H x 1.19 W x.24 D LTC-2750KR Super Red LTC-2750KF Orange Multiplex Common Cathode, Rt.Hand Decimal LTC-2750KS Yellow LTC-2750JG Yellow Green LTC-2750TBE Blue Infrared Emitter and Flash LED SMD LED Through Hole Lamp LED Display Automotive LED Signage LED Lighting LED Optical Sensors Photocoupler UV LED Detector 122

126 Numeric Display_Quadruple Digits Epoxy Type 7.62mm (.30 ) Dual-In-Line.52 H x 1.2 W x.28 D Part No. Color λ d (nm) Description Typ. Luminous Intensity F =1mA (μcd) LTC-3710KD Red Multiplex Common Cathode, Full Feature LTC-3710KG Yellow Green Numeric Display_Quadruple Digits Epoxy Type 8.5mm (.34 ) Dual-In-Line.54 H x 1.38 W x.24 D Part No. Color λ d (nm) Description Typ. Luminous Intensity F =1mA (μcd) LTC-3718KD Red Multiplex Common Cathode, Full Feature LTC-3718KG Yellow Green LED Catalog

127 Numeric Display_Quadruple Digits Part No. Color λ d (nm) Description LTC-4627JD Hyper Red 639 Typ. Luminous Intensity F =1mA (μcd) LTC-4627JR Super Red LTC-4627JF Orange Multiplex Common Anode, Rt.Hand Decimal LTC-4627JS Yellow LTC-4627JG Yellow Green LTC-4627TB Blue LTC-4727JD Hyper Red mm (.40 ) Dual-In-Line.5 H x 1.58 W x.28 D LTC-4727JR Super Red LTC-4727JF Orange Multiplex Common Cathode, Rt.Hand Decimal LTC-4727JS Yellow LTC-4727JG Yellow Green LTC-4727TB Blue Infrared Emitter and Flash LED SMD LED Through Hole Lamp LED Display Automotive LED Signage LED Lighting LED Optical Sensors Photocoupler UV LED Detector 124

128 Numeric Display_Quadruple Digits 10mm (.39 ) Dual-In-Line.63 H x 1.73 W x.15 D Part No. Color CIE (x,y) Description Typ. Luminous Intensity F =5mA (μcd) LTC-46D2SW White (0.294,0.286) Multiplex Common Anode Numeric Display_Quadruple Digits 14.2mm (.56 ) Dual-In-Line.75 H x 1.98 W x.32 D Part No. Color λ d (nm) Description Typ. Luminous Intensity F =10mA (μcd) LTC-57C7KD Hyper Red LTC-57C7KR Super Red LTC-57C7KF Orange 605 Multiplex Common Cathode 1600 LTC-57C7KS Yellow LTC-57C7KG Yellow Green LED Catalog

129 Numeric Display_Quadruple Digits Part No. Color λ d (nm) Description LTC-5623JD Hyper Red 639 Typ. Luminous Intensity F =1mA (μcd) LTC-5623KR Super Red LTC-5623KF Orange Multiplex Common Anode, Rt.Hand Decimal LTC-5623KS Yellow LTC-5623JG Yellow Green LTC-5623TB Blue LTC-5723JD Hyper Red mm (.56 ) Dual-In-Line.75 H x 1.98 W x.32 D LTC-5723KR Super Red LTC-5723KF Orange Multiplex Common Cathode, Rt.Hand Decimal LTC-5723KS Yellow LTC-5723JG Yellow Green LTC-5723TB Blue Infrared Emitter and Flash LED SMD LED Through Hole Lamp LED Display Automotive LED Signage LED Lighting LED Optical Sensors Photocoupler UV LED Detector 126

130 Numeric Display_Quadruple Digits 14.22mm (.56 ) Dual-In-Line.75 H x 1.98 W x.32 D Part No. Color λ d (nm) Description Typ. Luminous Intensity F =1mA (μcd) LTC-5653KD-01 Hyper Red LTC-5653KR-01 Super Red LTC-5653KF-01 Orange Multiplex Common Anode, Rt.Hand Decimal LTC-5653KS-01 Yellow LTC-5653KG-01 Yellow Green LTC-5653TB-01 Blue LTC-5753KD-01 Hyper Red LTC-5753KR-01 Super Red LTC-5753KF-01 Orange Multiplex Common Cathode, Rt.Hand Decimal LTC-5753KS-01 Yellow LTC-5753KG-01 Yellow Green LTC-5753TB-01 Blue LED Catalog

131 Numeric Display_Quintuple Digits 5.08mm (.2 ) Dual-In-Line.43 H x.98 W x.19 D Part No. Color λ d (nm) Description LTF-2606KD Hyper Red 639 Typ. Luminous Intensity F =1mA (μcd) LTF-2606KR Super Red LTF-2606KF Orange 605 Multiplex Common Anode, Rt.Hand Decimal 1600 LTF-2606KS Yellow LTF-2606KG Yellow Green Numeric Display_Quintuple Digits Part No. Color λ d (nm) Description LTF-2505KD Hyper Red mm (.26 ) Dual-In-Line.39 H x 1.18 W x.24 D 700 Typ. Luminous Intensity F =1mA (μcd) LTF-2505KR Super Red LTF-2505KF Orange 605 Multiplex Common Anode, Rt.Hand Decimal 1600 LTF-2505KS Yellow Infrared Emitter and Flash LED SMD LED Through Hole Lamp LED Display Automotive LED Signage LED Lighting LED Optical Sensors Photocoupler UV LED Detector LTF-2505KG Yellow Green

132 Numeric Display_SMD Type 5.08mm (.2 ) Dual-in-Line.39 H x.27 W x.12 D Part No. Color λ d (nm) Description Typ. Luminous Intensity F =2mA (μcd) LTS-2307CKD-P Hyper Red LTS-2307CKR-P Super Red LTS-2307CKF-P Orange Common Cathode LTS-2307CKS-P Yellow LTS-2307CKG-P Yellow Green LTS-2307TBE-P Blue LTS-2807CKG-P Yellow Green LTS-2807CKD-P Hyper Red LTS-2807CKR-P Super Red Common Anode LTS-2807CKF-P Orange LTS-2807CKS-P Yellow LTS-2807TBE-P Blue LED Catalog

133 Numeric Display_SMD Type Part No. Color λ d (nm) Description LTS-2306CKD-P Hyper Red 639 Typ. Luminous Intensity F =2mA (μcd) LTS-2306CKR-P Super Red LTS-2306CKF-P Orange Common Cathode LTS-2306CKS-P Yellow LTS-2306CKG-P Yellow Green LTS-2306TBE-P Blue LTS-2806CKD-P Hyper Red 639 7mm (.28 ) Dual-in-Line.43 H x.29 W x.17 D LTS-2806CKR-P Super Red LTS-2806CKF-P Orange Common Anode LTS-2806CKS-P Yellow LTS-2806CKG-P Yellow Green LTS-2806TBE-P Blue Infrared Emitter and Flash LED SMD LED Through Hole Lamp LED Display Automotive LED Signage LED Lighting LED Optical Sensors Photocoupler UV LED Detector 130

134 Numeric Display_SMD Type 7.62mm (.3 ) Dual-in-Line.47 H x.28 W x.14 D Part No. Color λ d (nm) Description Typ. Luminous Intensity F =1mA (μcd) LTS-3386CKD-P Hyper Red LTS-3386CKR-P Super Red LTS-3386CKF-P Orange Common Cathode LTS-3386CKS-P Yellow LTS-3386CKG-P Yellow Green LTS-3386CTB-P Blue LTS-3886CKD-P Hyper Red LTS-3886CKR-P Super Red LTS-3886CKF-P Orange Common Anode LTS-3886CKS-P Yellow LTS-3886CKG-P Yellow Green LTS-3886CTB-P Blue LED Catalog

135 Numeric Display_SMD Type Part No. Color λ d (nm) Description LTS-4312CKD-PM Hyper Red 639 Typ. Luminous Intensity F =2mA (μcd) LTS-4312CKR-PM Super Red LTS-4312CKF-PM Orange Common Cathode LTS-4312CKS-PM Yellow LTS-4312CKG-PM Yellow Green LTS-4312TBE-PM Blue LTS-4812CKD-PM Hyper Red mm (.4 ) Dual-in-Line.59 H x.39 W x.15 D LTS-4812CKR-PM Super Red LTS-4812CKF-PM Orange Common Anode LTS-4812CKS-PM Yellow LTS-4812CKG-PM Yellow Green LTS-4812TBE-PM Blue Infrared Emitter and Flash LED SMD LED Through Hole Lamp LED Display Automotive LED Signage LED Lighting LED Optical Sensors Photocoupler UV LED Detector 132

136 Numeric Display_SMD Type 10mm (.4 ) Dual-in-Line.63 H x.39 W x.08 D Part No. Color λ d (nm) Description Typ. Luminous Intensity F =2mA (μcd) LTS-4317CKD-P Hyper Red LTS-4317CKR-P Super Red LTS-4317CKF-P Orange Common Cathode LTS-4317CKS-P Yellow LTS-4317CKG-P Yellow Green LTS-4317TBE-P Blue LTS-4817CKD-P Hyper Red LTS-4817CKR-P Super Red LTS-4817CKF-P Orange Common Anode LTS-4817CKS-P Yellow LTS-4817CKG-P Yellow Green LTS-4817TBE-P Blue LED Catalog

137 Numeric Display_SMD Type Part No. Color λ d (nm) Description LTS-5325CKD-P Hyper Red 639 Typ. Luminous Intensity F =2mA (μcd) LTS-5325CKR-P Super Red LTS-5325CKF-P Orange Common Cathode LTS-5325CKS-P Yellow LTS-5325CKG-P Yellow Green LTS-5325TBE-P Blue LTS-5825CKD-P Hyper Red mm (.56 ) Dual-in-Line.75 H x.49 W x.15 D LTS-5825CKR-P Super Red LTS-5825CKF-P Orange Common Anode LTS-5825CKS-P Yellow LTS-5825CKG-P Yellow Green LTS-5825TBE-P Blue Infrared Emitter and Flash LED SMD LED Through Hole Lamp LED Display Automotive LED Signage LED Lighting LED Optical Sensors Photocoupler UV LED Detector 134

138 Numeric Display_SMD Type 5.08mm (.2 ) Dual-In-Line.39 H x.56 W x.12 D Part No. Color λ d (nm) Description Typ. Luminous Intensity F =1mA (μcd) LTD-2404CKD-P Hyper Red LTD-2404CKR-P Super Red LTD-2404CKF-P Orange Common Anode LTD-2404CKS-P Yellow LTD-2404CKG-P Yellow Green LTD-2404SW-P White LED Catalog

139 Numeric Display_SMD Type Part No. Color λ d (nm) Description LTD-4516CKD-PM Hyper Red mm (.4 ) Dual-In-Line.59 H x.78 W x.15 D Typ. Luminous Intensity F =2mA (μcd) LTD-4516CKR-PM Super Red LTD-4516CKF-PM Orange Multiplexed, Common Cathode LTD-4516CKS-PM Yellow LTD-4516CKG-PM Yellow Green LTD-4516TBE-PM Blue Infrared Emitter and Flash LED SMD LED Through Hole Lamp LED Display Automotive LED Signage LED Lighting LED Optical Sensors Photocoupler UV LED Detector 136

140 Numeric Display_SMD Type 14.22mm (.56 ) Dual-In-Line.79 H x.98 W x.09 D Part No. Color λ d (nm) Description Typ. Luminous Intensity F =2mA (μcd) LTD-5435CKD-P Hyper Red LTD-5435CKR-P Super Red LTD-5435CKF-P Orange Multiplex Common Anode LTD-5435CKS-P Yellow LTD-5435CKG-P Yellow Green LTD-5435TBE-P Blue LED Catalog

141 Numeric Display_SMD Type 10mm (.4 ) Dual-In-Line.62 H x 1.16 W x.09 D Part No. Color λ d (nm) Description LTC-46F6CKD-P Hyper Red 639 Typ. Luminous Intensity F =1mA (μcd) LTC-46F6CKR-P Super Red LTC-46F6CKF-P Orange Multiplex Common Anode LTC-46F6CKS-P Yellow LTC-46F6CKG-P Yellow Green LTC-46F6TB-P Blue Infrared Emitter and Flash LED SMD LED Through Hole Lamp LED Display Automotive LED Signage LED Lighting LED Optical Sensors Photocoupler UV LED Detector 138

142 Alphanumeric Display 12.7mm (.5 ) Dual-In-Line 1 H x.63 W x.38 D Part No. Color λ d (nm) Description Typ. Luminous Intensity F =1mA (μcd) LTP-537KD Hyper Red LTP-537KR Super Red LTP-537KS Orange 605 Common Cathode, Single, Dual Character, Rt. Hand Decimal 1600 LTP-537KF Yellow LTP-537KG Yellow Green LTP-587KD Hyper Red LTP-587KR Super Red LTP-587KS Orange 605 Common Anode, Single, Dual Character, Rt. Hand Decimal 1600 LTP-587KF Yellow LTP-587KG Yellow Green LED Catalog

143 Alphanumeric Display Part No. Color λ d (nm) Description LTP-3362JD Hyper Red 639 Typ. Luminous Intensity F =1mA (μcd) LTP-3362JR Super Red LTP-3362JS Orange 605 Common Cathode, Duplex, Dual Character, Rt. Hand Decimal 1200 LTP-3362JF Yellow LTP-3362JG Yellow Green LTP-3862JD Hyper Red mm (.3 ) Dual-In-Line.51 H x.67 W x.24 D LTP-3862JR Super Red LTP-3862JS Orange 605 Common Anode, Duplex, Dual Character, Rt. Hand Decimal 1200 LTP-3862JF Yellow LTP-3862JG Yellow Green Infrared Emitter and Flash LED SMD LED Through Hole Lamp LED Display Automotive LED Signage LED Lighting LED Optical Sensors Photocoupler UV LED Detector 140

144 Alphanumeric Display 10.4mm (.4 ) Dual-In-Line.63 H x.8 W x.28 D Part No. Color λ d (nm) Description Typ. Luminous Intensity F =1mA (μcd) LTP-4323JD Hyper Red LTP-4323KR Super Red LTP-4323KS Orange 605 Common Cathode, Duplex, Dual Character, Rt. Hand Decimal 1300 LTP-4323KF Yellow LTP-4323JG Yellow Green LTP-4823JD Hyper Red LTP-4823KR Super Red LTP-4823KS Orange 605 Common Anode, Duplex, Dual Character, Rt. Hand Decimal 1300 LTP-4823KF Yellow LTP-4823JG Yellow Green LED Catalog

145 Alphanumeric Display Part No. Color λ d (nm) Description LTP-3784KD-01 Hyper Red 639 Typ. Luminous Intensity F =1mA (μcd) LTP-3784KR-01 Super Red LTP-3784KF-01 Orange 605 Common Cathode, Duplex, Dual Character, Rt. Hand Decimal 1600 LTP-3784KS-01 Yellow LTP-3784JG-01 Yellow Green LTP-3786KD-01 Hyper Red mm (.54 ) Dual-In-Line.84 H x 1 W x.32 D LTP-3786KR-01 Super Red LTP-3786KF-01 Orange 605 Common Anode, Duplex, Dual Character, Rt. Hand Decimal 1600 LTP-3786KS-01 Yellow LTP-3786JG-01 Yellow Green Infrared Emitter and Flash LED SMD LED Through Hole Lamp LED Display Automotive LED Signage LED Lighting LED Optical Sensors Photocoupler UV LED Detector 142

146 Alphanumeric Display_SMD Type 10.16mm (.4 ) Dual-In-Line.75 H x.36 W x.15 D Part No. Color λ d (nm) Description Typ. Luminous Intensity F =1mA (μcd) LTP-4824CKD-P Hyper Red LTP-4824CKR-P Super Red LTP-4824CKF-P Orange 605 Common Anode 1050 LTP-4824CKS-P Yellow LTP-4824CKG-P Yellow Green Alphanumeric Display_SMD Type 7.62mm (.3 ) Dual-In-Line.44 H x.67 W x.15 D Part No. Color λ d (nm) Description Typ. Luminous Intensity F =1mA (μcd) LTP-3363CKD-P Hyper Red LTP-3363CKR-P Super Red LTP-3363CKF-P Orange 605 Multiplex Common Cathode, Rt.Hand Decimal 650 LTP-3363CKS-P Yellow LTP-3363CKG-P Yellow Green LED Catalog

147 Dot Matrix_5X7 Single Color Part No. Color λ d (nm) Description LTP-747KD Hyper Red 639 LTP-747KR Super Red 631 LTP-747KF Orange 605 LTP-747KS Yellow 587 LTP-747KG Yellow Green 572 LTP-757KD Hyper Red 639 LTP-757KR Super Red 631 LTP-757KF Orange 605 LTP-757KS Yellow 587 LTP-757KG Yellow Green mm (2φ) Dual-In-Line.7 H x.5 W x.25 D Typ.Iv/Dot@I p =32mA 1/16 Duty (μcd) Anode Column, Cathode Row 2300 Cathode Column, Anode Row 2300 Infrared Emitter and Flash LED SMD LED Through Hole Lamp LED Display Automotive LED Signage LED Lighting LED Optical Sensors Photocoupler UV LED Detector 144

148 Dot Matrix_5X7 Single Color 31.79mm (3φ) Dual-In-Line 1.25 H x.9 W x.31 D Part No. Color λ d (nm) Description Typ.Iv/Dot@I p =32mA 1/16 Duty (μcd) LTP-1457KD Hyper Red 639 LTP-1457KR Super Red 631 LTP-1457KF Orange 605 Anode Column, Cathode Row 4500 LTP-1457KS Yellow 587 LTP-1457KG Yellow Green 572 LTP-1557KD Hyper Red 639 LTP-1557KR Super Red 631 LTP-1557KF Orange 605 Cathode Column, Anode Row 4500 LTP-1557KS Yellow 587 LTP-1557KG Yellow Green 572 LTP-1557TBE Blue 470 Cathode Column, Anode Row 1350@I p =10mA 145 LED Catalog

149 Dot Matrix_5X7 Single Color Part No. Color λ d (nm) Description LTP-2057AKA Super Orange 615 Typ.Iv/Dot@I p =32mA 1/16 Duty (μcd) LTP-2057AKY Amber Yellow 592 Anode Column, Cathode Row 4600 LTP-2057AKR Super Red LTP-2157AKA Super Orange mm (5φ) Dual-In-Line 2.1 H x 1.5 W x.34 D LTP-2157AKY Amber Yellow 592 Cathode Column, Anode Row 4600 LTP-2157AKR Super Red Infrared Emitter and Flash LED SMD LED Through Hole Lamp LED Display Automotive LED Signage LED Lighting LED Optical Sensors Photocoupler UV LED Detector 146

150 Dot Matrix_5X8 Single Color 37.4mm (3φ) Dual-In-Line 1.47 H x.9 W x.31 D Part No. Color λ d (nm) Description Typ.Iv/Dot@I p =32mA 1/16 Duty (μcd) LTP-14058AKD Hyper Red 639 LTP-14058AKR Super Red 631 LTP-14058AKF Orange 605 Anode Column, Cathode Row 4500 LTP-14058AKS Yellow 587 LTP-14058AKG Yellow Green 572 LTP-14158AKD Hyper Red 639 LTP-14158AKR Super Red 631 LTP-14158AKF Orange 605 Cathode Column, Anode Row 4500 LTP-14158AKS Yellow 587 LTP-14158AKG Yellow Green LED Catalog

151 Dot Matrix_5X8 Single Color Part No. Color λ d (nm) Description LTP-2058AKD Hyper Red 639 LTP-2058AKR Super Red 631 LTP-2058AKF Orange 605 LTP-2058AKS Yellow 587 LTP-2058AKG Yellow Green 572 LTP-2158AKD Hyper Red 639 LTP-2158AKR Super Red 631 LTP-2158AKF Orange 605 LTP-2158AKS Yellow 587 LTP-2158AKG Yellow Green mm (5φ) Dual-In-Line 2.4 H x 1.5 W x.35 D Typ.Iv/Dot@I p =32mA 1/16 Duty (μcd) Anode Column, Cathode Row 4910 Cathode Column, Anode Row 4910 Infrared Emitter and Flash LED SMD LED Through Hole Lamp LED Display Automotive LED Signage LED Lighting LED Optical Sensors Photocoupler UV LED Detector 148

152 Dot Matrix_8X8 Single Color 20mm (1.9φ) Dual-In-Line.8 H x.8 W x.24 D Part No. Color λ d (nm) Description Typ.Iv/Dot@I p =32mA 1/16 Duty (μcd) LTP-7188KD Hyper Red 639 LTP-7188KR Super Red 631 LTP-7188KF Orange 605 Anode Row, Cathode Column 2300 LTP-7188KS Yellow 587 LTP-7188KG Yellow Green 572 Dot Matrix_8X8 Single Color 48mm (5φ) Dual-In-Line 1.26 H x 1.26 W x.32 D Part No. Color λ d (nm) Description Typ.Iv/Dot@I p =32mA 1/16 Duty (μcd) LTP-12788KD Hyper Red 639 LTP-12788KR Super Red 631 LTP-12788KF Orange 605 Anode Row, Cathode Column 2300 LTP-12788KS Yellow 587 LTP-12788KG Yellow Green LED Catalog

153 Dot Matrix_8X8 Single Color Part No. Color λ d (nm) Description LTP-18088KD Hyper Red 639 LTP-18088KR Super Red 631 LTP-18088KF Orange 605 LTP-18088KS Yellow 587 LTP-18088KG Yellow Green mm (5φ) Dual-In-Line 1.9 H x 1.9 W x.35 D Typ.Iv/Dot@I p =32mA 1/16 Duty (μcd) Anode Column, Cathode Row 4910 Infrared Emitter and Flash LED SMD LED Through Hole Lamp LED Display Automotive LED Signage LED Lighting LED Optical Sensors Photocoupler UV LED Detector 150

154 Dot Matrix_8X8 Multi Color 20.2mm (2.0φ) Multi-In-Line.8 H x.8 W x.24 D Part No. Color λ d (nm) Description Typ.Iv/Dot@I p =10mA (μcd) Super Red LTP-7488SF True Green 525 Anode Column, Cathode Row Blue LTP-7588SF Super Red True Green 525 Cathode Column, Anode Row Blue LED Catalog

155 Dot Matrix_16X16 Single Color 40mm (2.0φ) Multi-In-Line 1.59 H x 1.59 W x.07 D Part No. Color λ d (nm) Description 40mm (1.7φ) Dual-In-Line 1.57 H x 1.57 W x.14 D Typ.Iv/Dot@I p =28mA 1/16 Duty (μcd) LTP-158FFKF Orange 605 Anode Row, Cathode Column 1960 Dot Matrix_16X16 Single Color Part No. Color λ d (nm) Description Typ.Iv/Dot@I p =25mA 1/16 Duty (µcd) LTP-159FFKF Orange 605 Anode Row, Cathode Column 1240 Infrared Emitter and Flash LED SMD LED Through Hole Lamp LED Display Automotive LED Signage LED Lighting LED Optical Sensors Photocoupler UV LED Detector 152

156 Dot Matrix_16X16 Single Color 48mm (2.4φ) Mulit-In-Line 1.89 H x 1.89 W x.17 D Part No. Color λ d (nm) Description Typ.Iv/Dot@I p =60mA 1/16 Duty (µcd) LTP-185FFMKD-J Hyper Red 639 Anode Row, Cathode Column 1500 Dot Matrix_16X16 Single Color 56.4mm (3.0φ) Dual-In-Line 2.22 H x 2.22 W x.07 D Part No. Color λ d (nm) Description Typ.Iv/Dot@I p =35mA 1/16 Duty (µcd) LTP-229FFKF Orange 605 Anode Row, Cathode Column 2300µcd 153 LED Catalog

157 Light Bar Array Part No. Color λ d (nm) Description LTA-1000KD Hyper Red Pin DIP.100 Centers.96 L x.40 W x.32 H Typ. Luminous Intensity Iv@10mA LTA-1000KR Super Red LTA-1000KF Orange 605 Universal Rectangular Bar 16 LTA-1000KS Yellow Green LTA-1000KG Yellow Green Infrared Emitter and Flash LED SMD LED Through Hole Lamp LED Display Automotive LED Signage LED Lighting LED Optical Sensors Photocoupler UV LED Detector 154

158 Light Bar Array 4 Pin DIP.39 H x.19 W x.24 D Part No. Color λ d (nm) Description Typ. Luminous Intensity Iv@10mA LTL-2300HR Red LTL-2400Y Yellow 588 Universal Rectangular Bar 4.2 LTL-2500G Yellow Green Light Bar Array 8 Pin DIP.2 Centers.39 H x.39 W x.24 D Part No. Color λ d (nm) Description Typ. Luminous Intensity Iv@10mA LTL-2800G Yellow Green 569 Universal Rectangular Bar LED Catalog

159 Light Bar Array Part No. Color λ d (nm) Description LTL-2655JD Hyper Red Pin DIP.39 H x.39 W x.24 D Typ. Luminous Intensity Iv@10mA LTL-2655HR Red 623 Universal Rectangular Bar 8 LTL-2755Y Yellow LTL-2855G Yellow Green Light Bar Array Part No. Color λ d (nm) Description LTL-4201M 4 Pin DIP.05 Centers.39 H x.19 W x.24 D 1.8 Typ. Luminous Intensity Iv@10mA Red Universal Rectangular Bar Amber Yellow Infrared Emitter and Flash LED SMD LED Through Hole Lamp LED Display Automotive LED Signage LED Lighting LED Optical Sensors Photocoupler UV LED Detector 156

160 Light Bar Array 16 Pin DIP.2 Centers.79 H x.39 W x.24 D Part No. Color λ d (nm) Description Typ. Luminous Intensity Iv@10mA LTL-2720Y Yellow LTL-2820G Yellow Green Universal Rectangular Bar Red Orange LTL-2620M Yellow LED Display Module Epoxy Type 14.2mm (.56 ) Single-In-Line.75 H x 1.98 W x.32 D Part No. Color λ d (nm) Description Typ.Iv/Seg@I F =10mA (µcd) Current I F LTM-0735G Green Multiplex with IC Driver LTM-0735SW White (0.294, 0.286) LED Catalog

161 LED Display Module Part No. Color λ d (nm) Description I F =25mA, 1/8 Duty (µcd) LTM-1008M LED Display Module 10.2mm (.4 ) Single-In-Line.94 H x 1.69 W x.27 D Super Red Multiplex Common Anode Blue x 32 Matrix Pitch H x 7.56 W x.43 D Part No. Color λ d (nm) Description Typ.Iv/Dot@I F =20mA LTM-1524KS Amber Yellow 595 Multiplex with IC Driver 2.4 Infrared Emitter and Flash LED SMD LED Through Hole Lamp LED Display Automotive LED Signage LED Lighting LED Optical Sensors Photocoupler UV LED Detector 158

162 LED Display Module 16 x 48 Matrix Pitch H x 4.72 W x.06 D Part No. Color λ d (nm) Description Typ.Iv/Seg@I F =10mA LTM-1302SM Super Red Multiplex with IC Driver Yellow Green LED Catalog

163 Automotive LED

164 0603 Chip LED Interior 1.6 x 0.8 x 0.55 mm Part No. Color λ d (nm)/ CIE(x,y) Typ. Luminous Intensity Iv View Angle Typ. Voltage V F (V) Current I F Thermal Resistance R th (j-s) ( C/W) Max. Current I F Max. Junction Temperature Tj( C) Operating Temperature Range( C) LTSA-C191KEKT Red ~85 LTSA-C191KSKT Yellow ~85 LTSA-C191TGK5 True Green ~85 LTSA-C191TBK5 Blue ~85 LTSA-W191DBS5 Cool White (0.303, 0.317) ~ Chip LED Interior 2.0 x 1.25 x 1.1 mm Part No. Color λ d (nm)/ CIE(x,y) Typ. Luminous Intensity Iv View Angle Typ. Voltage V F (V) Current I F Thermal Resistance R th (j-s) ( C/W) Max. Current I F Max. Junction Temperature Tj( C) Operating Temperature Range( C) LTSA-C170KEKT Red ~85 LTSA-C170KSKT Yellow ~85 LTSA-C170TGKT True Green ~85 LTSA-C170TBKT Blue ~85 LTSA-W170ZTBAT-WT Ice Blue (0.201, 0.290) ~85 LTSA-W170DBC5 Cool White (0.297, 0.310) ~ LED Catalog

165 1206 Chip LED Interior Part No. 3.2 x 0.8 x 1.1 mm Color λ d (nm)/ CIE(x,y) Typ. Luminous Intensity Iv View Angle Typ. Voltage V F (V) Current I F Thermal Resistance R th (j-s) ( C/W) Max. Current I F Max. Junction Temperature Tj( C) Operating Temperature Range( C) LTSA-C150KEKT Red ~85 LTSA-C150KSKT Yellow ~85 LTSA-C150TGK5 True Green ~85 LTSA-C150TBK5 Blue ~85 LTSA-W150TBA5 Bright Cyan (0.226, 0.314) ~85 LTSA-C150TBV5 Soft Blue (0.260, 0.227) ~85 LTSA-C150TBW5 Cool White (0.299, 0.298) ~85 Mini Top LED Part No. 2.3x1.4x1.3 mm Color λ d (nm)/ CIE(x,y) Typ. Luminous Intensity Iv View Angle Typ. Voltage V F (V) Current I F Thermal Resistance R th (j-s) ( C/W) Max. Current I F Max. Junction Temperature Tj( C) Operating Temperature Range( C) LTSA-M67KKEWT Red ~100 LTSA-M67KKSWT Yellow ~100 LTSA-M67KTGWT True Green ~100 LTSA-M67KTBWT Blue ~100 LTSA-M67KTHET Ice Blue (0.190, 0.276) ~100 LTSA-M67KTWET Cool White (0.300, 0.300) ~100 New Interior Infrared Emitter and Flash LED SMD LED Through Hole Lamp LED Display Automotive LED Signage LED Lighting LED Optical Sensors Photocoupler UV LED Detector 162

166 PLCC2 Top LED Interior 3.5 x 2.8 x 1.9 mm Part No. Color λ d (nm)/ CIE(x,y) Typ. Luminous Intensity Iv View Angle Typ. Voltage V F (V) Current I F Thermal Resistance R th (j-s) ( C/W) Max. Current I F Max. Junction Temperature Tj( C) Operating Temperature Range( C) LTSA-T680VEWT Red ~100 LTSA-T680KEWT Red ~100 LTSA-T680VSWT Yellow ~100 LTSA-T680KSWT Yellow ~100 LTSA-T680ZGWT-3 True Green ~100 LTSA-T680ZBWT-3 Blue ~100 LTSA-T680ZHET Ice Blue (0.190, 0.276) ~100 LTSA-T680ZWET Cool White (0.320, 0.313) ~100 Side LED_S089 Interior 3.0x1.4x0.6 mm Part No. Color CIE(x,y) Typ. Luminous Flux Φv (lm) View Angle Typ. Voltage V F (V) Current I F Thermal Resistance R th (j-s) ( C/W) Max. Current I F Max. Junction Temperature Tj( C) Operating Temperature Range( C) LTSA-S089ZHET Ice Blue (0.190, 0.276) ~100 LTSA-S089ZWET Cool White (0.316, 0.333) ~ LED Catalog

167 Multi Color 3-in-1 Top LED_G683 Interior 3.5x2.8x1.45 mm Part No. Color λ d (nm) LTSA-G683ZBEGWU Typ. Luminous Intensity Iv Red View Angle Typ. Voltage V F (V) Current I F Thermal Resistance R th (j-s) ( C/W) Max. Current I F Max. Junction Temperature Tj( C) True Green Blue Multi Color 3-in-1 Side LED_S33 3.0x1.0x0.6 mm Part No. Color λ d (nm) LTSA-S33GBEGK5 Typ. Luminous Intensity Iv View Angle Typ. Voltage V F (V) Current I F Thermal Resistance R th (j-s) ( C/W) Max. Current I F Max. Junction Temperature Tj( C) Red True Green Blue Operating Temperature Range( C) -40~110 Interior Operating Temperature Range( C) -40~85 Infrared Emitter and Flash LED SMD LED Through Hole Lamp LED Display Automotive LED Signage LED Lighting LED Optical Sensors Photocoupler UV LED Detector 164

168 Multi Color 3-in-1 Side LED_S008 Interior 4.5 x 1.25 x 0.8 mm Part No. Color λ d (nm) Typ. Luminous Flux Φv (lm) View Angle Typ. Voltage V F (V) Current I F Thermal Resistance R th (j-s) ( C/W) Max. Current I F Max. Junction Temperature Tj( C) Operating Temperature Range( C) LTSA-S008RGBWA Red True Green Blue ~100 PLCC4 Top LED Rear Signal Interior 3.5 x 2.8 x 1.9 mm Part No. Color λ d (nm)/ CIE(x,y) Typ. Luminous Intensity Iv View Angle Typ. Voltage V F (V) Current I F Thermal Resistance R th (j-s) ( C/W) Max. Current I F Max. Junction Temperature Tj( C) Operating Temperature Range( C) LTSA-E67RVEWT Red ~100 LTSA-E67RVAWT Amber ~100 LTSA-E67RVSWT Yellow ~100 LTSA-E67RZHET Ice Blue (0.190, 0.276) ~100 LTSA-E67RZWET Cool White (0.320, 0.313) ~ LED Catalog

169 PLCC6 Top LED Front Rear Signal Interior Part No. 3.4 x 3.3 x 1.9 mm Color λ d (nm)/ CIE(x,y) Typ. Luminous Intensity Iv View Angle Typ. Voltage V F (V) Current I F Thermal Resistance R th (j-s) ( C/W) Max. Current I F Max. Junction Temperature Tj( C) Operating Temperature Range( C) LTSA-G6SPVEKT Red ~110 LTSA-G6SPVAKT Amber ~110 LTSA-G6SPVSKT Yellow ~110 LTSA-G6SVUWET Cool White (0.320, 0.313) ~110 LTSA-G6SVUAET PC Amber (0.570, 0.420) ~110 5mm Through Hole Lamp 5mm round, T1 3 / 4 Part No. Color λ d (nm) Typ. Luminous Intensity Iv View Angle Typ. Voltage V F (V) Current I F Thermal Resistance R th (j-s) ( C/W) Max. Current I F Max. Junction Temperature Tj( C) Operating Temperature Range( C) LTLA2R3EW3K Red ~100 LTLA2H3VYY1K Yellow ~100 LTLA2R3YW3K Yellow ~100 Rear Signal Infrared Emitter and Flash LED SMD LED Through Hole Lamp LED Display Automotive LED Signage LED Lighting LED Optical Sensors Photocoupler UV LED Detector 166

170 25 Piranha Rear Signal Part No. Color λ d (nm) Typ. Luminous Flux Φv (lm) View Angle Typ. Voltage V F (V) Current I F Thermal Resistance R th (j-s) ( C/W) Max. Current I F Max. Junction Temperature Tj( C) Operating Temperature Range( C) LTLA916VAJ2K Amber ~110 LTLA916VYJ2K Yellow ~ Piranha Rear Signal Part No. Color λ d (nm) Typ. Luminous Flux Φv (lm) View Angle Typ. Voltage V F (V) Current I F Thermal Resistance R th (j-s) ( C/W) Max. Current I F Max. Junction Temperature Tj( C) Operating Temperature Range( C) LTLA918VEJ3K Red ~100 LTLA918VYJ3K Yellow ~ LED Catalog

171 High Power LED_P3030 Front Rear Signal Part No. 3.5 x 3.0 x 0.7 mm Color λ d (nm)/ CIE(x,y) Typ. Luminous Flux Φv (lm) View Angle Typ. Voltage V F (V) Current I F Thermal Resistance R th (j-s) ( C/W) Max. Current I F Max. Junction Temperature Tj( C) Operating Temperature Range( C) LTPA-P3030CNPKE Red ~100 LTPA-P3030CNPTG True Green ~100 LTPA-P3030ANPTB Blue ~100 LTPA-P3030CWP57 Cool White (0.325, 0.340) ~100 LTPA-P3030CBPPA PC Amber (0.570, 0.420) ~100 High Power LED_P35 Part No. LTPA-P35PUDNPKE (Gold Plating) 3.5 x 3.7 x 0.8 mm Color λ d (nm)/ CIE(x,y) Typ. Luminous Flux Φv (lm) View Angle Typ. Voltage V F (V) Current I F Thermal Resistance R th (j-s) ( C/W) Max. Current I F Max. Junction Temperature Tj( C) Operating Temperature Range( C) Red ~100 LTPA-P3535CWP Cool White (0.325, 0.340) ~100 LTPA-P35PUCWP (Gold Plating) Cool White (0.325, 0.340) ~100 LTPA-P3535CBPPA PC Amber (0.570, 0.420) ~100 LTPA-P35PUCBPPA (Gold Plating) PC Amber (0.570, 0.420) ~100 Front Rear Signal Infrared Emitter and Flash LED SMD LED Through Hole Lamp LED Display Automotive LED Signage LED Lighting LED Optical Sensors Photocoupler UV LED Detector 168

172 High Power LED_C35 Front Rear Signal 3.45 x 3.45 x 2.13 mm Part No. Color λ d (nm)/ CIE(x,y) Typ. Luminous Flux Φv (lm) View Angle Typ. Voltage V F (V) Current I F Thermal Resistance R th (j-s) ( C/W) Max. Current I F Max. Junction Temperature Tj( C) Operating Temperature Range( C) LTPA-C3535CNPKE Red ~125 LTPA-C3535CNPTG True Green ~125 LTPA-C3535ANPTB Blue ~125 LTPA-C3535AWP Cool White (0.325, 0.340) ~125 LTPA-C3535BWP57 Cool White (0.325, 0.340) ~125 LTPA-C35NUAWP Cool White (0.325, 0.340) ~125 LTPA-C3535BBPPA PC Amber (0.570, 0.420) ~125 LTPA-C35NUBBPPA PC Amber (0.570, 0.420) ~125 High Power LED _S38 Front Signal 3.75 x 3.75 x 0.55 mm Part No. Color CIE(x,y) Typ. Luminous Flux Φv (lm) View Angle Typ. Voltage V F (V) Current I F Thermal Resistance R th (j-s) ( C/W) Max. Current I F Max. Junction Temperature Tj( C) Operating Temperature Range( C) LTPA-S38FUMWE Cool White (0.325, 0.340) ~125 LTPA-S38FUMBPPA PC Amber (0.570, 0.420) ~125 New 169 LED Catalog

173 High Power LED_C1915 Front Part No. Correlated color temperature (K) Typ. Luminous Flux Φv (lm) View Angle Typ. Voltage V F (V) Current I F Thermal Resistance R th (j-s) ( C/W) Max. Current I F Max. Junction Temperature Tj( C) Operating Temperature Range( C) LTPA-C K ~125 Under Development High Intensity Chip Array Part No. Correlated color temperature (K) Typ. Luminous Flux Φv (lm) View Angle 1.9 x 1.5 x 0.75 mm Typ. Voltage V F (V) Current I F Thermal Resistance R th (j-s) ( C/W) Max. Current I F Max. Junction Temperature Tj( C) Operating Temperature Range( C) LTPA-H2S K ~125 LTPA-H3S K ~125 LTPA-H4S K ~125 LTPA-H5S K ~125 Under Development 3.1 x 3.8 x 0.75 mm 4.2 x 3.8 x 0.75 mm 5.3 x 3.8 x 0.75 mm 6.4 x 3.8 x 0.75 mm Front Infrared Emitter and Flash LED SMD LED Through Hole Lamp LED Display Automotive LED Signage LED Lighting LED Optical Sensors Photocoupler UV LED Detector 170

174 Signage LED

175 Chip LED Single Color Part No. Color λ d (nm)/ CIE (x,y) Min. Luminous Intensity Iv Max. Luminous Intensity Iv View Angle Typ. Voltage V F (V) LTSN-C170KSWT Yellow LTSN-C170DS White (0.31, 0.31) Part No. 2.0 x 1.25 x 1.1 mm Chip LED Single Color 1.6 x 0.8 x 0.55 mm Color λ d (nm)/ CIE (x,y) Min. Luminous Intensity Iv Max. Luminous Intensity Iv View Angle Typ. Voltage V F (V) LTSN-C191KSKT Yellow LTSN-C191DS White (0.31, 0.31) Current I F Current I F Infrared Emitter and Flash LED SMD LED Through Hole Lamp LED Display Automotive LED Signage LED Lighting LED Optical Sensors Photocoupler UV LED Detector 172

176 Chip LED Multi Color 0.8 x 0.8 x 0.65 mm Part No. Color λ d (nm) Min. Luminous Intensity Iv Max. Luminous Intensity Iv View Angle Typ. Voltage V F (V) Current I F Red LTSN-B68JEGBB6 True Green Blue Chip LED Multi Color 1.0 x 1.0 x 0.65 mm Part No. Color λ d (nm) Min. Luminous Intensity Iv Max. Luminous Intensity Iv View Angle Typ. Voltage V F (V) Current I F Red LTSN-B32JEGBB6 True Green Blue LED Catalog

177 Chip LED Multi Color (IC Embedded) Part No. Color λ d (nm) LTSN-E263HEGBK Part No. Color λ d (nm) LTSN-E363CEGBW 1.8 x 1.8 x 0.65 mm Min. Luminous Intensity Iv Min. Luminous Intensity Iv Max. Luminous Intensity Iv Red Max. Luminous Intensity Iv Red View Angle View Angle Typ. Voltage V F (V) True Green Blue Chip LED Multi Color (IC Embedded) 3.2 x 3.2 x 1.1 mm Typ. Voltage V F (V) Current I F Current I F 2 14 True Green Blue Infrared Emitter and Flash LED SMD LED Through Hole Lamp LED Display Automotive LED Signage LED Lighting LED Optical Sensors Photocoupler UV LED Detector 174

178 PLCC Single Color 3.5 x 2.8 x 1.9 mm Part No. Color λ d (nm)/ CIE (x,y) Min. Luminous Intensity Iv Max. Luminous Intensity Iv View Angle Typ. Voltage V F (V) Current I F LTST-B680VEKT Red LTST-B680VSKT Yellow LTST-B680UGKT True Green LTST-B680UWET White (0.31, 0.31) PLCC Single Color 2.1 x 2.1 x 1.0 mm Part No. Color λ d (nm)/ CIE (x,y) Min. Luminous Intensity Iv Max. Luminous Intensity Iv View Angle Typ. Voltage V F (V) Current I F LTSN-N211QSWT Yellow LTSN-N211VSWT Yellow LTSN-N211UWET White (0.31, 0.31) LED Catalog

179 PLCC Multi Color Part No. Color λ d (nm) LTSN-N213EGBW Part No. Color λ d (nm) LTSN-H213EGBW 2.1 x 2.1 x 1.0 mm PLCC Multi Color 2.1 x 2.1 x 1.0 mm Min. Luminous Intensity Iv Min. Luminous Intensity Iv Max. Luminous Intensity Iv Red Max. Luminous Intensity Iv Red View Angle View Angle Typ. Voltage V F (V) Typ. Voltage V F (V) Current I F 2 20 True Green Blue Current I F 2 5 True Green Blue Infrared Emitter and Flash LED SMD LED Through Hole Lamp LED Display Automotive LED Signage LED Lighting LED Optical Sensors Photocoupler UV LED Detector 176

180 PLCC Multi Color 3.5 x 3.5 x 2.5 mm Part No. Color λ d (nm) Min. Luminous Intensity Iv Max. Luminous Intensity Iv View Angle Typ. Voltage V F (V) Current I F Red LTSN-D353EGBW True Green Blue LED Catalog

181 Through Hole Lamp_3mm 3mm Round Part No. Color Resin Color λ d (nm) Through Hole Lamp_3mm 3mm Round Part No. Color Resin Color λ d (nm) Min. Luminous Intensity Iv Min. Luminous Intensity Iv Max. Luminous Intensity Iv Max. Luminous Intensity Iv View Angle View Angle Typ. Voltage VF (V) Typ. Voltage VF (V) LTL17KET3KS Red Water Clear LTL17KTGX3KS True Green Water Clear LTL17KTBS3KS Blue Water Clear LTL1SHEW3KS Red Water Clear LTL1SHER3D Red Red Diffused (min.) LTL1SHYW3KS Yellow Water Clear LTL1SHTGV3DP True Green Green Diffused LTL1SHTBN3DP Blue Water Clear Current IF Infrared Emitter and Flash LED SMD LED Through Hole Lamp LED Display Automotive LED Signage LED Lighting LED Optical Sensors Photocoupler UV LED Detector 178

182 Through Hole Lamp_3mm 3mm Oval Part No. Color Resin Color λ d (nm) Typ. Luminous Intensity Iv View Angle Typ. Voltage V F (V) Current I F LTL3H3EPADS Red Red Diffued / LTL3H3TGTADS True Green Green Diffused / LTL3H3TBNADS Blue Blue Diffused / Through Hole Lamp_4mm 4mm Oval Part No. Color Resin Color λ d (nm)/ CIE (x,y) Min. Luminous Intensity Iv Max. Luminous Intensity Iv View Angle Typ. Voltage V F (V) Current I F LTL4HMEPADS Red Red Diffused / LTL4HMWSDS-A Yellow Yellow Diffused / LTL4HMYSADS Yellow Yellow Diffused / LTW4HMDVAJS White White Diffued (0.32, 0.33) / LED Catalog

183 Through Hole Lamp_4mm 4mm Oval Part No. Color Resin Color λ d (nm)/ CIE (x,y) Min. Luminous Intensity Iv Max. Luminous Intensity Iv View Angle Typ. Voltage VF (V) LTL4VMYS5D Yellow Yellow Diffused / Current IF LTW4VMDV5JS White White Diffued (0.3, 0.3) / Infrared Emitter and Flash LED SMD LED Through Hole Lamp LED Display Automotive LED Signage LED Lighting LED Optical Sensors Photocoupler UV LED Detector 180

184 Through Hole Lamp_5mm 5mm Round Part No. Color Resin Color λ d (nm)/ CIE (x,y) Min. Luminous Intensity Iv Max. Luminous Intensity Iv View Angle Typ. Voltage V F (V) Current I F LTL2H3E11K Red Water Clear LTL2P3EX2K Red Water Clear LTL2V3EY3KS Red Water Clear LTL2V3EUJS Red White Diffued LTL2R3FU3JSR Amber White Diffued LTL2H3Y11K Yellow Water Clear LTL2P3YX2K Yellow Water Clear LTL2R3YW3KS Yellow Water Clear LTL2R3TGY3KS Ture Green Water Clear LTL2H3TC21K Cyan Water Clear LTL2P3TCY2K Cyan Water Clear LTL2R3TCY3JS Cyan White Diffued LTW2V3D13JS White White Diffued (0.32, 0.33) LTW-2S3D8-CY White Water Clear (0.3, 0.3) LED Catalog

185 Through Hole Lamp_5mm 5mm Oval Part No. Color Resin Color λ d (nm)/ CIE (x,y) Min. Luminous Intensity Iv Max. Luminous Intensity Iv View Angle Typ. Voltage V F (V) LTL5H3TRDS Red Red Diffued / LTL5H3TGDS True Green Green Diffused / LTL5H3TBDS Blue Blue Diffused / LTW5H3DVAJS White White Diffued (0.32, 0.33) / Through Hole Lamp_5mm 5mm Oval Part No. Color Resin Color λ d (nm)/ CIE (x,y) Min. Luminous Intensity Iv Max. Luminous Intensity Iv View Angle Typ. Voltage V F (V) LTL5L3ES7D Red Red Diffused / LTL5L3YU7DS Yellow Yellow Diffused / LTL5L3TGV7D True Green Green Diffused / LTW5L3DW7JS White White Diffued (0.32, 0.33) / Current I F Current I F Infrared Emitter and Flash LED SMD LED Through Hole Lamp LED Display Automotive LED Signage LED Lighting LED Optical Sensors Photocoupler UV LED Detector 182

186 Through Hole Lamp_5mm_Dual Color 5mm Oval Part No. Color Resin Color λ d (nm) Min. Luminous Intensity Iv Max. Luminous Intensity Iv View Angle Typ. Voltage VF (V) Current I F LTL30SETG3J Red White Diffused 30 True Green LED Catalog

187 Lighting LED

188 Middle Power 2.7 x 1.4 x 0.8 mm Part No. Correlated color temperature (K) CRI Ra (min.) Typ. Luminous Flux Φv (lm) View Angle Typ. Voltage V F (V) Current I F Thermal Resistance R th (j-s) ( C/W) LTW-K140SZR27-EU LTW-K140SZR30-EU LTW-K140SZR40-EU LTW-K140SZR50-EU LTW-K140SZR57-EU LTW-K140SZR65-EU LTW-K140SXR LED Catalog

189 Middle Power Part No. 2.8 x 3.5 x 0.65 mm Correlated color temperature (K) CRI Ra (min.) Typ. Luminous Flux Φv (lm) View Angle Typ. Voltage V F (V) Current I F Thermal Resistance R th (j-s) ( C/W) LTW-2835SZK LTW-2835AZH LTW-2835AZI LTW-2835TZN LTW-2835AZL LTW-2835SZK LTW-2835AZH LTW-2835AZI LTW-2835TZN LTW-2835AZL LTW-2835SZK LTW-2835AZH LTW-2835AZI LTW-2835TZN LTW-2835AZL LTW-2835SZK LTW-2835AZH LTW-2835AZI LTW-2835TZN LTW-2835AZL LTW-2835SZK LTW-2835AZH LTW-2835AZI LTW-2835TZN LTW-2835AZL LTW-2835SZK LTW-2835AZH LTW-2835AZI LTW-2835TZN Infrared Emitter and Flash LED SMD LED Through Hole Lamp LED Display Automotive LED Signage LED Lighting LED Optical Sensors Photocoupler UV LED Detector LTW-2835AZL

190 Middle Power 5.6 x 3.0 x 0.9 mm Part No. Correlated color temperature (K) CRI Ra (min.) λ d (nm) λ p (nm) Typ. Luminous Flux Φv (lm) Typ. Radiant Flux (mw) View Angle Typ. Voltage V F (V) Current I F LTW-5630AZL27-EUH LTW-5630AQL LTW-5630AZL30-EUH LTW-5630AQL LTW-5630AZL40-EUH LTW-5630AQL LTW-5630AZL50-EUH LTW-5630AQL LTW-5630AZL57-EUH LTW-5630AQL LTW-5630AZL65-EUH LTW-5630AQL LTW-5630SD LTW-5630SD LTW-5630SD LTW-5630SD LTW-5630SD LTW-5630SP LTW-5630SP LTW-5630SP Thermal Resistance R th (j-s) ( C/W) 187 LED Catalog

191 Middle Power Part No. 7.4 x 5.0 x 1.3 mm Correlated color temperature (K) CRI Ra (min.) Typ. Luminous Flux Φv (lm) View Angle Typ. Voltage V F (V) Current I F Thermal Resistance R th (j-s) ( C/W) LTPL-P033BS LTPL-P033BS LTPL-P033BS Infrared Emitter and Flash LED SMD LED Through Hole Lamp LED Display Automotive LED Signage LED Lighting LED Optical Sensors Photocoupler UV LED Detector 188

192 High Power 3.5 x 3.5 x 2.13 mm Part No. Color λ d (nm) λ p (nm) Min. Luminous Flux Φv (lm) Max. Luminous Flux Φv (lm) Min. Radiant Flux (mw) Max. Radiant Flux (mw) View Angle Typ. Voltage V F (V) Current I F LTPL-C035RH630 Red Thermal Resistance R th (j-s) ( C/W) LTPL-C035RN615 Orange Red LTPL-C035GH530 True Green LTPL-C035GH500 Cyan LTPL-C035BH470 Blue LTPL-C035BH450 Blue LTPL-C035RH LTPL-C035RH High Power 1.6 x 1.6 x 1.38 mm Part No. Color λ d (nm) λ p (nm) Min. Luminous Flux Φv (lm) Max. Luminous Flux Φv (lm) Min. Radiant Flux (mw) Max. Radiant Flux (mw) View Angle Typ. Voltage V F (V) Current I F LTPL-C16FRD630 Red LTPL-C16FGH530 True Green LTPL-C16FBD470 Blue LTPL-C16FRD Thermal Resistance R th (j-s) ( C/W) LTPL-C16FRM LED Catalog

193 High Power Part No. Color λ d (nm) Min. Luminous Flux Φv (lm) Max. Luminous Flux Φv (lm) View Angle Typ. Voltage V F (V) Current I F Thermal Resistance R th (j-s) ( C/W) LTPL-C08ERS Red LTPL-C08EAS True Green LTPL-C08ECT Blue High Power 6.5 x 6.5 x 3.86 mm 3.45 x 3.45 x 2.13 mm Part No. Color λ d (nm) Min. Luminous Flux Φv (lm) Max. Luminous Flux Φv (lm) View Angle Typ. Voltage V F (V) Current I F Thermal Resistance R th (j-s) ( C/W) LTPL-C034AH610 Red LTPL-C034OH590 Yellow LTPL-C034DH Yellow Infrared Emitter and Flash LED SMD LED Through Hole Lamp LED Display Automotive LED Signage LED Lighting LED Optical Sensors Photocoupler UV LED Detector 190

194 Ceramic COB x x 1.6 mm Part No. Correlated color temperature (K) CRI Ra min. LES (mm) Min. Luminous Flux Φv (lm) Max. Luminous Flux Φv (lm) View Angle Typ. Voltage V F (V) Current I F Thermal Resistance R th (j-s) ( C/W) LTPL-M13706ZS27-T LTPL-M13710ZS27-T LTPL-M13712ZS27-T LTPL-M13706ZS30-T LTPL-M13710ZS30-T LTPL-M13712ZS30-T LTPL-M13706ZS40-T LTPL-M13710ZS40-T LTPL-M13712ZS40-T LTPL-M13706ZS50-F LTPL-M13710ZS50-F LTPL-M13712ZS50-F LED Catalog

195 Ceramic COB Part No x x 1.6 mm Correlated color temperature (K) CRI Ra min. LES (mm) Min. Luminous Flux Φv (lm) Max. Luminous Flux Φv (lm) View Angle Typ. Voltage V F (V) Current I F Thermal Resistance R th (j-s) ( C/W) LTPL-M03614ZS27-T LTPL-M03622ZS30-T LTPL-M03614ZS30-T LTPL-M03622ZS30-T LTPL-M03614ZS40-T LTPL-M03622ZS30-T Infrared Emitter and Flash LED SMD LED Through Hole Lamp LED Display Automotive LED Signage LED Lighting LED Optical Sensors Photocoupler UV LED Detector 192

196 Ceramic COB x x 1.6 mm Part No. Correlated color temperature (K) CRI Ra min. LES (mm) Min. Luminous Flux Φv (lm) Max. Luminous Flux Φv (lm) View Angle Typ. Voltage V F (V) Current I F Thermal Resistance R th (j-s) ( C/W) LTPL-M09825ZS30-T LTPL-M09825QS30-T LTPL-M09830ZS30-T LTPL-M09830QS30-T LTPL-M09825ZS40-T LTPL-M09830ZS40-T LTPL-M09825ZS50-F LTPL-M09830ZS50-F LED Catalog

197 Ceramic COB Part No x x 1.6 mm Correlated color temperature (K) CRI Ra min. LES (mm) Min. Luminous Flux Φv (lm) Max. Luminous Flux Φv (lm) View Angle Typ. Voltage V F (V) Current I F Thermal Resistance R th (j-s) ( C/W) LTPL-M07452ZS30-T LTPL-M07480ZS30-T LTPL-M07452ZS57-T LTPL-M07480ZS57-T LTPL-M07452ZS65-T LTPL-M07480ZS65-T Infrared Emitter and Flash LED SMD LED Through Hole Lamp LED Display Automotive LED Signage LED Lighting LED Optical Sensors Photocoupler UV LED Detector 194

198 MCPCB COB x x 1.6 mm Part No. Correlated color temperature (K) CRI Ra min. LES (mm) Min. Luminous Flux Φv (lm) Max. Luminous Flux Φv (lm) View Angle Typ. Voltage V F (V) Current I F Thermal Resistance R th (j-s) ( C/W) LTPL-M08206ZS27-T LTPL-M08210ZS27-T LTPL-M08218ZS27-T LTPL-M08206ZS30-T LTPL-M08206QS30-T LTPL-M08210ZS30-T LTPL-M08210QS30-T LTPL-M08218ZS30-T LTPL-M08218QS30-T LTPL-M08206ZS40-T LTPL-M08210ZS40-T LTPL-M08218ZS40-T LED Catalog

199 MCPCB COB Part No. 19 x 19 x 1.5 mm Correlated color temperature (K) CRI Ra min. LES (mm) Min. Luminous Flux Φv (lm) Max. Luminous Flux Φv (lm) View Angle Typ. Voltage V F (V) Current I F Thermal Resistance R th (j-s) ( C/W) LTPL-M04520ZS27-T LTPL-M04530ZS27-T LTPL-M04520ZS30-T LTPL-M04520QS30-T LTPL-M04530ZS30-T LTPL-M04530QS30-T LTPL-M04520ZS40-T LTPL-M04530ZS40-T Infrared Emitter and Flash LED SMD LED Through Hole Lamp LED Display Automotive LED Signage LED Lighting LED Optical Sensors Photocoupler UV LED Detector 196

200 Infrared Emitter and Detector

201 IR Emitter_3mm Through Hole Type T1 Top View, 3mm Part No. λ p (nm) Lens Color Viewing Angle Typ.Radiation Intensity I e (mw/sr) IR Emitter_3mm Through Hole Type Typ. Voltage V F (V) LTE Water Clear 60 F =20mA 1.2@I F =50mA LTE-18G3N 940 Water Clear 20 F =20mA F =20mA T1 Top View, 3mm Part No. λ p (nm) Lens Color Viewing Angle Typ.Radiation Intensity I e (mw/sr) Typ. Voltage V F (V) LTE Water Clear 20 F =20mA F =20mA LTE-4206C 940 Smoke 20 F =20mA F =20mA LTE Water Clear 25 F =50mA F =50mA LTE-16K3L 940 Water Clear 55 F =20mA F =20mA Infrared Emitter and Flash LED SMD LED Through Hole Lamp LED Display Automotive LED Signage LED Lighting LED Optical Sensors Photocoupler UV LED Detector 198

202 IR Emitter_3mm Through Hole Type T1 Top View, 3mm Part No. λ p (nm) Lens Color Viewing Angle Typ.Radiation Intensity I e (mw/sr) Typ. Voltage V F (V) Current I F LTE Water Clear IR Emitter_3mm Through Hole Type T1 Top View, 3mm Part No. λ p (nm) Lens Color Viewing Angle Typ.Radiation Intensity I e (mw/sr) Typ. Voltage V F (V) Current I F LTE-14H0B 850 Black LED Catalog

203 IR Emitter_3mm Through Hole Type T1 Top View, 3mm Part No. λ p (nm) Lens Color T1 Top View, 3mm Part No. λ p (nm) Lens Color Viewing Angle Viewing Angle Typ.Radiation Intensity I e (mw/sr) Typ.Radiation Intensity I e (mw/sr) Typ. Voltage V F (V) Typ. Voltage V F (V) Current I F LTE-16H0B 850 Black IR Emitter_3mm Through Hole Type Current I F LTE-18H0B 850 Black (.02) 2.54 NOM. (.1) 4.10 (0.16) 1 (.04) 22MIN (.87) 8.40 (.33) 1.0MIN (.04) FLAT DENOTES CATHODE 4.6 (.18) Infrared Emitter and Flash LED SMD LED Through Hole Lamp LED Display Automotive LED Signage LED Lighting LED Optical Sensors Photocoupler UV LED Detector 200

204 IR Emitter_5mm Through Hole Type T1 3/4 Top View, 5mm Part No. λ p (nm) Lens Color Viewing Angle Typ.Radiation Intensity I e (mw/sr) Typ. Voltage V F (V) LTE-3279K 940 Light Blue 60 F =100mA F =100mA LTE-3271B 940 Water Clear 50 F =20mA F =50mA LTE-3271BL 940 Blue 50 F =20mA F =50mA LTE-3371T 940 Water Clear 40 F =20mA F =50mA LTE-5228A 940 Water Clear 40 F =20mA F =20mA LTE-3223L 940 Water Clear 30 F =20mA F =50mA LTE-3273L 940 Water Clear 40 F =20mA F =50mA LTE-3273DL 940 Blue 45 F =20mA F =50mA LTE-32B3L 940 Water Clear 50 F =20mA F =20mA LTE Water Clear 20 F =20mA F =20mA LTE-4238R 880 Water Clear 20 F =20mA F =20mA LTE Water Clear 30 F =50mA F =50mA LTE Water Clear 50 F =50mA F =50mA LTE Water Clear 30 F =50mA F =50mA LTE Water Clear 25 F =50mA F =50mA LTE Water Clear 20 F =50mA F =50mA LTE-3220L 850 Water Clear 30 F =50mA F =50mA LTE-3070L 850 Water Clear 45 F =50mA F =50mA LTE-3370L 850 Water Clear 20 F =50mA F =50mA LTE-32B0L 850 Water Clear 40 F =20mA F =50mA LTE-32F0L 850 Water Clear 60 F =50mA F =50mA LTE-7F70L 850 Water Clear 95 F =50mA F =100mA 201 LED Catalog

205 IR Emitter_5mm Through Hole Type T1 3/4 Top View, 5mm Part No. λ p (nm) Lens Color Part No. λ p (nm) Lens Color Part No. λ p (nm) Lens Color Viewing Angle Viewing Angle Viewing Angle Typ.Radiation Intensity I e (mw/sr) Typ.Radiation Intensity I e (mw/sr) Typ.Radiation Intensity I e (mw/sr) Typ. Voltage V F (V) Typ. Voltage V F (V) Typ. Voltage V F (V) Current I F LTE-2872U 940 Water Clear IR Emitter_Side Look 5.72 x 4.40 x 2.25 mm Current I F LTE Water Clear IR Emitter_Side Look 4.12 x 4.00 x 2.25 mm Current I F LTE Water Clear Infrared Emitter and Flash LED SMD LED Through Hole Lamp LED Display Automotive LED Signage LED Lighting LED Optical Sensors Photocoupler UV LED Detector 202

206 IR Emitter_Side Look 4.00 x 3.00 x 2.95 mm Part No. λ p (nm) Lens Color Viewing Angle Typ.Radiation Intensity I e (mw/sr) Typ. Voltage V F (V) LTE Water Clear 30 F =20mA F =20mA LTE Water Clear 30 F =20mA F =50mA IR Emitter_SMD Side View 6.40 x 5.80 x 5.00 mm Part No. λ p (nm) Lens Color Viewing Angle Typ.Radiation Intensity I e (mw/sr) Typ. Voltage V F (V) LTE-7377L 880 Blue 16 F =50mA F =350mA 203 LED Catalog

207 IR Emitter_SMD Type 3.2 x 1.6 x 1.1 mm Part No. λ p (nm) Lens Color IR Emitter_SMD Type 1.6 x 0.8 x 0.8 mm Viewing Angle Typ.Radiation Intensity I e (mw/sr) Typ. Voltage V F (V) Current I F LTE-C Clear LTE-C Clear Part No. λ p (nm) Lens Color Viewing Angle Typ.Radiation Intensity I e (mw/sr) Typ. Voltage V F (V) Current I F LTE-C1901-ZF 940 Clear LTE-C1906R Clear Infrared Emitter and Flash LED SMD LED Through Hole Lamp LED Display Automotive LED Signage LED Lighting LED Optical Sensors Photocoupler UV LED Detector 204

208 IR Emitter_SMD Type 3.2 x 1.6 x 1.1 mm Part No. λ p (nm) Lens Color Viewing Angle Typ.Radiation Intensity I e (mw/sr) Typ. Voltage V F (V) Current I F LTE-C211-X 940 Clear LTE-C216-P 850 Clear LTE-C216R Clear IR Emitter_SMD Type 3.2 x 2.4 x 2.4 mm Part No. λ p (nm) Lens Color Viewing Angle Typ.Radiation Intensity I e (mw/sr) Typ. Voltage V F (V) Current I F LTE-C Clear LTE-C Clear LTE-C9306R Clear LED Catalog

209 IR Emitter_SMD Type 3.2 x 1.6 x 1.85 mm Part No. λ p (nm) Lens Color IR Emitter_SMD Type 1.6 x 0.8 x 0.98 mm Viewing Angle Typ.Radiation Intensity I e (mw/sr) Typ. Voltage V F (V) Current I F LTE-C9501-E-T 940 Clear LTE-C9506B 850 Black Part No. λ p (nm) Lens Color Viewing Angle SOLDERING TERMINAL Typ.Radiation Intensity I e (mw/sr) Typ. Voltage V F (V) Current I F LTE-C Clear ANODE MARK R0.350 MOLDING BODY (LENS) P.C BOARD POLARITY - + Infrared Emitter and Flash LED SMD LED Through Hole Lamp LED Display Automotive LED Signage LED Lighting LED Optical Sensors Photocoupler UV LED Detector 206

210 IR Emitter_SMD Type 3.2 x 2.5 x 1.6 mm Part No. λ p (nm) Lens Color Viewing Angle Typ.Radiation Intensity I e (mw/sr) Typ. Voltage V F (V) Current I F LTE-S9511-E 940 Clear IR Emitter_SMD Type 3.2 x 2.5 x 1.2 mm Part No. λ p (nm) Lens Color Viewing Angle Typ.Radiation Intensity I e (mw/sr) Typ. Voltage V F (V) Current I F LTE-S9511TS 940 Clear IR Emitter_SMD Type 3.2 x 2.4 x 1.6 mm Part No. λ p (nm) Lens Color Viewing Angle Typ.Radiation Intensity I e (mw/sr) Typ. Voltage V F (V) Current I F LTE-S9711-J 940 Clear LED Catalog

211 IR Emitter_SMD Type 3.0 x 2.0 x 1.0 mm Part No. λ p (nm) Lens Color IR Emitter_SMD Bowl Type 2.30 x 1.95 x 0.90 mm Viewing Angle Typ.Radiation Intensity I e (mw/sr) Typ. Voltage V F (V) Current I F LTE-S Clear LTE-S Clear Part No. λ p (nm) Viewing Angle Typ.Radiation Intensity I e (mw/sr) Typ. Voltage V F (V) Max. Continuous Current LTE-C F =100mA F = 100mA 100 LTE-C F =100mA F = 100mA 100 Cathode Anode Infrared Emitter and Flash LED SMD LED Through Hole Lamp LED Display Automotive LED Signage LED Lighting LED Optical Sensors Photocoupler UV LED Detector 208

212 IR Emitter_High Power SMD 3.85 x 3.85 x 1.51 mm Part No. λ p (nm) Lens Color Viewing Angle Typ.Radiation Intensity I e (mw/sr) Typ. Voltage V F (V) LTE-R38381-S 940 Clear 90 F =1000mA F =1000mA LTE-R38831S-S 940 Clear 90 F =1000mA F =1000mA LTE-R38386-SE8 850 Clear 90 F =700mA F =350mA LTE-R38386-ZFE8 850 Clear 150 F =700mA F =350mA LTE-R38386-S 850 Clear 90 F =1000mA F =1000mA LTE-R38386-ZF 850 Clear 150 F =1000mA F =1000mA LTE-R38386S-S 850 Clear 90 F =1000mA F =1000mA LTE-R38386S-ZF 850 Clear 150 F =1000mA F =1000mA LTE-R38389S-S 810 Clear 90 F =1000mA F =1000mA IR Emitter_SMD Type 2.5 x 1.6 x 0.55 mm Part No. λ p (nm) Lens Color Viewing Angle Typ.Radiation Intensity I e (mw/sr) Typ. Voltage V F (V) Current I F LTE-C195IRG 660 Clear LED Catalog

213 Photodiode_5mm Through Hole Type Part No. Lens Color Visable Light Fiber Typ. Short Circuit Current I s (μa)@v R =5V; E e =0.1mW/cm 2 ;λ=940nm Max. Reverse Dark Current Voltage ID (R) R =10V; E e = 0mW/cm 2 Min. Reverse Break Down Voltage V (BR)R R =100μA E e = 0mW/cm 2 LTR-323DB Dark Yes Part No. Lens Color T1 3/4 Top View, 5mm Photodiode_Side Look 6.6 x 5.0 x 4.0 mm Visable Light Fiber Typ. Short Circuit Current I s (μa)@v R =5V; E e =0.1mW/cm 2 ;λ=940nm Max. Reverse Dark Current Voltage ID (R) R =10V; E e = 0mW/cm 2 Min. Reverse Break Down Voltage V (BR)R R =100μA E e = 0mW/cm 2 LTR-526AD Dark Yes Infrared Emitter and Flash LED SMD LED Through Hole Lamp LED Display Automotive LED Signage LED Lighting LED Optical Sensors Photocoupler UV LED Detector 210

214 Photodiode_Side Look 6.6 x 5.0 x 4.0 mm Part No. Lens Color Visable Light Fiber Typ. Short Circuit Current I s (μa)@v R =5V; E e =0.1mW/cm 2 ;λ=940nm Max. Reverse Dark Current Voltage ID (R) R =10V; E e = 0mW/cm 2 Min. Reverse Break Down Voltage V (BR)R R =100μA E e = 0mW/cm 2 LTR-516AB Dark Yes LTR-516AD Dark Yes Photodiode_Side Look 7.5 x 5.2 x 3.0 mm Part No. Lens Color Visable Light Fiber Typ. Short Circuit Current I s (μa)@v R =5V; E e =0.1mW/cm 2 ;λ=940nm Max. Reverse Dark Current Voltage ID (R) R =10V; E e = 0mW/cm 2 Min. Reverse Break Down Voltage V (BR)R R =100μA E e = 0mW/cm 2 LTR-536AD Dark Yes LED Catalog

215 Photodiode_Side Look Part No. Lens Color 7.6 x 7.0 x 2.8 mm Visable Light Fiber Photodiode_SMD Side Look 6.4 x 5.0 x 5.80 mm Typ. Short Circuit Current I s (μa)@v R =5V; E e =0.1mW/cm 2 ;λ=940nm Max. Reverse Dark Current Voltage ID (R) R =10V; E e = 0mW/cm 2 Min. Reverse Break Down Voltage V (BR)R R =100μA E e = 0mW/cm 2 LTR-546AB Dark Yes LTR-546AD Dark Yes Part No. Lens Color Visable Light Fiber Typ. Short Circuit Current I s (μa)@v R =5V; E e =0.1mW/cm 2 ;λ=940nm Max. Reverse Dark Current Voltage ID (R) R =10V; E e = 0mW/cm 2 Min. Reverse Break Down Voltage V (BR)R R =100μA E e = 0mW/cm 2 LTR-733DBM1-TA Dark Yes Infrared Emitter and Flash LED SMD LED Through Hole Lamp LED Display Automotive LED Signage LED Lighting LED Optical Sensors Photocoupler UV LED Detector 212

216 Photodiode_SMD Type 3.2 x 2.7 x 1.1 mm Part No. Lens Color Visable Light Fiber Typ. Short Circuit Current I s (μa)@v R =5V; E e =0.5mW/cm 2 ;λ=940nm Max. Reverse Dark Current Voltage ID (R) R =10V; E e = 0mW/cm 2 Min. Reverse Break Down Voltage V (BR)R R =100μA E e = 0mW/cm 2 LTR-C155-DC Clear No LTR-C155-DB Dark Yes Photodiode_SMD Type 5.0 x 4.0 x 0.85 mm Part No. Lens Color Visable Light Fiber Typ. Short Circuit Current I s (μa)@v R =5V; E e =0.5mW/cm 2 ;λ=940nm Max. Reverse Dark Current Voltage ID (R) R =10V; E e = 0mW/cm 2 Min. Reverse Break Down Voltage V (BR)R R =100μA E e = 0mW/cm 2 940nm : 40 LTR-C5510-DC Clear No 660nm : nm : LTR-C5511-DB Black Yes LED Catalog

217 Photodiode_SMD Type Part No. Lens Color Visable Light Fiber Photodiode_SMD Type Typ. Short Circuit Current I s (μa)@v R =5V; E e =0.5mW/cm 2 ;λ=940nm Max. Reverse Dark Current Voltage ID (R) R =10V; E e = 0mW/cm 2 Min. Reverse Break Down Voltage V (BR)R R =100μA E e = 0mW/cm 2 LTR-C950-DB Black Yes Part No. Lens Color 3.2 x 1.6 x 1.85 mm 3.0 x 2.0 x 1.0 mm Visable Light Fiber Typ. Short Circuit Current I s (μa)@v R =5V; E e =0.5mW/cm 2 ;λ=940nm Max. Reverse Dark Current Voltage ID (R) R =10V; E e = 0mW/cm 2 Min. Reverse Break Down Voltage V (BR)R R =100μA E e = 0mW/cm 2 LTR-S320-DB-L Dark Yes Infrared Emitter and Flash LED SMD LED Through Hole Lamp LED Display Automotive LED Signage LED Lighting LED Optical Sensors Photocoupler UV LED Detector 214

218 Phototransistors_3mm Through Hole Type T1 Top View, 3mm Part No. Lens Color Visable Light Fiber Min. On State Collector Current I CE =5V; E e =1mW/cm 2 ; λ=940nm Max. Dark Current V CE =10V Max. Collector-Emitter Saturation Voltage V CE(SAT) I c =100μA E e = 1mW/cm 2 Min. Collector-Emitter Breakdown Voltage V (BR)CEO I c =1mA E e = 0mW/cm 2 LTR-1650D Dark Yes Phototransistors_3mm Through Hole Type T1 Top View, 3mm Part No. Lens Color Visable Light Fiber Min. On State Collector Current I CE =5V; E e =1mW/cm 2 ; λ=940nm Max. Dark Current V CE =10V Max. Collector-Emitter Saturation Voltage V CE(SAT) I c =100μA E e = 1mW/cm 2 Min. Collector-Emitter Breakdown Voltage V (BR)CEO I c =1mA E e = 0mW/cm 2 LTR-4206 Water Clear No LTR-4206E Dark Yes LED Catalog

219 Phototransistors_3mm Through Hole Type Part No. Lens Color T1 Top View, 3mm Visable Light Fiber Phototransistors_3mm Through Hole Type T1 Top View, 3mm Min. On State Collector Current I CE =5V; E e =1mW/cm 2 ; λ=940nm Max. Dark Current V CE =10V Max. Collector-Emitter Saturation Voltage V CE(SAT) I c =100μA E e = 1mW/cm 2 Min. Collector-Emitter Breakdown Voltage V (BR)CEO I c =1mA E e = 0mW/cm 2 LTR-3208 Water Clear No LTR-3208E Dark Yes Part No. Lens Color Visable Light Fiber Min. On State Collector Current I CE =5V; E e =1mW/cm 2 ; λ=940nm Max. Dark Current V CE =10V Max. Collector-Emitter Saturation Voltage V CE(SAT) I c =100μA E e = 1mW/cm 2 Min. Collector-Emitter Breakdown Voltage V (BR)CEO I c =1mA E e = 0mW/cm 2 LTR-209 Water Clear No LTR-209H Dark Yes Infrared Emitter and Flash LED SMD LED Through Hole Lamp LED Display Automotive LED Signage LED Lighting LED Optical Sensors Photocoupler UV LED Detector 216

220 Phototransistors_Side Look 5.72 x 4.40 x 2.25 mm Part No. Lens Color Visable Light Fiber Min. On State Collector Current I CE =5V; E e =1mW/cm 2 ; λ=940nm Max. Dark Current V CE =10V Max. Collector-Emitter Saturation Voltage V CE(SAT) I c =100μA E e = 1mW/cm 2 Min. Collector-Emitter Breakdown Voltage V (BR)CEO I c =1mA E e = 0mW/cm 2 LTR-301 Water Clear No Phototransistors_Side Look 4.0 x 3.0 x 2.95 mm Part No. Lens Color Visable Light Fiber Min. On State Collector Current I CE =5V; E e =1mW/cm 2 ; λ=940nm Max. Dark Current V CE =10V Max. Collector-Emitter Saturation Voltage V CE(SAT) I c =100μA E e = 1mW/cm 2 Min. Collector-Emitter Breakdown Voltage V (BR)CEO I c =1mA E e = 0mW/cm 2 LTR-306 Red Clear No Phototransistors_Side Look 4.12 x 4.0 x 2.25 mm Part No. Lens Color Visable Light Fiber Min. On State Collector Current I CE =5V; E e =1mW/cm 2 ; λ=940nm Max. Dark Current V CE =10V Max. Collector-Emitter Saturation Voltage V CE(SAT) I c =100μA E e = 1mW/cm 2 Min. Collector-Emitter Breakdown Voltage V (BR)CEO I c =1mA E e = 0mW/cm 2 LTR-309 Water Clear No LED Catalog

221 Phototransistors_Side Look Part No. Lens Color 6.8 x 5.0 x 3.0 mm Visable Light Fiber Phototransistors_Side Look 4.77 x 5.0 x 3.0 mm Phototransistors_Side Look 4.77 x 5.0 x 3.0 mm Min. On State Collector Current I CE =5V; E e =1mW/cm 2 ; λ=940nm Max. Dark Current V CE =10V Max. Collector-Emitter Saturation Voltage V CE(SAT) I c =50μA E e = 1mW/cm 2 Min. Collector-Emitter Breakdown Voltage V (BR)CEO I c =1mA E e = 1mW/cm 2 LTR-5579DP1 Dark Yes Part No. Lens Color Visable Light Fiber Min. On State Collector Current I CE =5V; E e =1mW/cm 2 ; λ=940nm Max. Dark Current V CE =10V Max. Collector-Emitter Saturation Voltage V CE(SAT) I c =50μA E e = 0.5mW/cm 2 Min. Collector-Emitter Breakdown Voltage V (BR)CEO I c =1mA E e = 0mW/cm 2 LTR-5986H Water Clear No Part No. Lens Color Visable Light Fiber Min. On State Collector Current I CE =5V; E e =1mW/cm 2 ; λ=940nm Max. Dark Current V CE =10V Max. Collector-Emitter Saturation Voltage V CE(SAT) I c =100μA E e = 1mW/cm 2 Min. Collector-Emitter Breakdown Voltage V (BR)CEO I c =1mA E e = 0mW/cm 2 Infrared Emitter and Flash LED SMD LED Through Hole Lamp LED Display Automotive LED Signage LED Lighting LED Optical Sensors Photocoupler UV LED Detector LTR-5888DH Dark Yes

222 Phototransistors_Side Look 6.8 x 5.0 x 3.0 mm Part No. Lens Color Visable Light Fiber Min. On State Collector Current I CE =5V; E e =1mW/cm 2 ; λ=940nm Max. Dark Current V CE =10V Max. Collector-Emitter Saturation Voltage V CE(SAT) I c =50μA E e = 0.5mW/cm 2 Min. Collector-Emitter Breakdown Voltage V (BR)CEO I c =1mA E e = 0mW/cm 2 LTR-5576D Dark Yes Phototransistors_SMD Type 3.2 x 1.6 x 1.1 mm Part No. Lens Color Visable Light Fiber Min. On State Collector Current I CE =5V; E e =0.5mW/cm 2 ; λ=940nm Max. Dark Current V CE =20V Max. Collector-Emitter Saturation Voltage V CE(SAT) I c =100μA E e = 0.5mW/cm 2 Min. Collector-Emitter Breakdown Voltage V (BR)CEO I c =1mA E e = 0mW/cm 2 LTR-C1503 Clear No Phototransistors_SMD Type 1.6 x 0.8 x 0.8 mm Part No. Lens Color Visable Light Fiber Min. On State Collector Current I CE =5V; E e =0.5mW/cm 2 ; λ=940nm Max. Dark Current V CE =20V Max. Collector-Emitter Saturation Voltage V CE(SAT) I c =100μA E e = 0.5mW/cm 2 Min. Collector-Emitter Breakdown Voltage V (BR)CEO I c =100μA E e = 0mW/cm 2 LTR-C1903 Clear No LED Catalog

223 Phototransistors_SMD Type Part No. Lens Color 3.2 x 2.4 x 2.4 mm Visable Light Fiber Phototransistors_SMD Type 3.2 x 1.6 x 1.85 mm Min. On State Collector Current I CE =5V; E e =0.5mW/cm 2 ; λ=940nm Max. Dark Current V CE =20V Max. Collector-Emitter Saturation Voltage V CE(SAT) I c =100μA E e = 0.5mW/cm 2 Min. Collector-Emitter Breakdown Voltage V (BR)CEO I c =100μA E e = 0mW/cm 2 LTR-C9303B Dark Yes Part No. Lens Color Visable Light Fiber Min. On State Collector Current I CE =5V; E e =0.5mW/cm 2 ; λ=940nm Max. Dark Current V CE =20V Max. Collector-Emitter Saturation Voltage V CE(SAT) I c =100μA E e = 0.5mW/cm 2 Min. Collector-Emitter Breakdown Voltage V (BR)CEO I c =100μA E e = 0mW/cm 2 LTR-C950-TB-T Dark Yes Infrared Emitter and Flash LED SMD LED Through Hole Lamp LED Display Automotive LED Signage LED Lighting LED Optical Sensors Photocoupler UV LED Detector 220

224 Phototransistors_SMD Type 3.2 x 2.5 x 1.6 mm Part No. Lens Color Visable Light Fiber Min. On State Collector Current I CE =5V; E e =0.5mW/cm 2 ; λ=940nm Max. Dark Current V CE =20V Max. Collector-Emitter Saturation Voltage V CE(SAT) I c =100μA E e = 0.5mW/cm 2 Min. Collector-Emitter Breakdown Voltage V (BR)CEO I c =100μA E e = 0mW/cm 2 LTR-S951-TB Dark Yes Phototransistors_SMD Type 3.2 x 2.4 x 1.6 mm Part No. Lens Color Visable Light Fiber Min. On State Collector Current I CE =5V; E e =0.5mW/cm 2 ; λ=940nm Max. Dark Current V CE =20V Max. Collector-Emitter Saturation Voltage V CE(SAT) I c =100μA E e = 0.5mW/cm 2 Min. Collector-Emitter Breakdown Voltage V (BR)CEO I c =100μA E e = 0mW/cm 2 LTR-S971-TB Dark Yes LED Catalog

225 Phototransistors_SMD Type Part No. Photolink_Transmitter Part No. Lens Color 3.0 x 2.0 x 1.0 mm Visable Light Fiber 7x3 Data Rate (Mbps) Min. On State Collector Current I CE =5V; E e =0.5mW/cm 2 ; λ=940nm Operating Voltage (V) Max. Dark Current V CE =20V Max. Collector-Emitter Saturation Voltage V CE(SAT) I c =100μA E e = 0.5mW/cm 2 Min. Collector-Emitter Breakdown Voltage V (BR)CEO I c =100μA E e = 0mW/cm 2 LTR-S320-TB Dark Yes Fiber Coupling Light Output (dbm) Min Max Min Typ Max LTDL-TA16A LTDL-TA25A Infrared Emitter and Flash LED SMD LED Through Hole Lamp LED Display Automotive LED Signage LED Lighting LED Optical Sensors Photocoupler UV LED Detector 222

226 Photolink_Transmitter 5x3 Part No. Data Rate (Mbps) Operating Voltage (V) Fiber Coupling Light Output (dbm) Min Max Min Typ Max LTDL-TA25B Photolink_Transmitter 7x3 Part No. Data Rate (Mbps) Operating Voltage (V) Input Sensitivity (dbm) Min Max Min Max LTDL-RA16A LTDL-RA25A LED Catalog

227 Infrared Transceiver Part No. Data Rate (kbit/s) Infrared Transceiver Package Dimension (H x W x D) (mm) Link Distance (M) Idle Current Shutdown Current (na) Receiver Latency (us) Sypply Voltage (V) HSDL x 8.00 x to to 3.6 V - HSDL x 8.00 x to to 3.6 V - Part No. 2.5 x 8.0 x 3.0 mm 1.6 x 7.0 x 2.8 mm Data Rate (kbit/s) Package Dimension (H x W x D) (mm) Link Distance (M) Idle Current Shutdown Current (na) Receiver Latency (us) Sypply Voltage (V) HSDL x 7.00 x to to 3.6 V - - HSDL-3208-S x 7.40 x to to V Front Front Top Top Front (Shielded) Front (Shielded) Infrared Emitter and Flash LED SMD LED Through Hole Lamp LED Display Automotive LED Signage LED Lighting LED Optical Sensors Photocoupler UV LED Detector 224

228 Optical Sensor

229 Ambient Light Sensor Part No. Description Package Type LTR-329ALS Digital Light Sensor Ambient Light Sensor Part No. Description Package Type LTR-303ALS 2.00 x 2.00 x 0.70 mm 2.00 x 2.00 x 0.70 mm Digital Light Sensor Operating Temp ( C) Supply Voltage (V) ChipLED 4 pins -30 to to 3.6 Operating Temp ( C) Supply Voltage (V) ChipLED 6 pins -30 to to 3.6 Interface I2C fast mode (400kbit/s) Interface I2C fast mode (400kbit/s) Interrupt & Persist No Interrupt & Persist Yes DLS Full Scale ADC Count 16-bit ADC (linear) DLS Full Scale ADC Count 16-bit ADC (linear) Light Range 0.01 lux to 64k lux Light Range 0.01 lux to 64k lux Infrared Emitter and Flash LED SMD LED Through Hole Lamp LED Display Automotive LED Signage LED Lighting LED Optical Sensors Photocoupler UV LED Detector 226

230 Ambient Light Sensor 2.00 x 2.00 x 0.70 mm Part No. Description Package Type Operating Temp ( C) Supply Voltage (V) Interface Interrupt & Persist DLS Full Scale ADC Count Light Range LTR-308ALS Very Low Power Consumption Digital Light Sensor ChipLED 6 pins -40 to to 3.6 I2C fast mode (400kbit/s) Yes Up to 20-bit ADC (linear) 0.01 lux to 157k lux RGB Color Sensor 2.00 x 2.00 x 0.70 mm Part No. Description Package Type Operating Temp ( C) Supply Voltage (V) Interface Interrupt & Persist DLS Full Scale ADC Count Light Range LTR-380RGB RGB Sensor + Digital Light Sensor ChipLED 6 pins -40 to to 3.6 I2C fast mode (400kbit/s) Yes Up to 20-bit ADC (linear) 0.01 lux to 157k lux 227 LED Catalog

231 UV Sensor Part No. Description Package Type LTR-390UV UV Sensor + Digital Light Sensor Proximity Sensor 3.94 x 2.36 x 1.35 mm Part No. Description Package Type LTR-659PS 2.00 x 2.00 x 0.70 mm Digital Proximity Sensor+ IR LED Operating Temp ( C) Supply Voltage (V) ChipLED 6 pins -40 to to 3.6 Operating Temp ( C) Interface I2C fast mode (400kbit/s) Supply Voltage (V) ChipLED 8 pins -30 to to 3.6 Interrupt & Persist Interface Yes I2C fast mode (400kbit/s) DLS / UV Full Scale ADC Count Up to 20-bit ADC (linear) Interrupt & Persist Yes Light Range 0.01 lux to 157k lux PS Full Scale ADC Count 11-bit ADC(linear) UV Sensitivity (Count/ UVI) 1400 Detection Range (mm) Infrared Emitter and Flash LED SMD LED Through Hole Lamp LED Display Automotive LED Signage LED Lighting LED Optical Sensors Photocoupler UV LED Detector 228

232 PS ALS Proximity Sensor 3.94 x 2.36 x 1.50 mm Part No. Description Package Type Operating Temp ( C) Supply Voltage (V) Interface Interrupt & Persist PS Full Scale ADC Count Detection Range (mm) LTR-676PS Digital Proximity Sensor+ IR LED (Small Window) ChipLED 8 pins -40 to to 3.6 I2C fast mode (400kbit/s) Yes Up to 11-bit ADC(linear) in-1 Integrated Sensor 1.30± ~0.03mm 0.40 Pin 1 Marking Ambient Light Sensor 0.309x0.309 mm^2 Proximity Light Sensor 0.215x0.215 mm^2 4x VDD 2. AGND 3. LED GND 4. SEL 5. LDR 6. INT 7. SCL 8. SDA 6x ± x x 2.00 x 1.30 mm ± ± x0.30 6x0.35 8x0.025 Part No. Description Package Type Operating Temp ( C) Supply Voltage (V) Interface Interrupt & Persist DLS Full Scale ADC Count Light Range PS Full Scale ADC Count Detection Range (mm) LTR-507ALS (2-in-1) Digital Light Sensor+Long Distance Proximity Sensor+LED Driver ChipLED 8 pins -40 to to 3.6 I2C fast mode (400kbit/s) Yes Up to 20-bit ADC (linear) 0.01 lux to 64k lux 11-bit ADC(linear) LED Catalog

233 3-in-1 Integrated Sensor Part No. LTR-559ALS 3-in-1 Integrated Sensor Part No. LTR-578ALS Description (3-in-1) Digital Light Sensor+Proximity Sensor+IR LED Description 3.94 x 2.36 x 1.35 mm 3.94 x 2.36 x 1.35 mm (3-in-1, Small Window, FOV = +/- \40deg) Digital Light Sensor+Proximity Sensor+IR LED Package Type ChipLED 8 pins Package Type ChipLED 8 pins Operating Temp ( C) -30 to +70 Operating Temp ( C) -40 to +85 Supply Voltage (V) 2.4 to 3.6 Supply Voltage (V) 1.7 to 3.6 Interface I2C fast mode (400kbit/s) Interface I2C fast mode (400kbit/s) Interrupt & Persist Yes Interrupt & Persist Yes DLS Full Scale ADC Count 16-bit ADC (linear) DLS Full Scale ADC Count Up to 20-bit ADC (linear) Light Range 0.01 lux to 64k lux Light Range 0.01 lux to 157k lux PS Full Scale ADC Count 11-bit ADC(linear) PS Full Scale ADC Count Up to 11-bit ADC(linear) Detection Range (mm) Detection Range (mm) Infrared Emitter and Flash LED SMD LED Through Hole Lamp LED Display Automotive LED Signage LED Lighting LED Optical Sensors Photocoupler UV LED Detector 230
